MXQ series
198Pages

Catalog excerpts

reduction (Current model: 30 mm ) ∗1 Product weight reduction (Current model: 380 g ) ∗1 Allowable kinetic energy Reduced in height and weight with thinner table improvement (Current model: 0.055 J ) ∗1 ∗1 Comparison between the double-ported type and the current MXQ12-30 (without adjuster) ¡Thin table made of special stainless steel ¡Durable material with the same strength as the current model 2 combinations of guide and cylinder bore size available Page Double-ported type 11 Increases flexibility of wiring and piping with piping ports and auto switch mounting grooves on both sides Bore size Bore size Single side-ported type 67 Better auto switch visibility. Indicator LED can be checked from one side when used with a short stroke. ¡The centralized adjuster of the functional option is available as standard. ¡Made to order options have been added. • Dual stroke specification • Side adjuster specification • Combined use of shock absorber + metal stopper, etc. Low thrust with high rigidity type Page 53 Combination with a cylinder of one bore size smaller increases rigidity according to thrust. The height can be reduced as well. Height interchangeable type Page 83 Height interchangeable with the current MXQ series

Open the catalog to page 1

Air Slide Table MXQ Series 2 combinations of guide and cylinder bore size available Double-ported type MXQA  Height reduced by Improved visibility Two auto switch mounting grooves Guide Size and Cylinder Bore Size Combination Chart Guide size Small guide  A piping port and auto switch mounting groove are provided on both sides. Maximum load mass Bore size When the height needs to be the same as the current model, choose the MXQ, height interchangeable type. Purpose of usage q Guide rigidity and a large table surface are necessary but thrust is not needed. Application • Horizontal...

Open the catalog to page 2

Air Slide Table MXQ Series Select the best actuator with guide according to the application. Low thrust with high rigidity type MXQB Single side-ported type Page Height interchangeable type Page 67 83 MXQC MXQ Guide rigidity according to thrust improved  Guide can be downsized when load is light! • Reduced in height • Reduced in air consumption • Lightweight Bore size  Compact body with good switch visibility Applicable to ø8 and ø12 only  Compact design, Two auto switch mounting grooves on one side Bore size  Same height as the current model  Visibility of auto switches improved ...

Open the catalog to page 3

Air Slide Table MXQ Series Stroke adjuster (Option) The stroke adjuster is positioned in the center. Play at the stroke end is reduced. Stroke adjuster Allowable kinetic energy improved Allowable kinetic energy improved by reducing the weight of movable parts Speed - Load weight 2 Allowable kinetic energy improved 1.5 Current model 1 Table configuration for better function and easier maintenance Dowel pin holes positioned in the center Round shape Dowel pin holes positioned in the center 2-color indicator solid state auto switch capable (D-M9) Dowel pin holes interchangeable with the...

Open the catalog to page 4

Air Slide Table MXQ Series The mounting dimensions are equivalent to the current MXQ series.  Workpiece mounting The mounting screw O.D. and thread positions have interchangeability with the current MXQ series. Thread spacing Thread spacing ∗ Threads at the end plate have no interchangeability. Workpiece mounting hole  Body mounting Two methods of mounting are available. Lateral mounting (Body tapped) Body mounting threads and spacing have interchangeability with the current MXQ series. Lateral mounting (Through hole) Various stroke adjusters (Option)  Shock Absorber  Metal Stopper with...

Open the catalog to page 5

Air Slide Table MXQ Series It is possible to combine an extension stroke end adjuster and a retraction stroke end adjuster. Extension stroke end adjuster Example Extension stroke end adjuster Metal stopper with bumper Retraction stroke end adjuster Retraction stroke end adjuster Rubber stopper Shorter total length type table is now available. Total length shortened by 8.5 mm Shorter total length 70 mm (Basic type 78.5 mm) (For MXQ8A-20) ∗ Extension stroke end adjusters cannot be mounted. Compact auto switch is now available. • Reed auto switch: D-A9, D-A9V • Solid state auto switch:...

Open the catalog to page 6

Air Slide Table MXQ Series Functional Options With buffer mechanism ¡Protects workpieces and tools by eliminating impact at the extension stroke end ¡Buffer unit is auto switch capable. Application Example Buffer mechanism operating condition Buffer stroke Normally OFF Auto switch ∗ ON is buffer in operation In workpiece insertion processes when there is a problem such as faulty positioning, the buffer mechanism absorbs the shock from the workpiece impact to prevent damage. Buffer mechanism Magnet Normally ON Auto switch ∗ OFF is buffer in operation Normal condition ∗ By changing the...

Open the catalog to page 7

Air Slide Table MXQ Series Axial piping With buffer, end lock With buffer, axial piping Centralized adjuster Buffer, Centralized adjuster (Symmetric type) With buffer Buffer, Centralized adjuster Shorter total length type Centralized adjuster (Symmetric type) Symmetric type Double-ported type MXQA Functional option (pages 5, 6, 15) Cylinder with stable lubrication function (Lube-retainer) Body option Standard type Bore size Low thrust with high rigidity type MXQB Single side-ported type MXQC Height interchangeable type MXQ

Open the catalog to page 8

Metal stopper with bumper Shock absorber Rubber stopper Metal stopper Extension stroke end/ Retraction stroke end mounting Solid state/Reed PTFE grease (-X7) Grease for food processing equipment (-X9) Long adjustment bolt (10 mm longer adjustment range) (-X11) Long adjustment bolt (20 mm longer adjustment range) (-X12) Long adjustment nut and bolt (-X28) Without built-in auto switch magnet (-X33) Fluororubber seal (-X39) Anti-corrosive guide unit (-X42) EPDM seal (-X45) Low-speed specification (15 to 50 mm/s) (-X580) End plate compatible with the current MXQ series (-X2100) Heat-resistant...
