• Increased Productivity: The Signode PSF significantly boosts productivity by reducing the time needed for strapping large or palletized loads.
• Improved Efficiency: Allows a single operator to easily strap pallets.
• Ease of Use: Designed for simplicity, requiring only a push button to start the strap cycle.
• Operator Friendly: Ergonomically designed for safe and comfortable operation.
• Low Maintenance: Minimal maintenance requirements.

The Signode PSF is a power strap feeder designed for quick and efficient strapping of palletized or large packs. It replaces labor-intensive manual strapping, requiring only one operator and providing a safe, ergonomic workstation. The strapping tool is mounted on an overhead spring pivoting system for ease of use and reduced operator fatigue.

• Steel Strap: Width 12 mm to 19 mm; Gauge 0.4 mm to 0.9 mm. Quality: Apex or Magnus.
• Plastic Strap: Width 11 mm to 16 mm; Gauge 0.5 mm to 0.9 mm. Quality: Dylastic® (polypropylene) or Tenax® (polyester).

• PSF-T: Feeder with fixed bottom strap guide.
• PSF-B-FT: Feeder with moveable bayonet.
• PSF-M-B-FT: Moveable feeder with bayonet.
• Special Dimensions: Available upon request.

1. Strapfeed Around Load: Initiated by a push button, feeding strap around three sides of the load. A flap creates a strap loop in front of the operator, adjustable to operational needs.
2. Securing the Load: The strap is applied around the load, and the ends are inserted into the tool for tensioning and sealing. Unused strap can be returned to the dispenser with a second push button activation.

• Power Requirement: 400 V 3 phases 50 Hz + G
• Compressed Air: Industrial air 6 bars
• Weight: 300 to 500 kg depending on model and dimensions
• Max. Conveyor Height: 2250 mm
• Width: 600 to 1600 mm

Strapping materials, service, and spare parts for the PSF are available globally from Signode distributors and partners.
