Centrifugal Separator Selection ManualSLon MagneticSeparatorCo., Ltd. Address: Shahe Industrial Park, Ganzhou, Jiangxi Province, China p.c : 341000 Tel : +86-797-818 6449 Fax : +86-797-730 7127 Website : www.slonmagnetics.com E-mail: [email protected] [email protected]

Centrifugal Separator Selection Manual SLon centrifuge separator utilizes different density between the minerals to separate them. It depends on centrifugal force to strength the flow of membrane for separation which greatly improves the processing capacity of the equipment and enables SLon centrifuge separator to collect finer particles. SLon centrifuge separator is efficient in separation, wear-resistant, easy to be operated and maintained. It’s suitable for separating and collecting fine ferrous minerals, non-ferrous and precious and rare metal minerals, such as magnetite, hematite, specularite,...

SI!©!! SLon Magnetic Separator Co., Ltd Structure and Working Principle The parameters of SL Centrifugal Separator O The structure of SL centrifugal separator is shown as below. It consists of centrifugal drum, frame, feeding device, concentrate flushing pipe, rinse pipe, discharge box and so on. Working Principle: The slurry is fed to the inner surface of the drum by the feeding device and rotates with the drum driven by the centrifugal drum. The inner surface has a slope along the axial direction, and the slurry also flows along the axial direction at a certain velocity. In this way, the slurry...

SI!©!! SLon Magnetic Separator Co., Ltd. SY Rotary Screen Structure and Working Principle Low fault rates, simple operation and maintenance. It consists of stainless steel screen, slag board, flushing water pipe, slag box, discharge pipe, transmission mechanism and ore receiving hopper. The cylinder rotates under the drive of the transmission mechanism, and the slurry is fed into the circumference of the screen from the lower left part of the slurry inlet and slag discharge pipe. Fine-grained minerals and water pass through the screen and fall into the ore receiving hopper, flowing along the...

The parameters of SY Rotary Screen O Parameters Eight side tank and three-layer specially designed blades provide good scrubbing effect. It could achieve high concentration, high speed, high efficiency stirring scrub and strength. The blade, shaft and tank are made of wear-resistant rubber or polyurethane. It’s suitable for silica sand, quartz sand or other minerals that need to remove oxide layer and impurities on the surface.

Centrifugal Separator Selection Manual Structure and Working Principle The Application of SL Centrifugal Separator It consists of trough, transmission shaft, gear box, motor, base and etc. High-concentration silica sand and quartz sand slurry enters the scrubber, and through the forced stirring of the blades, the slurry makes a circular and up-and-down rolling motion in the mixer, which collides and rubs against the inner wall of the tank, so that the impurities and oxide layers adhering to the surface of the material fall off. The edges and corners of the material are smooth, achieving a pure...
