Stäubli Fluid Connectors
GPV 14 Liquefied Petroleum (LPG)

GPV 14 Liquefied Petroleum (LPG)

Product catalog summary

Compatibility and Standards:
The GPV 14 nozzle is compatible with EN13760 and ISO 19825 K15 receptacles found on vehicles. It is designed in accordance with the ATEX Directive 2014/34/UE for explosive atmospheres and holds UL certification under the UL 125 standard.

Ease of Use:
The nozzle operates similarly to a petrol pump nozzle. Users simply position the nozzle at the receptacle and operate the trigger.

Safety Features:
The nozzle features fully automatic operation with an audible click upon engagement. The circuit closes and opens automatically with trigger activation, ensuring no gas flow unless properly engaged. Incomplete locking is impossible, and the nozzle unlocks automatically when the trigger is released.

Storage and Design:
The nozzle should be stored in a specially designed holder to protect it from weather and pollutants. Its flat-surface, anti-pollution design ensures spill-free connections, reducing the risk of burns from gas release.

Customization and Weight:
The nozzle allows for customization with space for a logo and weighs only 1.5 kg.

Reliability:
No radial forces act on seals during handling, and there are no dynamic seals in the fluid stream. The autoclave front seal increases sealing force with pressure.

Applications:
Suitable for self-service filling of private vehicles, commercial vehicles, and lift trucks powered by liquefied petroleum gas (LPG).

Technical Specifications:
Constructed with an aluminum casing and insulated polyamide surfaces, the nozzle is compatible with LPG. It has a maximum allowable pressure of 25 bar, operates between -40°C and +65°C, and has a minimum LPG flow of 125 l/min at 20°C with a 0.7 bar loss. Maximum leakage volume is 0.4 cm³, with electrical resistance under 10 Ohm and resistance to saline spray over 144 hours. It is mechanically strong for over 100,000 cycles.

Associated Products:
For enhanced safety, the GPV 14 can be used with the BRW 11 break-away coupling, which allows for immediate disconnection and automatic circuit shut-off if the hose is accidentally pulled.

Global Presence:
Stäubli has a global presence, and the GPV 14 nozzle is part of their reliable and sustainable product offerings.

Catalog excerpts

FAST MOVING TECHNOLOGY Staubu FAST MOVING TECHNOLOGY Staubu Self service refuelling | LPG (Autogas) vehicles

Open the catalog to page 1

US patent 7 040 358 And other countries Totally safe operation Self-service filling for vehicles powered by liquefied petroleum gas. ■■ Commercial vehicles Lift trucks... No radial forces acting on the seals when the circuit is opened or closed during handling. No gas flow is possible unless the refuelling nozzle is engaged in the No dynamic seals in the fluid stream. connecting piece. Private vehicles The inline connection principle rules out Autoclave front seal: the sealing force Incomplete locking is impossible. increases with pressure. The circuit is closed and the nozzle unlocks automatically...

Open the catalog to page 2

Technical data Maximum allowable pressure PS (bar) Construction ■ Aluminium casing ■ Insulated polyamide handling surfaces Materials compatible with LPG. For even greater safety, use the GPV 14 refuelling nozzle in combination with the BRW 11 break-away coupling. This system permits immediate disconnection and automatic circuit shut-off if the hose is accidentally pulled on or pulled out of the connecting piece. You can find out more about it in our documentation RQ002.

Open the catalog to page 3

Stäubli Units Stäubli Units Representatives /Agents Representatives / Agents Global presence of the Stäubli Group www.staubli.com Staubli is a trademark of Stäubli International AG, registered in Switzerland and other countries. © Stäubli 20/02/2020. We reserve the right to modify product specifications without prior notice. [email protected] | Photocredits: Stäu

Open the catalog to page 4
