blind nuts

Product catalog summary

Overview: This document outlines the technical specifications and usage guidelines for SERBLOC mounting tools and nuts, designed for both small and large series applications. It covers manual and semi-automatic tools, technical characteristics, and various applications.

Specifications:

Manual Tools: Hand clamps for mounting SERBLOC nuts ranging from M3 to M14, featuring rapid screwing and unscrewing devices.
Semi-Automatic Tools: PNEUMO-OIL devices for large series, capable of mounting nuts from M3 to M16, with automatic screwing features.

Technical Characteristics:

Tightening Torque: Provided for both steel and aluminum SERBLOC nuts, with specific values for different nut sizes.
Extraction Loads: Calculated based on support thickness and SERBLOC barrel diameter.
Shearing Resistance: Data obtained from tests on dimensionally stable sections.

Applications:

Suitable for mounting supports on materials such as reinforced polyester, thin plastics, and laminated surfaces.
Used in industries like automotive, marine, and construction for leaktight assemblies and blind mounting in hollow sections.

Product Variants:

Different head types such as flat, countersunk, and hexagonal, available in materials like steel, stainless steel, and aluminum.
Special notes on self-clinching studs, nuts, and blind rivets for specific applications.

Additional Information: Contact details for further inquiries and ISO 9002 certification for quality assurance are provided.

Types and Dimensions: Lists different types of SERBLOC nuts such as hexagonal, flush head, and countersunk head, each with specific dimensions and crimping thickness ranges. Available in both open and closed configurations for different applications.

Installation Procedure: Involves screwing the SERBLOC nut into a tool, inserting it into a pre-drilled hole, and actuating the tool to expand the nut, securing it in place for a strong and reliable fastening.

Advantages: Provides a secure and leakproof fastening solution, with high resistance to screwing torque, suitable for both manual and hydro-pneumatic installation tools.

Quality Assurance: Emphasizes the company's commitment to quality, adapting production to new technologies, and maintaining strict control from manufacturing to distribution.

Catalog excerpts

rapid assembly conical barre By adapting our production to new technologies,we have managed to gain the confidenceof both small entreprisesand major international corporations,in leading economic sectors like the automobileindustry,household appliances,telephone,office automation,computer technology,etc. ADVANTAGES > When setting,the flutes anchor the SERBLOCnut in the support,giving it considerable clamping strength.Torque resistance is higher than that of a class 6.8 steel screw. Support preparation.The cylindrical housing P can be made by punching or drilling.For countersunk heads,provide...
