S O L U T I O N S F O R Y O U R B U S I N E S S Optical Inspection Loupes • Magnifiers • Hand-Held Microscopes I n t e r n a t i o n a l TM S O L U T I O N S F O R Y O U R B U S I N E S S Optical Inspection Loupes • Magnifiers • Hand-Held Microscopes I n t e r n a t i o n a l TM www.startinternational.com Optical Inspection Product Catalog

TA B L E O F C O N T E N T S M A G N I F I E R S Aspheric Magnifiers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Benchtop Magnifiers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Eyeglass Magnifiers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Headband Magnifiers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Linen...

ASPHERIC MAGNIFIERS Page 1 I n t e r n a t i o n a l www.startinternational.com • info@startinternational.com $50 Minimum order. Specifications are subject to change without notice. © 2007 START International ABOUT ASPHERIC MAGNIFIERS Aspheric magnifiers, unlike spherical magnifiers, provide an “orthoscopic” image. Our aspheric lenses are shaped with a variant radii calculated to produce a sharp image right to the edge of the lens. This allows for distortion free viewing over the entire lens area with greater magnification than is possible with a normal spherical lens. START International...

BENCH TOP MAGNIFIERS Page 2 START International HIGH POWER BENCH TOP MAGNIFIERS Features: • Compact with a small bench footprint • 2 magnifications to choose fro • All metal construction • Clear glass lenses • 22 watt bulb with bulb cover Catalog # GM127-2 GM127-4 Lens Power 2X (4 Diopter) 4X (16 Diopter) Lens Aperture 4.75" (120mm) 4.75" (120mm) Field of View 6.50" (165mm) 5.25" (133mm) Working Distance 6.30" (160mm) 4.33" (110mm) Eye Point 5.91" (150mm) 5.12" (130mm) Base Dimensions 11.5 x 7.25" (295 x 184mm) Horizontal bar 4.25" (108mm) Vertical Support Bar 9" (229mm) Bulb Type 22W...

EYEGLASS MAGNIFIERS Page 3 I n t e r n a t i o n a l www.startinternational.com • info@startinternational.com $50 Minimum order. Specifications are subject to change without notice. © 2007 START International EYEGLASS MAGNIFIERS General Features for ALL eyeglass magnifiers: • Lightweight and comfortable • Reduce eye fatigue • Swing out of the line of vision when not in use Donegan Optical BINOCULAR MAGNIFIERS Features: • Optical quality acrylic lens • Frame and lens weight less than 1.3 oz. (37g) • Frame made of a special highly durable and flexible plastic • Lens can clip onto your...

HEADBAND MAGNIFIERS Page 4 BINOCULAR HEADBAND MAGNIFIERS General Features for ALL headband magnifiers: • Unrestricted view while reducing eye strain • Leaves both hands free • Can be worn over prescription eyeglasses • Adjustable contoured headband • Pivots out of the way when not in use Catalog # Power Working Distance GM7004 2.2X 6.7" (170mm) 3.3X 4.0" (110mm) 4.1X 2.5" (65.0mm) 5.2X 1.8" (45.0mm) Catalog # Power Working Distance DODA2 1.50X 20" (508mm) DODA3 1.75X 14" (356mm) DODA4 2.00X 10" (254mm) DODA5 2.50X 8" (200mm) DODA7 2.75X 6" (150mm) DPDA10 3.50X 4" (110mm) *DOLP1 2.50X...

LINEN TESTERS Page 5 I n t e r n a t i o n a l www.startinternational.com • info@startinternational.com $50 Minimum order. Specifications are subject to change without notice. © 2007 START International Catalog # Power Lens Diameter Field of View Weight Double Lens TS1006WZ3* 6X 1.10" (27.9mm) 1.00" (25.4mm) 2.2 oz. (46g) Models TS2003WA3 3X 1.80" (45.7mm) 2.00" (50.8mm) 5.2 oz. (114g) * Machined from zinc, all others aluminum Catalog # Power Lens Diameter Field of View Weight Single Lens TS1209SA3 9X 0.5" (12.7mm) .50" (12.7mm) 0.5 oz. (14g) Models TS3407SA3 7X 0.8" (20.3mm) .75" (19.1mm)...

FIXED FOCUS LOUPES Page 6 Catalog # OP2000 GM7010 GM7015 Power 8X 10X 15X Lens Diameter 0.95" (24mm) 1.18" (30mm) .75" (19.1mm) Field of View 1.25" (32mm) 1.25" ( 32mm) .50" (12.7mm) Optical System 2 lens 2 lens 2 lens Lens Material Acrylic Acrylic Optical Glass Weight 1.0 oz. (28g) 0.9 oz. (25.5g) 0.7 oz. (19.8g) Overall Dimensions 1.93ø x 1.67" 1.43ø x 1.68" 1.40ø x 1.34" (49.0 x 42.0mm) (36.3 x 42.7mm) (35.5 x 34.0mm) FIXED FOCUS ILLUMINATED LOUPES Feature: • Optical quality glass lens elements Catalog # TS1966 OPM100 TS2023 Power 10X 10X 15X Lens Diameter 1.00" (25.4mm) 1.07" (27.2mm)...

HAND LOUPES Page 7 I n t e r n a t i o n a l www.startinternational.com • info@startinternational.com $50 Minimum order. Specifications are subject to change without notice. © 2007 START International Catalog # Power Lens Diameter Dimensions Weight TS2022-75 1.3X 2.95" (75mm) 3.03 x 7.68 x .98" 8.64 oz. (245g) (77 x 195 x 25mm) TS2022-55 2.0X 2.13" (54mm) 2.20 x 6.89 x .87" 4.13 oz. (117g) (56 x 175 x 22mm) TS2022-35 4.0X 1.46" (37mm) 1.54 x 6.10 x .60" 2.35 oz. (67.0g) (39 x 155 x 15mm) Bausch & Lomb® GLASS LENS READING MAGNIFIER Features: • Distortion free • Provides true color...

Page 8 I n t e r n a t i o n a l www.startinternational.com • info@startinternational.com $50 Minimum order. Specifications are subject to change without notice. © 2007 START International Peak JEWELERS LOUPES Features: • Soft vinyl housing for comfort or spun aluminum housing for durability • High quality optical glass lenses • Small hole in eyepiece helps prevent clouding of the lens when in use • Lenses in spun aluminum loupes are easily removed for cleaning Aluminum Body Catalog # Power # lenses Focal Length Lens Diameter Single Lens TS2048A13 3.3X 1 3.0" (76.2mm) .9" (23mm) TS2048A16...
