BFS Series

Product catalog summary

Overview: The BFS Series Multi-Bag Housings are designed for high flow industrial and commercial filter applications. They are constructed from 304L or 316L stainless steel for maximum durability and are available in models ranging from two to six rounds.

Design Features:

Clamp Closure: Available for 2BFS housings, offering quick and easy bag change-outs with a pressure rating of 150 PSI up to 250°F.
Swing Bolt Closure: Available for 2BFS through 6BFS, suitable for larger flow applications with a pressure rating of 150 PSI up to 300°F. Features include heavy-duty swing bolt closure and davit assembly, low profile for easy bag change-outs, and zinc-plated eye nuts and davit handle to prevent galling.
Optional 134 epoxy coating for seawater or corrosive applications.

Applications: Suitable for use in water, chemicals, food & beverage, electronics, oil, inks/paints/coatings, coolants, and pulp & paper industries.

Specifications & Operating Parameters:

Maximum Operating Pressure: 150 psig (10.3 bar) at 250°F for clamp closure and 300°F for swing bolt closure.
Connections: Inlet/Outlet options include 3" RF Flanges for 2BFS, 4" RF Flanges for 3BFS and 4BFS, and 6" RF Flanges for 5BFS and 6BFS. Optional RF Flanges or Sanitary Ferrules are available.
Materials of Construction: Head/Shell made from 304L or 316L stainless steel, with zinc-plated steel eye nuts and davit handle, and 304L stainless steel mounting legs.
Gaskets: Standard Buna N, with optional EPR, Silicone, Teflon Encapsulated Silicone, and Viton.
Baskets: Standard 1/8" perforated stainless steel, with various perforation and mesh sizes available.
Finish: Poly-coat on exterior surfaces, with optional 134 coating or electro-polish.

Customization: Housings can be customized to meet specific requirements. Contact Shelco’s technical support or distributor for more information.

Ordering Guide: Example format: 2BFS-2SB-3-316B, where model, bag size, closure style, flange size, material, and gasket type are specified.

Catalog excerpts

BFS Series Multi-Bag Housings – Two through Six Round • Designed for high flow industrial and commercial filter applications • 304L or 316L Stainless Steel Construction for maximum durability • 2BFS housings with Clamp Closure --Recognized market leader offering exceptional value --Clamp closure offers quick and easy bag change-outs --150 PSI pressure rating up to 250°F --3” Flanged Connections • 2BFS through 6BFS with Swing Bolt Closure --Heavy Duty Swing Bolt Closure and Davit Assembly are ideal for larger flow applications --Low profile for easy bag change-outs --150 PSI pressure rating up to 300°F --Eye nuts and davit handle are zinc plated to prevent gauling • Optional 134 epoxy coating for seawater or corrosive applications Applications Water Food & Beverage Oil Coolants Specifications & Operating Parameters Chemicals Electronics Inks / Paints / Coatings Pulp & Paper Maximum Operating Pressure Materials of Construction 150 psig (10.3 bar) @ 250°F (121°C) – Clamp closure 150 psig (10.3 bar) @ 300°F (149°C) – Swing bolt closure Head / Shell: 304L or 316L Stainless Steel Eye Nuts and Davit Handle: Zinc Plated Steel Mounting Legs: 304L Stainless Steel Connections Inlet /Outlet: - 3" RF Flanges (2BFS) - 4" RF Flanges (3BFS, 4BFS) - 6" RF Flanges (5BFS and 6BFS) Optional: RF Flanges or Sanitary Ferrules Drain Port: - 1/2" FNPT (2BFS-2C) - 3/4" FNPT (2BFS-2SB - 6BFS-2SB) Vent Port: 1/2" FNPT Gauge Ports: 1/4" FNPT Gaskets Buna N Optional: EPR, Silicone, Teflon Encapsulated Silicone, Viton Baskets 1/8" perforated Stainless Steel Optional: Various perforation and mesh sizes Finish Poly-coat on exterior surfaces Optional: 134 coating or electro-polish www.shelco.com

Open the catalog to page 1

MODEL CLOSURE FLOW RATE* GPM (LPM) DIMENSIONS 2BFS-2C Clamp 2BFS-2SB Swing Bolt 3BFS-2SB Swing Bolt 4BFS-2SB Swing Bolt 5BFS-2SB Swing Bolt 6BFS-2SB Swing Bolt 350 (1325) 350 (1325) 525 (1987) 700 (2650) 700 (3312) 1050 (3975) A B C 49 9/16" (125.9) 39 1/8" (99.4) 49 9/16" (125.9) 39 1/8" (99.4) 52 7/8" (134.3) 41 1/16" (104.3) 61 1/4" (155.6) 40 1/2" (102.9) 63 1/2" (161.3) 42" (106.7) 63 1/2" (161.3) 42" (106.7) D 16" (40.6) 16" (40.6) 20" (50.8) 20" (50.8) 24" (61.0) 24" (61.0) 10 1/2" (26.7) 10 1/2" (26.7) 10 3/4" (27.2) 11 1/4" (28.6) 13 3/8" (34.0) 13 3/8" (34.0) E F G 4 1/8" (10.5) 11...

Open the catalog to page 2
