深圳市万天源光电有限公司 Shenzhen Wanty Photoelectric Co.,Ltd PRODUCT: Shenzhen Wanty SPECIFICATION Revision: 0.0 T101GBP003-V0 This module uses ROHS material This specification may change without prior notice in order to improve performance or quality. Please contact Wanty department for updated specification and product status before design for this product or r

深圳市万天源光电有限公司 Shenzhen Wanty Photoelectric Co.,Ltd REVISION RECORD REV NO. REV DATE V0

3, ABSOLUTE MAXIMUM RATINGS 9, RELIABILITY TEST CONDITIONS

深圳市万天源光电有限公司 Shenzhen Wanty Photoelectric Co.,Ltd 1、GENERAL INFORMATION Item of general information Module Structure Normally Black Recommended Viewing Direction Gray inversion Direction Module size (W×H×T) Color Pixel Arrangement Module Interface Type HDMI interface Android/Linux (need to be configured first) Power Supply Module Power consumption Color Numbers

深圳市万天源光电有限公司 Shenzhen Wanty Photoelectric Co.,Ltd

深圳市万天源光电有限公司 Shenzhen Wanty Photoelectric Co.,Ltd 5、CTP CHARACTERISTICS Item of CTP Panel Type Glass Cover + Glass Sensor Surface Hardness Interface Type Support Points Sampling Rate Supply voltage

Note 1. Contrast Ratio(CR) is defined mathematically by the following formula. For more information see FIG 2.: Average Surface Luminance with all white pixels (FI. F2, P3, P4, PS, P6.P7, PS, P9) Average Surface Luminance with ail black pixels(Pl,P2, P3, P4, PS, P6,P7, PS, P9) Note 2. Surface luminance is the LCD surface from the surface with all pixels displaying white. For more information see FIG 2. Lv=Average Surface Luminance with all white pixels (P1,P2,P 3,P4, P5,P6,P7,P8,P9) Note 3. The uniformity in surface luminance (5WHITE) is determined by measuring luminance at each test position...

深圳市万天源光电有限公司 Shenzhen Wanty Photoelectric Co.,Ltd Note 4. The response time is defined as the LCD optical switching time interval between “White”state and“Black”state. Rise time (TON ) is the time between photo detector output intensity changed from 90% to 10%. And fall time (TOFF ) is the time between photo detector output intensity changed from 10% to 90%. For more information see FIG 1. Note 5. CIE (x, y) chromaticity ,The x,y value is determined by screen active area position 5. For more information see FIG 2. Note 6. Viewing angle is the angle at which the contrast ratio is greater than...

深圳市万天源光电有限公司 Shenzhen Wanty Photoelectric Co.,Ltd FIG.2. Measuring method for Contrast ratio, surface luminance, Luminance uniformity, CIE (x , y) chromaticity A : H/6 ; B : V/6 ; H,V : Active Area(AA) size Measurement instrument: BM-7; Light spot size=5mm, 350mm distance from the LCD surface to detector lens.

深圳市万天源光电有限公司 Shenzhen Wanty Photoelectric Co.,Ltd Application Note: Please connect the USB first, and then connect the HDMI DCLK frequency@ Frame rate=60Hz Horizontal display area 1 Horizontal Line HSYNC pulse width HSYNC Back Porch(Blanking) HSYNC Front Porch Vertical display area VSYNC period time VSYNC pulse width VSYNC Back Porch(Blanking) VSYNC Front Porch DCLK thd th thpw thb thfp tvd tv tvpw tvb tvfp Unit MHz DCLK DCLK D

深圳市万天源光电有限公司 Shenzhen Wanty Photoelectric Co.,Ltd 9、RELIABILITY TEST CONDITIONS No. Test Item Test Condition High Temperature Storage High Temperature Operating Temperature Cycle Storage A、Inspection after test: Inspection after 2~4 hours storage at room temperature, the sample shall be free from defects:  Air bubble in theLCD;  Sealleak;  Non-display;  Missingsegments;  Glasscrack;  Current is twice higher than initialvalue. B、Remark:  The test samples should be applied to only one testitem.  Sample size for each test item is5~10pcs.  Failure Judgment Criterion: Basic Specification,...

深圳市万天源光电有限公司 Shenzhen Wanty Photoelectric Co.,Ltd 10、INSPECTION CRITERION This specification is made to be used as the standard of acceptance/rejection criteria for TFT-LCD/IPS TFT-LCD module product, and this specification is applicable only in the case that the size of module equal to or exceed than 4.3 inch. 10.1 Sampling plan according to GB/T2828.1-2003/ISO 2859-1：1999 and ANSI/ASQC Z1.4-1993,normal level 2 and based on: Major defect: AQL 0.65 Minor defect: AQL 1.5 10.2 Viewing distance for cosmetic inspection is about 30cm with bare eyes, and under an environment of 20~40W light intensity,...

Zone A: character/Digit area Zone B: viewing area except Zone A (Zone A + Zone B=minimum Viewing area) Zone C: Outside viewing area (invisible area after assembly in customer’s product) Note: As a general rule, visual defects in Zone C are permissible, when it is no trouble for quality and assembly of customer’s product. B » Definition of some visual defect

Inspection standard Bright dot /dark dot defect Zone Note: Minimum distance between defective dots is more than 5mm; Pixel dots’ function is normal, but bright dots caused by foreign material and other reasons are judged by the dot defect of 5.2. 1. Minimum distance between defective dots is more than 5 mm; 2. The quantity of defect is zero in operating condition.

(i) Shifting in position should not exceed the glass outline dimension. (ii) Incomplete covering of the viewing area due to shifting is not allowed. Dirt which can be wiped easily should be acceptable. 5.4.3 Polarizer Dent & Air bubble (i) If the polarizer scratch can be seen after cover assembling or in the operating condition, judge by the linear defect of 5.3. (ii )If the polarizer scratch can be seen only in non-operating condition or some special angle, judge by the following: Using 3% ND filter, it’s NG if it can be seen in R,G,B picture. Visible under: ND3%; D = 0.15mm, Acceptable; 0.15mm<D...

hips on the corner of terminal shall not be allowed to extend into the ITO pad or expose perimeter seal. (iii) Usual surface crack It is only applicable to the upper glass of LCD.
