SPX ClearSky Plume Abatement System *J CREATING CLEARER VIEWS COOLING TECHNOLOGIES

Nothing Could Be Clearer Cooling tower systems have been around for decades; in fact, SPX Cooling Technologies has been synonymous with leading cooling tower technology since 1894. And while every SPX cooling system is designed for maximum performance, certain environmental conditions can lead to visible water vapor plumes — plumes that can affect visibility and safety as well as public perception, and potentially delay permits and jeopardize project timelines. For many, finding a cooling solution that provides exceptional performance and value while minimizing plume development has been...

A Break in the Clouds ClearSky Plume Abatement System Why is plume abatement important? Aesthetics / Neighbor Relations – Even though the cooling tower plume is made up of water vapor, a community may perceive it as unwanted or smoke-related. This may affect the use of nearby land or decrease property values. Safety – Community concerns regarding visibility can be removed by significantly reducing visible plume. Retrofit – The ClearSky Plume Abatement System can be added to existing cooling towers in many cases, making plume abatement even more economical. Permitting – Permitting can be a...

Marley created the industry’s first plume abatement tower. Performance with Leading Edge Technologies SPX ClearSky Plume Abatement System is a ground-breaking approach to the reduction of cooling plumes. Employing leading-edge technology, not only does ClearSky provide the proven performance you need — including design flexibility — but it can also lower installation and operating costs. In fact, ClearSky has simply the best value proposition in plume abatement — it can even be installed into existing cooling tower applications, negating the need for complete system replacement. For...

Forget What You’ve Seen Before The power behind the ClearSky system lies in its elegance and simplicity. Building on the highly successful and effective SPX Cooling Technologies coil plume solution system, ClearSky provides the latest, evolutionary solution with its unique patented design that is as effective as it is unconventional.

ClearSky Cooling Process 1 Ambient air passes through the warm, wet section Warm, saturated air travels in between alternate pairs of plates Cooler, saturated air from the wet section side and warmer dryer air from ambient side mix together Ambient air passes into ducts Ambient air travels in between alternate pairs of plates Clear the air with your neighbors. Clear away your plume.

Now You See It Now You Don’t It’s not enough to simply say something works — you need proof. That’s why the ClearSky story begins with SPX, a leading name in cooling towers for more than a century. SPX Cooling Technologies has more than 80 plume abatement installations worldwide, and the story continues based on technology funded in part by the U.S. Department of Energy as well as hundreds of thousands of hours of real-world operation. Empowered by that legacy and expertise, the ClearSky Plume Abatement System provides effective, economical operation. COST SAVINGS SAVINGS POTENTIAL Lower...

Multiple Needs, Singular Solution The ClearSky system offers several unique benefits to EPCs, End Users and Regulators. That’s because ClearSky was developed based on a variety of criteria, reflecting diverse needs, applications, and conditions, including the following: Safety and visibility concerns Regulation compliance Sunlight impairment Aesthetics Community and neighbor relations Water Conservation As a result, ClearSky offers solutions for multiple audiences, in turn providing them with the key features and benefits they need to meet their own specific challenges. Engineering,...

End Users/Operators When plume abatement is necessary, ClearSky allows cooling tower operators to reduce plume production, minimizing operating costs without compromising cooling performance versus more expensive dry solutions. Regulators By minimizing visibility and safety issues, ClearSky provides cooling tower operators with an effective and reasonable solution for compliance with plume regulations. » Reduced Maintenance – No coil replacement or fin cleaning, plus reduced operator monitoring and training » Environmental Agency Regulations – Utilizes less energy, and has lower carbon...

SPX Cooling Technologies is a world-leading full-line cooling tower and air-cooled condenser manufacturer. The company provides exceptional-quality evaporative cooling towers, fluid coolers and evaporative condensers under the Marley and Balcke brand names. Ernst-Dietrich-Platz 2 40882 Ratingen GERMANY 49 (0)2102 1669 681 infode@spx.com spxcooling.com In the interest of technological progress, all products are subject to design and/or material change without notice. ©2009 SPX Cooling Technologies eu_CLEARSKY-09
