iBird Pro information EN
1 / 2Pages

Industry 4.0. WLAN compatible. Via App. Sets blind rivets up to Ø 6.4 mm all materials. Wireless connection: WiFi 2.4/5.0 GHz and Bluetooth Setting force: 20.000 N Weight: 2,2 kg incl. battery (2.0 Ah) Drive: Brushless motor (BLDC) Setting stroke: 25 mm Working Blind rivet nuts from range: Ø 2,4 mm alu up to Ø 6.4 mm all materials (max. mandrel-Ø 4.3 mm) • For smartphone, tablet, PC • Simple connection to the tool with GESIPA® app • Data availability at any time • Andon Ring for visualising riveting processes • Optional connection to three devices at the same time • Premium software: optional (availability of) setting process *Supplied in the L-BOXX including one battery 18 V (2.0 Ah) and a charger 18 V. Further variants available to order! GESIPA Blindniettechnik GmbH Nordendstraße 13-39 64546 Mörfelden-Walldorf

Advantages 1. Andon-Ring On the iBird® Pro there is a signal ring for visualising the riveting processes. the colouring can be set individually via the app. 3. Charger for 18 V batteries Charger with „AIR COOLED“charging technology. Charging time approx. 40 min. with 2.0 Ah and approx. 80 min. with 4.0 Ah. For charging all battery packs of the CAS brands. Premium Software Setzprozess Assistent t Setting process assistan GESIPA Blindniettechni k GmbH Nordendstraße 13-39 64546 Mörfelden-Wa lldorf Deutschland info@gesipa.com - www.gesipa.c om 2. GESIPA® app Thanks to the QR code on the device,...
