OptimScan-5M Plus High-Precision 3D Inspection system

OptimScan-5M Plus is High-Precision 3D Inspection scanner with narrow-band blue light source and upgraded high-resolution industrial lens, it provides better detail performance in scanning and smoother data quality. Three sets of high-resolution industrial lenses are used according to different size object, making it more flexible and adaptable. It is widely applied in reverse engineering, quality inspection and quality control.

Product features High Resolution Three sets of 5 megapixel high resolution cameras and 1080P projection were used to obtain high precision features. HHigh Accuracy Single shot accuracy can reach up to 0.005mm, scanner provides the function of environmental vibration detection and effectively ensure high quality data and precision. Multiple Scan Range The system realizes different scanning range by switching off different lenses to ensure a finer scanning performance. HDR Function The HDR function helps to scan high contrasted objects like black and white objects to get complete data.

One-click Integration Module Function The system integrates the "one-click" automatic markers alignment module and the GREC global deviation control module, which effectively reduces alignment errors and get high-quality data with high precision. Compatible with Mainstream Software Support Multiple data formats Support mainstream reverse design or 3D inspection software

Import Data Support a variety of data model formats, compatible with data captured by various mainstream scanner and CAD digital data of various mainstream design software. T Alignment Compare The RPS reference positioning system and the reference alignment function achieve high-precision automatic alignment. It can effectively ensure the accuracy of deviation analysis. Multiple deviation analysis functions can be used to meet the different needs. T Measurement Evaluation it supports dimensions of AsMeY14.5GD&T tolerance and geometric. The software can also automatically calculate the...

Output Data Format .asc^.stl^.obj^ etc., and compatible with the mainstream 3D software Recommended Graphics card: NVIDIA GTX 1080 or above;Video memory:s4 G; computer configuration Processor:above i7 8700;Memory:s32 GB;Port: USB 3.0 *Also compatible with all major metrology, CAD, and computer graphic software through mesh and point cloud import. OptimScan-5M Plus-EN 20230605-V0.6
