Metal Sheet Transport+GS1 Code Coding+Inspection+Rejection

Metal Sheet Feeding System-1100 Introduction Feeding roll-table, iron printing feeder, positioning(including double sheet rejection), ink-jet platform, ink-jet coding system (optional, or optional laser coding system), led UV curing (optional, matching according to ink type), image system(optional),rejection/ sampling table, receiving machine, receiving roller deck, etc. The system is widely used in metal plate packaging industries such as iron printing, can making, lid making, etc Variable data coding and printing inspection, adopting modular design, can expand more applications. Main technical...

Machine workflow Feeder roll-table ➢ Electric conveying of material stack and quick centering adjustment ➢ feeding load bearing 2.5t ➢ Professional iron printing feeder ➢ Double sheet detection device Rectification device Cylinder side push gauge and unilateral stop gauge are used for positioning, with high stability and positioning accuracy of ± 0.2mm. ➢ Both sides are adjusted by handwheel, which can quickly adjust the plate specification Vacuum platform ➢ Extended to 3.5m vacuum adsorption platform, more processing modules can be configured (variable data inkjet,Laser coding, photographic...

➢ Proprietary negative pressure design, strong and uniform suction, ensuring the flat operation of the material sheet. Install led UV curing device; ➢ Steel frame structure, wide belt, vacuum adsorption; Install led UV curing unit. ➢ The detection and verification space can be expanded. Double rejection device Equipped with waste kicking device, waste products are automatically removed (photo detection is required) ➢ The other one is used as a sampling platform Receiving Unit ➢ The main drive is driven by Siemens Servo motor ➢ Adsorb and receive the material on the surface to prevent the material...
