ZCT260K-LBS-BUS-B1-31 Power Line monitoring Inclinometer Sensor - 1

n.Feature Small volume. Light weight. High cost performance,easy installation. With digital filtering function inside. Good shock resistance. I. General discription ZCT260K-LBS-BUS-B1-30 is a 2-axis inclinometer researched and produced by Shanghai Zhichuan Electronic Tech Co.,Ltd. It is high precision,high stability,with measuring range ±60°. RS485 BUS topology output interface. In order to support different environment, this product can accept other kind interface. ^.Application Angle test, level adjustment, zero point adjustment. Safety control, monitor, alarm. Mechanical arm angle test. Original position control, tilt recorder W. Parameter chart: (Unless special mark,all below datas are typical value under room temperature 25°) 1.operating parameter: Shanghai zhichuan Electronic Tech Co.,Ltd -1 - Add: 3/F building, No.1128 Denghui Road, Minhang, Shanghai, China,201109 Tel: 021-64908096 Fax: 021-64906992

Open the catalog to page 1

ZCT260K-LBS-BUS-B1-31 Power Line monitoring Inclinometer Sensor - 2

Note 1: Resolution means the minimum value chang that can be tested within the measure range. Note 2: Accuracy means the difference between the output value and the input true value. Note 3: Response time means the needed time of sensor output reaching 85% of the final output,resulted by the step change of measured tilt. 3. Other parameter: a) Start code: 1 byte, this value was defined be 0xA1; b) Address code: 1 byte, subsidiary address code on RS485 bus line; c) order code: 1 byte, use to distinguish the instruction tape; d) Data field length: 2 byte, high byte in front, low byte in the...

Open the catalog to page 2

ZCT260K-LBS-BUS-B1-31 Power Line monitoring Inclinometer Sensor - 3

anti-byte of the single byte. W. User's instruction: (The red-bold-italic words in the below chart is a example when current device address is 0x01) 1. Setting order code for data storage interval: 0x01 Shanghai zhichuan Electronic Tech Co.,Ltd - 3 - Add: 3/F building, No.1128 Denghui Road, Minhang, Shanghai, China,201109 Tel: 021-64908096 Fax: 021-64906992

Open the catalog to page 3

ZCT260K-LBS-BUS-B1-31 Power Line monitoring Inclinometer Sensor - 4

Shanghai zhichuan Electronic Tech Co.,Ltd - 4 - Add: 3/F building, No.1128 Denghui Road, Minhang, Shanghai, China,201109 Tel: 021-64908096 Fax: 021-64906992

Open the catalog to page 4

ZCT260K-LBS-BUS-B1-31 Power Line monitoring Inclinometer Sensor - 5

Order code explanation: After execute this command,sensor will not accept any Shanghai zhichuan Electronic Tech Co.,Ltd - 5 - Add: 3/F building, No.1128 Denghui Road, Minhang, Shanghai, China,201109 Tel: 021-64908096 Fax: 021-64906992

Open the catalog to page 5

ZCT260K-LBS-BUS-B1-31 Power Line monitoring Inclinometer Sensor - 6

new command, not collect tilt message until power on reset. This order support Single node and broadcast mode. For broadcast mode,sensor no data return; single Node mode, return content as below: 1) Return data 1. When power on,system test angle automatically and log the result into 32 byte cache region in turn according to the spacing interval(default 0.5s) seted by 0x01 order code. Contend in the cache region will not keep when power fail. 2.Please set the device address code correctly before use the sensor. 3.After received a whole set order frame, sensor will handle this frame after 350...

Open the catalog to page 6

ZCT260K-LBS-BUS-B1-31 Power Line monitoring Inclinometer Sensor - 7

Ⅹ. Installation notice When installing the sensor,wrong operation will cause big error of tilt test. Should install "2 surface" and "2 wire" correctly. Take note of the 2 point below: ①:‘2 surface’means mounting surface of sensor and the surface which the sensor will be Mount to. These 2 surface should adjoin closely.（surface be measured should be level as possible)，should not have angle(as angle a in chart A). Correct installation as chart B. ②:‘2 wire’means the shaft line of sensor and shaft line of surface be measured. The 2 shaft line should not have intersection angle（as angle b in...

Open the catalog to page 7
