SES-STERLING
Code marker cards SES-MARKERS

Code marker cards SES-MARKERS

Product catalog summary

Overview: The document provides technical specifications and details for SES-MARKERS, which are code marker cards used for labeling purposes. These markers are compliant with RoHS standards.

Specifications:

Material: TEV vinyl-covered cotton.
Operating Temperatures: -30 to +105°C (class A), -40 to +150°C (short term).
Application Temperatures: +10 to +40°C.
Adhesive: Special thermal setting adhesive with adherence on steel of 2.5 N/cm.
Tensile Strength at Break: 80 N/cm.
Card Dimensions: 255 x 30 or 40 mm.
Print Height: 1.6 mm.
Strip Details: 150 to 156 strips per card, 3 mm width, 8 and 12 mm length for wires up to Ø 2.5 mm, 0.30 mm thickness.
Standard Colour: White.

Packaging: The markers are packaged in sets of 10 cards with the same legend. Smaller quantities incur an extra charge.

Product Information: The document includes a list of figures and letters available for marking, repeated in series, and the corresponding codes for ordering.

Ordering Information: Custom legends are available upon request with a minimum order of 10 cards. An example order is provided for clarity.

Catalog excerpts

Code marker cards SES-MARKERS E8 TEV vinyle covered cotton 10 cards same legend (for smaller quantities an extra charge will be applied). 150 to 156 strips 3 mm 8 and 12 mm (for wires up to Ø 2,5 mm) 0,30 mm white Strip number: Strip width: Strip length: Strip thickness: Standard colour: Dimension of the card: Print height: -30 to +105°C (class A) -40 to +150°C (short term) Temperatures of application: +10 to +40°C Adhesive: special thermal setting adhesive Adherence on steel: 2,5 N/cm Tensile strength at break: 80 N/cm Operating temperatures: • Product information Figures and letters in series Figures and letters repeated

Open the catalog to page 1

Code marker cards SES-MARKERS Article number code group detail article code colour Example for order: E8 white strip - legend M code legend code legend number strips /card code legend number strips /card code legend number strips /card Other legends upon request with a minimum of order of 10 cards.

Open the catalog to page 2
