AisaFENIX Data Sheet

Product catalog summary

Introduction
The AISAFENIX system is designed for demanding geological, law enforcement, and environmental applications. Specifications are subject to change without notice, and any errors or omissions are unintentional.

Camera Specifications

Spectrograph: High efficiency transmissive imaging spectrograph.
Spectral Range: VNIR: 380 - 970 nm, SWIR: 970 - 2,500 nm.
Spectral Resolution: VNIR: 3.5 nm (mean), SWIR: 10 nm.
F/#: F/2.4.
Smile / Keystone: Less than 0.2 pixels.
Polarization Sensitivity: Throughput is practically independent of polarization.
Signal-to-Noise Ratio (Peak): VNIR: 600 - 1,000:1, SWIR: 1,050:1.
Spatial Resolution: 384 pixels.
Frame Rate: Up to 100 Hz.
Integration Time: Adjustable within frame period.
Field of View (FOV): 32.3°.
Instantaneous Field of View (IFOV): 0.084°.
Swath Width: 0.58 x altitude.
Altitude for 1m Pixel Size: 660 m.
Electro Mechanical Shutter: Yes.
Detector: VNIR: CMOS, SWIR: Stirling cooled MCT.
Spectral Binning Options: VNIR: 2x, 4x, 8x; SWIR: -.
Number of Spectral Bands: VNIR: 348, 174, 87; SWIR: 274.
Spectral Sampling/Band: VNIR: 1.7 nm, 3.4 nm, 6.8 nm; SWIR: 5.7 nm.
Data Interface: VNIR: CameraLink 12-bit, SWIR: CameraLink 16-bit.
Typical Power Consumption: 150 W.
Maximum Power Consumption: 500 W.

Environmental Characteristics

Storage Temperature: -20 to +50 ºC.
Operating Temperature: +5 to +40 ºC, non-condensing.

Graphical Data

Swath Width vs Altitude: Demonstrates the relationship between swath width and altitude, with a FOV of 32 degrees.
Ground Pixel vs Altitude: Shows how ground pixel size changes with altitude, maintaining a FOV of 32 degrees.
Image Rate for Square Ground Pixel: Illustrates the image rate per second at an aircraft speed of 60 m/s (120 knots) for varying ground pixel sizes.

Catalog excerpts

FOR THE MOST DEMANDING GEOLOGICAL, LAW ENFORCEMENT AND ENVIRONMENTAL APPLICATIONS

Open the catalog to page 1

AISAFENIX Swath width vs altitude from the ground 5000 Camera specifications Spectrograph High efficiency transmissive imaging spectrograph Spectral range Spectral resolution (Mean)* Smile / Keystone Polarization sensitivity Throughput practically independent of polarization Signal-to-noise ratio (peak) Ground pixel vs. altitude from the ground Integration time Adjustable within frame period Swath width Altitude for 1m pixel size Electro mechanical shutter Number of spectral bands Spectral sampling / band Image rate for square ground pixel @ aircraft speed 60 m/s (120 knots) Spectral binning...

Open the catalog to page 2
