Wireless Marker-Free Tracking System

EinScan Trak Wireless Marker-Free Tracking System One System, Two Work Modes EinScan Trak is the world's first wireless, dual-form, marker-free tracking system. Its Choose the right setup for your applications—detachable, easy to calibrate,and detachable handheld scanner seamlessly transforms into an independent wireless laser ready with one-click startup. Enables seamless switching and flexible scanner, delivering greater flexibility across diverse scanning tasks. The marker-free combination of tracking mode and handheld scanner mode, supporting tracking system captures large surfaces directly...

Inside Tracking System How the Units Collaborate for Efficiency 15m³ Large Volume Wireless Scanning Equipped with Wi-Fi 6 module supports wireless scanning. Connects via an independent LAN and pairs automatically at startup. Enjoy 15m³ ultra large tracking volume, giving you more freedom to move, capture, and create with higher efficiency. *A router is required and included as standard. Hybrid Leapfrog Function for Large Objects Move the tracker with marker-based alignment to extend the scanning range for large objects, only 4 markers needed for per tracking range, Spherical Scanner Tracked by the...

Three Scanning Modes Built for Diverse Needs 7 Parallel Laser Lines For Fine Details Captures lines and sharp edges on automotive components with greater clarity. 19+19 Crossed Laser Lines Laser Line For Deep Holes For challenging deep hole scanning, the single laser line reaches deeper to capture fine details with 1:4 diameter- depth ratio, supporting applications such as vehicle reverse engineering. Acquires high-quality data from large objects quickly, delivers workflow efficiency and scanning flexibility.

All-Scenario Marker-Free 3D Scanning Less Prep. Faster Setup. Higher Productivity. Marker-Free Laser Scanning in Handheld Scanner Mode For feature-rich surfaces, handheld scanner mode delivers a smooth, marker-free scan experience. Marker-Free Tracking System *For high-accuracy requirements, global markers are still recommended. EinScan Trak features built-in retroreflective markers on its spherical scanner module, enabling the wireless tracker to precisely monitor the scanner’s position in real time. This supports a more flexible scanning workflow and stable data capture without relying on object...

Build Complete 3D Models Efficiently Flexible Scan, Smart Merge Tracking Mode Resolution: 2.0mm Handheld Scanner Mode Smart Data Merge Across Modes and Resolutions Merge data captured in tracking mode and handheld scanner mode within one project, with compatibility across different laser modes and resolutions. Reduce redundant data and build more complete 3D models faster. Handheld Scanner Mode Real-Time Adjustment During Scanning During scanning, you can switch between different resolutions in one scan and customize areas that require more details in the local resolution function. It delivers a...

Highly Adaptable, Flexible Wireless Workflow Reliable Outdoor Scanning Performance with Longer Battery Life Ideal for Various Materials Scan black and reflective surfaces(e.g.,car rims) effortlessly without any data loss. Ship Modification Design Multi-Environment Adaptability Reliable scanning outdoor & indoor, supports scanning under strong outdoor light up to 110,000 lux. No Battery Anxiety Up to 5.5 hours of battery life in tracker mode, with hot-swappable batteries for uninterrupted operation. Handheld scanner mode supports up to 3.5 hours of use. Safe to Transport, Easy to Carry High-strength...

Flexible Scanning, Precise Measurement, Streamlined Reverse Engineering Applications • Industry-Specific Customization EXScan Trak+EXModel Series+EXMeasure • Product & Industrial Design EXScan Trak is a scanning software for EinScan Trak Series, designed to support complex 3D data acquisition with a flexible and efficient workflow. Smart Merge of Different Modes and Resolutions Real-Time Laser and Resolution Switching Rapid & Diverse Data Editing Tools Real-Time Feedback Scan Interface EXModel Series is a powerful gateway that simplifies CAD modeling, from 3D scanning to manufacturing. It provides a...

SPECIFICATIONS Work Mode Tracking Mode Handheld Scanner Mode Scan Mode Light Source 19+19 Crossed Laser Lines / 7 Parallel Lines / Single Line Volumetric Accuracy Scanning Speed Working Distance Tracking Volume Alignment Mode Tracking / Global Marker Marker / Global Marker / Feature Camera Resolution Depth Cameras: 2MP * 2; Texture Camera: 5MP * 1 Output Formats Laser Class Operation Conditions CE, FCC, ROHS, WEEE, FDA, SRRC, IP50 Windows 10/11 (64-bit); Graphics Card: NVIDIA GeForce RTX 3060; VRAM: 6 GB or above; RAM: 32 GB or above, DDR5 dual-channel; Interface: USB 3.0; LAN; Processor: 13th...
