HIGH PERFORMANCE CARD LOCK & EJECTOR CLIP PINS SPIROL® Series 880 Coiled Spring Pins The flexibility of the Series 880 Coiled Spring Pin makes it the ideal hinge pin for PC board card lock and ejector mechanisms. The Coiled Pin simplifies the design and manufacturing processes. The quality of the hinge is unsurpassed by any other fastening method due to the low insertion force and compression of the pin during and after installation. The pin's uniform radial spring force results in a controlled hinge movement that remains consistent throughout the life of the assembly. The Coiled Pin offers a wide range of benefits over other types of components used as hinge pins. Features/Benefits: Flexible • Unlike any other pin, the Coiled Pin absorbs forces to preserve joint integrity and prevent cracked hinges throughout the life of the assembly. • The Coiled Pin conforms to the widest hole tolerance of any press-fit pin in the industry, and does not damage the plastic to retain itself. Self Retaining • No secondary operations are required for retention. Simply insert the pin into the hole. Corrosion Resistant • The Coiled Pins are manufactured from 302/304 stainless steel so they will not rust in the assembly. Conducive for Manual or Automatic Installation • Regardless of how the pin is installed, the pin installs easily with low insertion forces. Orientation is not required.

High Performance Card Lock & Ejector Clip Pins D U.S.A. Spirol West Inc. 1950 Compton Avenue, Unit 111 Corona, California 92881-6471 Tel. +1 (1) 951.273.5900 Fax. +1 (1) 951.273.5907 EJECTOR CLIP E D Spirol International Corporation 30 Rock Avenue Danielson, Connecticut 06239 Tel. +1 (1) 860.774.8571 Fax. +1 (1) 860.774.2048 (US Distributors: Fax. 1.860.774.0487) Spirol International Corporation Shim Division 321 Remington Road Stow, Ohio 44224 Tel. +1 (1) 330.920.3655 Fax. +1 (1) 330.920.3659 P Canada Spirol Industries, Ltd. 3103 St. Etienne Boulevard Windsor, Ontario Canada N8W 5B1 Tel. +1...
