User Simplicity • Industrial Power • Modular Design

Industrial Robots Great speeds (13+ single picks/min), reach, payloads (up to 150 kg) and robustness. Siviko RoboMOD Palletizer Palletizing software Create your own palletizing layouts without programming. Modular Design Easy assembly and commissionng. Many options. Four sizez - S, M, L and XL. Pneumatic and vacuum grippers designed by Siviko for all types of objects The system's true intelligence lies in its software, powered by the Ignition platform and the proprietary Siviko Easy Pallet software, which allows operators to create new palletizing layouts without programming skills. By choosing...

screenshot of the pallet bulling screen screenshot of the main screen Current Palletizing Layout A Layout name Description Current layout L Current layout R Settings Current Alarms Alarm History Package positions Q Alternating Odd and Even layers Change order Package move From robot oooolo oooooll Door closed Repeat last item Palletizing data Production speed Average travel time Total packs per hour Current pack Current layer Pack number Daily counter Total counter Pack Stopper R 2 Down ooooo oooooll Parameters change Door closed Palletizing data Production speed Average travel time Current pack...

RoboMOD size M RoboMOD Palletizer S is our smallest modular and industrial robot palletizer model. It is the most compact model, with a smaller payload, but in terms of cycle times, it is as good as the bigger models. It is the perfect solution when working with lighter boxes or other objects that can be picked up with a vacuum. There are many available modules and options. RoboMOD Palletizer M has a bigger payload, which allows the use of many different types of grippers. With a mechanical gripper it can pick up many objects up to 20 kg that a vacuum gripper cannot, such as unstable or open-top...

RoboMOD size XL RoboMOD Palletizer L is a heavy-duty model. Powered by the new FANUC M-710iD/70 - with a 70 kg payload, 2,104 mm reach, and rapid axis speeds - it far outperforms cobots solution. Engineered to handle up to 40 kg of useful load, it effortlessly lifts bags, boxes, or buckets and supports multi-object custom grippers to multiply your throughput. There are many available modules and options. RoboMOD Palletizer XL is our biggest model and perfect solution for payloads of more than 40 kg. It can lift heavy and bulky items such as 50 kg bags, extra heavy or large boxes, bulding materials,...

Modules and options Second pallet place The second pallet place module extends the autonomy time of your RoboMOD Palletizer. Once the first pallet position is full, the robot continues palletizing on the second one. Since there are no safety light barriers inside the cell, once a worker opens a door, the entire palletizing cell stops operating. This option improves downtime for not changing the pallet on time. Adds a second infeed conveyor in the back of the cell. This allows the RoboMOD palletizer to serve two production lines simultaneously. With the second pallet position, the cell can palletize...

Automatic pallet retrieval double This option adds automated double retrieval of a pallet with two positions. One is active, and the other is a buffer from which the pallet has to be picked up. There is a light barrier on the conveyor exit. Automatically transfers full pallets to an external conveyor or stretch wrapper. Works best with an automated empty pallet pick and place or pallet dispenser module. This option is only possible with the Siviko RoboMOD L and XL palletizer. A buffer for 13 empty pallets is added as a module. The gripper has added forks and a sensor that allow the robot to pick...

Palletizing grippers TTTTTTTTTTTTTTTTTTTTTTTrt^ffn Vacuum grippers Vacuum grippers can handle a lot of products. The limitation comes if the top of the product is open or too flexible. Size and payload can be customized Custom Siviko Vacuum grippers Any other brand can be integrated Palletizing of bags, sacks, and pauches Pneumatic top press for better grip Payload max 50 kg, customizable Mechanical gripper with pneumatic actuators Maximum bag dimension 800 x 550 x 150 mm (L x W x H), customizable Minimum bag dimension 350 x 250 x 80 mm (L x W x H), customizable

• First, select size - S, M, L or XL. • Second, select modules. • Thrid, select gripper. • Easy transportation due to compact size. • Easy assembly and commissioning. • FANUC industrial robots • Great speeds, reach, and payloads. • Industrial robots are built to last. • Cheaper than cobots for the same parameters. • Various pneumatic and vacuum • Palletize almost anything-boxes, bags, trays, buckets, • Pick many different SKUs with the same gripper. • Slip sheet and pallet pick-up options. Benefits of using the RoboMOD Investing in the Siviko RoboMOD Palletizer has many advantages from anoperations...

38 Treti Mart bul. Ruse 7000 Bulgaria 56 Kimchovets stl. Sofia 1415 Bulgaria Contact us and we can explore the best option for your specific case.
