Content 02 | 03 Consultancy, design, production, after-sales service 04 | 05 Special Plants 06 | 07 Strip decoiling and strip coiling 08 | 09 Strip straightening and part levelling 10 | 11 Strip decoiling, straightening and feeding 12 | 13 Strip welding and strip accumulating 14 | 15 Wire decoiling, straightening and cut to length SOPREM is your partner for tailor-made solutions in mechanical engineering. We offer our customers consultation and planning as well as production and after-sales service.We have over 45 years experience in different industrial sectors providing experience for the benefi...

> 01 > 02 > 03 > 04 > 01 Design and Development > 02 Production Planning and preparation of the mechanical and electrical design is undertaken by a team of highly experienced designers. They design complex machines, strip feeding lines and control units; our production capability is supported through partnerships with specially selected engineering companies. Our CNC-controlled production machinery can produce parts economically within the required tolerances. Around 50 per cent of our products are produced at SOPREM, so that we achieve high fl exibility throughout the planning and management...

> 05 > 06 > 05 Transverse strip cutting lines > 06 Strip welding lines The transverse strip cutting lines for the production of boards made of high- strength steel include an integrated precision straightening unit with lateral positioning of the strip. This enables continuous transverse cutting and ensures length precision and fl atness of the parts. Strips are economically joined with our strip welding machines. They reduce changeover times and avoid dangerous punching processes during coil ex- change. > 07 Part levellers We build part levellers and lines for economic straightening of uneven...

> 01 The decoilers for vertical decoiling are often equipped with a precision coil mandrel with central adjustable strip tension, recommended when using thin and narrow strips to protect the strip edges.SOPREMs smallest decoilers are suitable for a max. coil weight of 30 kg and 100 kg respectively. Several thousands of these are used all over the world, especially in the watch- making and small electronic compon- ents industries. We also offer a wide range of options, e.g. different loop controls, paper decoiling and rewind- ing as well as double decoilers. >

> 03> 04 > 04 Cradle decoiler for a max. coil weight of 200 or 500 kg, including two shafts, which can be equipped with abrasion resistant rubber. The spool is placed on the powered shafts. A strip straightener can be added as an option. > 05 Double decoiler with a max. load weight of 200, 500 and 1,250 kg, enabling coil handling to be significantly reduced. Small decoilers for 30 kg and 100 kg can also be supplied as double decoilers. Larger decoilers can be supplied upon request. > 06 Triple pallet decoiler with fine adjustable strip pull is suitable for decoiling thin, narrow strips. Our product...

> 01> 02 If there is insuffi cient space in your workshop, you will fi nd the solution in the compact design of SOPREM equipment. We combine the decoiler with the straightener to a strip feeding system. Optionally the straightener can be equipped with an integrated feed. This compact design allows you to easily incorporate the equipment in a cut-to-length line or in a strip feed- ing system. The loop between the straighter and the press is not neces- sary in this system. The compact designs of SOPREM equipment are becoming more and more popular, as they allow optimum use of production space....

Roller feeder type WV > > 03> 04 > 04 Decoiling, straightening and feeding unit equipped with decoiler, loop cabinet, strip gripper and straightener with integrated feeder. This com- pact unit enables strip feeding of a max. width of 300 mm and a thickness ranging from 1,5 8 mm. After the straightener, the strip is fed directly into the press. The strip loop can be omitted. > 05 > 06 Decoiling-straightening machine equipped with a decoiler, inserting table, straightener and conveyor table. This compact unit enables feeding of strips of a max. width of 300 mm and a thickness of 5 mm. A loop is...

> 01 Strip feeding lines and strip accumu-lators are necessary because of the high production requirements in com-pound pipe production. Non-stop pro- duction places the highest demands on the reliability of the strip accumulator and the welding unit. If the fi rst strip end welding fails, the strip accumulator needs to have suffi cient material for the second weld. SOPREM builds this equipment to highest quality standards meeting all the requirements of a 24 / 7 non-stop production. >

> 02> 03 Strip end welding machine type SGA > 03 Strip accumulator unit for cooling tube production, equipped with a pallet decoiler, a strip end weld- ing machine, a parallel accumulator and a feeder. The unit is very well suited for a 24 / 7 non-stop production. > 02 Strip accumulator unit for compound pipe pro- duction, equipped with two connected decoilers, a strip end welding machine, a linear accumulator and a feeder. The unit is very well suited for a 24 / 7 non-stop production. > 01 Strip end welding machine with automatic strip cutting, strip positioning and welding. The equip- ments...

> 01 Modern production companies au-tomate wire feedings with decoilers, straightening-feeding systems and cut-to-length lines. While decoiling larger diameter wires used in the production of connecting elements, the wire spring back must be compensated for. For this, we re- commend the decoiler with loop arm and spring compensation system. Wires with a very thin diameter, used in the production of small draft or compression springs, loop controls with very low wire loads are neces- sary. SOPREM can supply wire decoilers equipment for both requirement pro- ducing improved productivity. >

> 02 > 04 > 03 Wire decoiler type DH > 04 > 05 Wire rewinder with electronically controlled lateral wire positioning. The max. load is 200 or 500 kg. This equipment is suitable to rewind wires with medium diameters and for high lateral wire posi- tioning requirements. The rewinder is also suitable for rewinding strips. Wire rewinder with mechanically controlled lateral wire positioning. The max. load is 30 or 100 kg. This equipment is suitable for the rewinding of small diameter wires and for low lateral wire posi- tioning requirements. The rewinder is also suitable for rewinding strips. > >...
