STRIP STRAIGHTENERS STRIP STRAIGHTENERS SOPREM strip straighteners ensure the quality of your products. They assure that the distorted steel strips are a thing of the past and that you get top products for optimum further processing regardless of the source material. How do deviations in flatness occur? Deviations in flatness can occur in machining processes such as punching, laser or plasma cutting, hardening, nibbling, shearing and coating. They are caused by a change in the inner material tension of the strip material during processing. Your specifications are our benchmark We manufacture...

l>01| Strip feeding installation for fineblanking press Decoiler, loading capacity 3000 kg, with hydraulic auxiliary motor, hydraulic pressing arm and driven roll, pneumatic disc brake, two bottom hydraulic coil supporting rolls, conical rolls for lateral strip guidance. Strip straightener with 11 straightening rolls for strip thickness range 3 to 14 mm, maximum passage width 300 mm. Hydraulic ventilation of the upper pinch rolls, motorised adjustment of the upper straightening rolls, hydraulic grabber arm for inserting of strip beginning. Modern control by means of a touch panel. ^o^Strip Straightener...

STRIP STRAIGHTENERS > 03 Rocker The rocker is the tool of the straightener, its precision and rigidity are decisive for the quality and result of the straightening process. Combined machines SOPREM‘S compact, combination equipment is the ideal solution where space in your production hall is confirmed. We combine the decoiler with the straightener in a strip feeding system. > 04 Longitudinal inclination of the rocker Most material bending will occur at the straightener inlet where the material becomes ductile. Longitudinal inclination of the rocker is achieved by using a hand operated or motor...

Precision strip Straightener with 19 straightening rolls For straightening of strips with material thicknesses of 0,2 to 0,7 mm, the maximum passage width is 450 mm and the roll diameter 16 mm. The upper rocker can be inclined in longitudinal and transversal direction. Equipped with ultrasonic loop control. Facts, area of application • Fine straightening of strips with low material thickness but big width • Apparatus construction, air conditioning technology In detail Every straightening roll is driven by a gear. Roll axis spacings for optimal straightening geometry. Material tensions are considerably...

STRIP STRAIGHTENERS Strip Straightener with 19 straightening rolls rTol Rocker The rocker is the tool of the straightener, its precision and rigidity are decisive for the quality and result of the straightening process. |>11] Transversal inclination of the rocker Wavy edges and slight sword shape of the strips can be eliminated by transversal inclination of the upper rocker. |>^2I Longitudinal inclination of the rocker The greatest alternate bending will occur at the straightener inlet where the material becomes ductile. Longitudinal inclination of the rocker is achieved by using a hand operated...

STRIP STRAIGHTENERS > 16 Opening of upper rocker Hinged upper part of the straightener for better access for straightening rolls cleaning. > 18 Medium straightening of thin strips Straightener with 17 hardened, ground and hard chrome plated straightening and pinch rolls. Multiple backup rolls for all straightening rolls. Straightening depth display by two analogue dials. Strip thickness range 0,05 - 0,6 mm, maximum passage width 60 mm. > 17 Hard chrome plated rolls Hard chrome plated straightening and pinch rolls, 68 – 72 HRC with superfinish to increase the wear resistance and avoid material...

Strip Straightener with 7 straightening rolls Strip straightener with 7 straightening rolls > 20 Combined strip straightening-decoiling line This machine enables straightening of strips with material thicknesses of 0,4 to 7,0 mm, the maximum passage width is 300 mm and the roll diameter 80 mm. The straightening depth setting of the three upper straightening rolls is made individually with an Allen key. Elements at the straightener inlet: Hydraulic insertion aid, symmetrically adjustable lateral strip guidance by means of crank handle. Elements at the straightener outlet: Hydraulic strip transfer...

STRIP STRAIGHTENERS > 22 Conveying table Hydraulically operated transfer table with hinged steel bridge parts and integrated roller basket, the geometry of which adapts automatically to the position of the transfer table. Options > 21 Strip insertion aid Hydraulic strip insertion aid equipped with extendible pick-up pin, pivotable table and upper pressing roll for introducing the strip beginning into the straightener. > 23 Lateral strip guidance Unit mounted at the straightener inlet consisting of two vertical, hardened and grounded guide rolls, symmetrically adjustable by hand wheel. Mechanical...

Precision straightening Rough straightening

PART LEVELLERS PART LEVELLERS SOPREM part levellers ensure the quality of your products. They assure that the distorted metal parts are a thing of the past and that you get top products for optimum further processing, regardless of the source material. How do deviations in flatness occur? Deviations in flatness can occur in machining processes such as punching, laser or plasma cutting, hardening, nibbling, shearing and coating. They are caused by a change in the inner material tension of the part during processing. Your specifications are our benchmark We manufacture the machine to suit your...

> 01 SCHUBERT design SOPREM builds levellers in SCHUBERT design and equips then with state-of-the-art drive and control technology. We offer retrofits for older lines and keep a wide range of spare parts. In detail A wide part thickness range can be covered. Every straightening roll is driven by a cardan shaft. This reduces the roll axis spacings to a minimum and allows even small parts to be straightened. Material inner tensions are considerably reduced and evenly distributed, a prerequisite for low-tension further processing. > 02 Part Leveller with 19 straightening rolls Machine with a roll...
