Introduction
This document outlines the specifications and operational guidelines for various coaxial switch types, including manual, impulse solenoid drive, lifting magnet drive, and motor drive systems. Each switch type is tailored for specific applications and conditions.

Manual Operation
These switches are manually operated using a knob and are locked in position to withstand vibration or rotation.

Impulse Solenoid Drive (Latching)
Features a rotating permanent magnet within a stationary coil, providing two stable positions. It requires a pulse control signal and retains its position during power outages.

Lifting Magnet Drive (Failsafe)
Uses electromagnetic force to move a lever, which returns to its resting position when the control signal stops, aided by external forces like a spring. It is not locked in end positions.

Motor Drive
Employs a capacitor motor with a hypocycloidic gear for torque generation, featuring a 90° rotation angle and locked end positions.

Technical Specifications
- Degree of Protection: IP40, with outdoor versions available.
- Temperature Range: Operating: +10°C to +40°C; Storage: -20°C to +80°C.
- Power Ratings: Valid at room temperature, normal pressure, and 50% humidity.
- Dimensions: Provided in mm.

2-Way Switches
Details on models include frequency range, isolation, insertion loss, and power rating, with specifics on connectors, lifetime, weight, voltage, and current.

Specifications

Operating Current: ≤ 1.0 A and ≤ 1.5 A.
Switch Over Time: ≤ 160 ms, ≤ 1.0 s, and ≤ 1.2 s.
Lifetime: ≥ 250,000 operations.
Weight: Approximately 10.5 kg, 26.5 kg, and 38 kg.
Connectors: Various EIA sizes (50Ω).
Operating Voltage: 230 V AC ± 10%, 50...60 Hz.
Control Voltage: 24 V DC ± 10%.

Performance Parameters

Frequency Range: 0 < f ≤ 0.86 GHz and 0 < f ≤ 0.82 GHz.
VSWR: ≤ 1.06 and ≤ 1.08.
Isolation: ≥ 70 dB and ≥ 75 dB.
Insertion Loss: ≤ 0.05 dB and ≤ 0.02 dB.
Power Rating: ≤ 38.0 kW and ≤ 90.0 kW.

Additional Information

Circuit diagrams are on pages 19 and 20.
Designs are subject to modification.

Catalog excerpts

Conditions gnrales de vente tr.row {} td.cell {} div.block {} div.paragraph {}

Open the catalog to page 2

EinleitungIntroduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42-Wege Schalter2 Way Switch DPDTHubmagnetantrieb, monostabilLinear solenoid drive, failsafe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7HandbettigungManual operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8Impulsdrehmagnet, bistabilSolenoid drive, latching . . . . . . . . . . . . . . . . ....

Open the catalog to page 3

Hypocycloidic Gear The drive and the basic switch element (rotor) are connected by a special hypocycloidic gear developed by SPINNER. The hypocycloidic gear changes torque and angular velocity as it turns. Motor Drive Lifting Magnet Drive (Failsafe) Motor driven switches use a capacitor motor (230V/50-60Hz) with a special gear (see hypocycloidic gear), developed by SPINNER, which generates the torque required to turn the switch. This drive system has a 90 rotation angle and is locked in both end positions. By application of electromagnetic force a lever is lifted from its resting position to...

Open the catalog to page 4

Dimensions All dimensions are given in mm. Degree ofProtection Storage and Operating Temperatures Signalling and Interlock Contacts IP40 (according to EN60529) is the degree of pro- tection for the switches so they are only suitable for indoor installation. Switches for outdoor installation are available on request. The operating temperature is +10C to +40аC and the storage temperature is -20C to +80аC. Switches for larger temperature ranges are available on request. The signal contacts are designed as potential-free SPDTcontacts and indicate the actual switch position. They can be used up to...

Open the catalog to page 5

Conditions gnrales de vente tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:3.75pt "Arial", sans-serif; } .font1 { font:5.00pt "Arial", sans-serif; } .font2 { font:6.00pt "Arial", sans-serif; } .font3 { font:8.00pt "Arial", sans-serif; } .font4 { font:11.00pt "Arial", sans-serif; } .font5 { font:14.00pt "Arial", sans-serif; } .font6 { font:8.00pt "Arial Black", sans-serif; } .font7 { font:10.00pt "Arial Black", sans-serif; } 2-WEGE SCHALTER, HUBMAGNETANTRIEB, MONOSTABIL 2 WAY SWITCH DPDT, LINEAR SOLENOID DRIVE, FAILSAFE BN 74 37 41 Frequenzbereich Frequency range VSWR Ubersprechd驠mpfung...

Open the catalog to page 7

Conditions gnrales de vente tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:7.00pt "Arial", sans-serif; } .font1 { font:8.00pt "Arial", sans-serif; } .font2 { font:11.00pt "Arial", sans-serif; } .font3 { font:8.00pt "Arial Black", sans-serif; } .font4 { font:10.00pt "Arial Black", sans-serif; } 2-WEGE SCHALTER, HANDBET驀TIGUNG 2 WAY SWITCH DPDT, MANUAL OPERATION BN 75 46 45 Frequenzbereich VSWR Frequency range 0 < f < 1 GHz < 1.03 1 < f < 2 GHz < 1.13 2 < f < 3 GHz < 1.13 3 < f < 5 GHz < 1.22 Ubersprechdmpfung Durchgangsdmpfung Isolation Insertion loss Dauerbelastbarkeit Power...

Open the catalog to page 8

Conditions gnrales de vente tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:3.75pt "Arial", sans-serif; } .font1 { font:5.00pt "Arial", sans-serif; } .font2 { font:7.00pt "Arial", sans-serif; } .font3 { font:8.00pt "Arial", sans-serif; } .font4 { font:11.00pt "Arial", sans-serif; } .font5 { font:8.00pt "Arial Black", sans-serif; } 2-WEGE SCHALTER, HANDBET驀TIGUNG 2 WAY SWITCH DPDT, MANUAL OPERATION BN 75 95 24 Frequenzbereich VSWR Frequency range 0 < f < 1 GHz < 1.04 1 < f < 2 GHz < 1.08 2 < f < 3 GHz < 1.08 3 < f < 4 GHz < 1.12 4 < f < 5 GHz < 1.12 Ubersprechdmpfung Durchgangsdmpfung...

Open the catalog to page 9

Conditions gnrales de vente tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:5.00pt "Arial", sans-serif; } .font1 { font:6.00pt "Arial", sans-serif; } .font2 { font:7.00pt "Arial", sans-serif; } .font3 { font:8.00pt "Arial", sans-serif; } .font4 { font:11.00pt "Arial", sans-serif; } .font5 { font:54.00pt "Arial", sans-serif; } .font6 { font:8.00pt "Arial Black", sans-serif; } .font7 { font:10.00pt "Arial Black", sans-serif; } 2 WEGE SCHALTER, IMPULSDREHMAGNETANTRIEB, BISTABIL 2 WAY SWITCH DPDT, SOLENOID DRIVE, LATCHING BN 75 40 30 0 Frequenzbereich VSWR Ubersprechd驠mpfung Durchgangsdmpfung...

Open the catalog to page 10

Conditions gnrales de vente tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:4.60pt "Arial", sans-serif; } .font1 { font:5.00pt "Arial", sans-serif; } .font2 { font:6.00pt "Arial", sans-serif; } .font3 { font:7.00pt "Arial", sans-serif; } .font4 { font:8.00pt "Arial", sans-serif; } .font5 { font:9.00pt "Arial", sans-serif; } .font6 { font:11.00pt "Arial", sans-serif; } .font7 { font:29.00pt "Arial", sans-serif; } .font8 { font:8.00pt "Arial Black", sans-serif; } .font9 { font:10.00pt "Arial Black", sans-serif; } .font10 { font:4.00pt "Courier New", monospace; } .font11 { font:4.00pt...

Open the catalog to page 11

Conditions gnrales de vente tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:3.75pt "Arial", sans-serif; } .font1 { font:5.00pt "Arial", sans-serif; } .font2 { font:6.00pt "Arial", sans-serif; } .font3 { font:8.00pt "Arial", sans-serif; } .font4 { font:9.00pt "Arial", sans-serif; } .font5 { font:11.00pt "Arial", sans-serif; } .font6 { font:8.00pt "Arial Black", sans-serif; } .font7 { font:10.00pt "Arial Black", sans-serif; } .font8 { font:8.00pt "Franklin Gothic Medium", sans-serif; } .font9 { font:9.00pt "Georgia", serif; } 2 WEGE SCHALTER, IMPULSDREHMAGNETANTRIEB, BISTABIL 2...

Open the catalog to page 12
