STI-638
3Pages

Catalog excerpts

Ratemeters / Tachometers pulse rate / period meter in wall mounted IP 67 housing rotational / linear speed control revolution / movement period control binary outputs REL / OC analogue output: active or passive, power supply output: 24V DC RS-485 / Modbus RTU "over" signalling when the measuring range is exceeded ultra bright red, green and blue display free configuration software S-Config The STI-638 tachometers encased in a tight, wall-mounted housing (IP 67) with 6-digit, large LED display are designed to control rotational or linear speed of moving objects. The device is also able to measure frequency. As an additional advantage the device can convert the rotational / linear speed into inverse values, and to display the single revolution period or process duration. The 24V DC / 100 mA output is designed to supply measuring transducers, and the RS-485 port enables data transmission in production process monitoring systems.The REL / OC control outputs can be programmed depending on the instantaneous value of rotational speed. Additionally the counter may be equipped with analogue outputs, according to the customer selection: active current output, passive isolated current output or active voltage output. The counter may be configured with no need to open the case, by using the remote controller, the local keyboard or with free S-Config software via the RS-485 communication port. TECHNICAL DATA 19V ÷ 50V DC; 16V ÷ 35V AC or 85 ÷ 260V AC/DC, all separated for 19V ÷ 50V DC: max. 8,7 W; for 16V ÷ 35V AC max. 13 VA; for 85 ÷ 260V AC/DC max. 29 VA LED, 6 x 38 mm high, red, green or blue (according to order), ultra bright pulse, fully isolated, with debouncing filter and pulse width control, max. input frequency 50.0 kHz Input levels low level: 0 V ÷ 1 V; high level: 10 V ÷ 30 V (about 12 mA @ 24V) Input frequency range Displayed values range Rotational speed precision selected in the range 0 ÷ 0.00000 of unit Rotational speed unit revolutions per second (rps), per minute (rpm), per hour (rph) Pulse waiting time settable from 0.1 to 39.9 seconds ± 0.02% ± one digit (full temperature range) Outputs (option) Analogue output (available with 2 x REL or OC, see ordering) active current: operating range 0/4-20 mA (max. 0-24 mA), load resistance 700 Ω max., resolution 13 bit passive current: isolated, operating range 4-20 mA (max. 2,8-24 mA), load resistance 600 Ω@24VDC, resolution 13 bit active voltage: operating range 0/1-5V, 0/2-10V (max. 0-11V), load resistance min. 2000 Ω, resolution 13 bit Power supply output Communication interface RS-485, 8N1 and 8N2, 1200 bit/s ÷ 115200 bit/s, Modbus RTU (not galvanically isolated) Operating temperature Storage temperature -10°C ÷ +70°C (standard), -20°C ÷ +70°C (depending on option) Protection class wall mounting; material: ABS + fibreglass Dimensions (WxHxD) SIMEX Ltd., Wielopole 11, 80-556 Gdańsk, Poland, tel. (+48) 58 762-07-77, fax 58 762-07-70, www.simex.pl Power supply

Open the catalog to page 1

Ratemeters / Tachometers LED DISPLAY VERSIONS Ultra bright display (according to order): - red, - green, - blue. DIMENSIONS Side view Distances between mounting holes Case dimensions pulse input version with 2 x OC 85-260V AC/DC 50/60Hz 11VA DATA+ DATAGND - + ACTIVE current output pulse input version with 2 x REL, 1 x OC and 1 x AO 0/4-20 mA, active SIMEX Ltd., Wielopole 11, 80-556 Gdańsk, Poland, tel. (+48) 58 762-07-77, fax 58 762-07-70, www.simex.pl

Open the catalog to page 2

Ratemeters / Tachometers ORDERING STI-638-X-40-XXXX0-10-X-XX1 display: R : red, ultra bright G : green, ultra bright B : blue, ultra bright options: 00 : no options 08 : operating temp. -20°C ÷ +50°C power supply: type of outputs: 3 : 24V AC/DC 1100 : 2 x REL 4 : 85V - 260V AC/DC 1200 : 1 x REL + 1 x OC 2200 : 2 x OC 1111 : 4 x REL 2222 : 4 x OC 1125 : 2 x REL + 1 x OC + 1 x AO (4-20 mA, passive, isolated) 112D : 2 x REL + 1 x OC + 1 x AO (0/4-20 mA, active, non-isolated) 112E : 2 x REL + 1 x OC + 1 x AO (0/1-5V, 0/2-10V, active, non-isolated) REMOTE CONTROLLER SIR-15 InfraRed remote...
