Product Catalog www.STARTinternational.com E L E C T R I C / A U T O M A T I C Tape Dispensers - Label Dispensers - Non-Adhesive Cutters A S O L U T I O N F O R E V E R Y N E E D

ABOUT START International has provided solutions for manufacturing companies worldwide since 1981. We provide the service and expertise that are required to ensure that our customers are fitted with the best equipment for the job. Our company is built on adding value to production lines and building relationships with our customers. MISSION START’s mission is to continuously provide the highest quality products, build and maintain relationships with our customers, and to constantly improve the customer service experience. INNOVATION START’s best product innovations come from simple observations...

AUTOMOTIVE Tape Dispensers Wire Harnessing Double Face or VHB Application Parts Assembly Paint Masking Parts Pass-Fail Process Label Dispensers Product ID Safety Notification Die-Cut Double Face Die-Cut Gaskets Non-Adhesive Cutters Heat Shrink Tubing Sleeving Stripping Seat Belts Ribbon Mesh Let START fit your application FOOD / BEVERAGE Tape Dispensers Safety Seal Bag Sealing Box Sealing SHOE MANUFACTURING Tape Dispensers Cloth Tapes Double Transfer Label Dispensers Product ID Size ID Non-Adhesive Cutters Ribbon Leather Cloth Shoelaces Elastics Velcro® PHARMACEUTICAL / MEDICAL Tape Dispensers...

VERSATILITY Virtually any tape can be dispensed on our machines for use in a variety of industries. ACCURACY Tolerance of +/- .04” (1mm) within the programmed length on each cut. PRECISION Each piece is cut clean for accurate and attractive tape presentation. EFFICIENCY Increase productivity and reduce material costs. USABILITY Easy set-up and operation, with virtually no operator training needed. Look for the START holographic seal to ensure product authenticity!

Please refer to our website for the latest products and specifications. Specifications are subject to change without notice. [email protected] www. startinternational.com 3 TAPE Dispensers MODEL # Max. Outside 3-in-1 Core Accuracy Length Tape Width Cut Length Dia. of Roll Hlder of Cut** Setting Weight Dimensions zcM1000 .28 to 2.0” .79 to 39” 7” 1”, 1.4”,3” +/–.04” digital 5.3 lbs 9.7”(L) x 5.4”(W) x 5.9”(H) (7 to 51mm) (20 to 999mm) (178mm) (25, 35, 76mm) (1mm) (LED) (3.4 kg) 24.5cm(L) x 13.7cm(W) x 15cm(H) Electrical requirements: 117V 50/60Hz, <1 amp (220V 50/60Hz available) ** dependent...

Please refer to our website for the latest products and specifications. Specifications are subject to change without notice. [email protected] www. startinternational.com 5 TAPE Dispensers Electronic Tape Dispenser with Safety Guard Cutting Head Safety guard system prevents activation of cutter when foreign objects are present (fingers, tools, etc.) Ideal for medium to high production of repetitive taping for industrial applications Program a defined length and automatically advance and cut tape Accepts tape widths from .28” to 2” (7 to 51mm) Cuts tape lengths from 1.2” to 39” (30 to...

TAPE Dispensers Please refer to our website for the latest products and specifications. Specifications are subject to change without notice. [email protected] www. startinternational.com 6 Cut Max. Outside Core Accuracy MODEL # Tape Width Length Dia. of Roll Diameter of Cut* Weight Footprint Dimensions TDA080 .25 to 3.15” 1.6 to 394” 9” 3” +/- .04” 23.4 lbs 9.25(L) X 6.75”(W) 9”(L) x 6.625”(W) x 12”(H) (6 to 80mm) (40 to 9999mm) (228mm) (76mm) (1mm) (10.6 kg) (235 X 172mm) 229mm(L) x 168mm(W) x 305mm(H) Electrical requirements: 115V 50/60Hz <2 amps (220V 50/60Hz available) * Dependent...

Please refer to our website for the latest products and specifications. Specifications are subject to change without notice. [email protected] www. startinternational.com 7 TAPE Dispensers Add’l info for TDA080 Modifications .. Heavy-duty metal construction .. All metal gears and advancement rollers .. 4 modes of operation: manual feed-manual cut, manual feed and cut, auto feed and cut and interval feed and cut .. Guillotined cut for a straight edge piece of tape .. Digital push switch display for easy length adjustments .. Safety interlock .. Accuracy +/- .04” (1mm) (dependent on type...

TAPE Dispensers Please refer to our website for the latest products and specifications. Specifications are subject to change without notice. [email protected] www. startinternational.com 8 Electronic Electronic “Heavy-Duty” Tape Dispenser – 150mm Wide Ideal for high production of repetitive taping for industrial applications Program a defined length and automatically advance and cut tape Accepts tape widths from .25” to 5.9” (6 to 150mm) Cuts lengths from 1.6” to 394” (40 to 9999mm) Cut Max. Outside Core Accuracy MODEL # Tape Width Length Dia. of Roll Diameter of Cut* Weight Dimensions...

Please refer to our website for the latest products and specifications. Specifications are subject to change without notice. [email protected] www. startinternational.com 9 TAPE Dispensers Cut Max. Outside Core Accuracy Tape Feed Adjustable Length MODEL # Tape Width Length Dia. of Roll Diameter of Cut* Cutter Type Tape Spacing Setting Weight TDA025 .12 to .98” .47 to 2.36” 5.1” (130mm) 1”, 1.25” & 3” +/–.04” automatic carousel yes mechanical 6.2 lbs (3 to 25mm) (12 to 60mm) (25, 32, & 76mm) (1mm) (lead screw) (2.75 kg) Dimensions: 11.8”(30cm)L x 6.3”(16cm)W x 6.3”(16cm)H Electrical...

*SHOWN WITH THE TDA080 Electric / Manual z cM0300 Manual Tape Dispe with Hand Lever Ideal for low volume produ Definite length tape dispenser Dispense tape from .25” to 1” (6 to 25mm) in width Dispense tape from .50” to 4” (13 to 102mm) in length with a single pull TDM080 Manual Lever Tape Dispenser Ideal for low volume produc Lever operated definite leng Dispense tape from .38” (10mm) to 3.15” (80mm) Dispense tape from 1” to 10” (25 to 254mm) with each lever stroke TDLR050B Universal Liner Remover/Tape Dispenser Excellent for foil tapes with an inside liner Will handle up to 2” (51mm) wide tapes...
