SERVOFLEX MiniHD 5200 Product Brochure

SERVOFLEX MiniHD 5200 Product Brochure
1 / 6Pages

Catalog excerpts

SERVOFLEX MiniHD 5200 Product Brochure - 1

Product overview Portable gas analyzer for measurement of common gas mixtures Unrivalled performance Patented Paramagnetic and Infrared technologies for ultra-sensitive monitoring with complete reliability Precision single measurement operation Gas Oxygen Carbon Monoxide Application Process control Carbon Dioxide Combustion Safety Manufactured by Servomex over 70 years’ experience innovating and pioneering gas analysis with thousands of units used in the field every year Flexible SENSING TECHNOLOGY Accurate measurement of O2, CO and CO2 levels with no background interference Internal pump option or AFCD option for pressurised samples I deal for diverse field and light industrial applications including physiology studies, research, combustion optimization, transformer entry, and medical gas verification Easy to use Quick start up and use Intuitive, user-friendly interaction and interface Long life Li-Ion battery power for maximized uptime Ergonomic, small design that is ideal for field use Low cost of ownership Non-depleting technologies maximize availability and reduce maintenance/running costs Simplified calibration and ongoing maintenance Benchmark compliance UL approved and CE marked 100-240V / 43-70Hz AC power supply CE marked and in compliance with EEC, EMC and WEEE Directives Key applications Physiology studies Universities Combustion optimization Medical gas verification For more information visit servomex.com/contact

Open the catalog to page 1

SERVOFLEX MiniHD 5200 Product Brochure - 2

MiniHD 5200 Reliability you can depend on When you work in light industrial and field applications, you need robust, durable and accurate analytical equipment with immunity to background interference. Your job relies on ultra-sensitive measurements and maximized device uptime – especially when conducting field testing. No matter what your monitoring requirement, you’ll want a device that offers long battery runtime, low operational costs, ongoing maintenance costs and ease of use. And we don’t believe you should have to compromize. Product overview Portables Useful links: A no compromise...

Open the catalog to page 2

SERVOFLEX MiniHD 5200 Product Brochure - 3

Technical data sheet Full scale range (FSR) Mnimum output range Cell construction Decimal places ** Allow 1 hour warm up to meet performance specification Performance Accuracy Zero drift per week Tilt effect Pressure effect Directly proportional to ambient barometric pressure Directly proportional to ambient barometric pressure <0.2% reading / mBar change in ambient pressure <0.2% reading / mBar change in ambient pressure Flow variation effect Temperature coefficient zero Temperature coefficient span Operating environment Operating ambient pressure range Operating ambient humidity range...

Open the catalog to page 3

SERVOFLEX MiniHD 5200 Product Brochure - 4

Sample conditions Sample gas Clean, dry, non-flammable and non-toxic gases only Internal pump samples at 0.7 litres (0.3 cubic feet) per minute (nominal). User configurable timer Flow control To maximise measurement stability, unpumped units are supplied with an automatic flow control device (AFCD), over the specified inlet pressure range this controls sample flow rate to approximately 1.5 to 6 litres (0.05 to 0.2 cubic feet) per minute Sample inlet connection 5mm OD stub with “QuickConnect” barb fitting for 6.3mm (1/4”) ID tube or adaptor to 1/8” NPT fitting (option) Sample outlet...

Open the catalog to page 4

SERVOFLEX MiniHD 5200 Product Brochure - 5

Options Description Rechargeable batteries Advanced lithium ion batteries, typical battery life 10 hours at 20˚C (68˚F) Additional barb fittings Additional QuickConnect barb fittings to simplify connection of zero and span gases QuickConnect fitting to allow connection to hard pipes To handle wet or dirty samples Sampling probes Stainless steel probes with holder and connecting tube Recommended spares for two years operation, comprising replacement filters (5) and filter cap ‘O’ ring Carry case Protective canvas case for additional protection Transport case Tough plastic shipping case with...

Open the catalog to page 5

SERVOFLEX MiniHD 5200 Product Brochure - 6

We’re ready to help Whatever your gas analysis requirements, wherever you are. These analyzers are not intended for any form of use on humans and are not medical devices as described in the Medical Devices legislation or regulation. Please note: Whilst every effort has been made to ensure accuracy, no responsibility can be accepted for errors and omissions. Data may change, as well as legislation, and you are strongly advised to obtain copies of the most recently issued regulations, standards and guidelines. This document is not intended to form the basis of a contract. Servomex has a...
