Guide to Bulk Solids Samplers

Product catalog summary

Overview: This document is a comprehensive guide to bulk solids samplers provided by Sentry Equipment Corp. It details various models of samplers designed for different materials and applications, including point samplers, strip samplers, and cross-cut samplers.

Point Samplers: These samplers collect samples at a single point in the product flow. Key models include:

Model B1: Suitable for non-free flowing and free flowing materials, including sanitary products, from gravity chutes and hoppers. Conforms to 3-A Sanitary Standards.
Model R: Designed for pneumatic convey lines, capturing a fixed sample volume with an isolated sample tube and auger.
Model A: For free flowing materials from screw or drag conveyors.
Model RPG: Recommended for avoiding product degradation, suitable for various materials from gravity chutes and conveyors.
Model PR: For free flowing materials in pneumatic convey lines, capturing a fixed sample volume.
Model SAH, SAE, SAK: Compact samplers for gravity chutes, hoppers, and fluid bed dryers, suitable for various installations with different sample cavity volumes.
Model SA: For vertical spouts and chutes, approved by USDA and other organizations, available with air or electric actuation.
Model DS-3: Flexible mounting with a conical sweeping action, collecting up to 262 cc per cycle.

Strip Samplers: These samplers take a sample of a strip across the product flow stream.

Cross Cut Samplers: These samplers take a sample of the entire area of the flow stream. Key models include:

Model D2: For non-free flowing and free flowing materials from gravity chutes and hoppers.
Model RB: Discharges material during the entire sample cycle, suitable for various materials from gravity lines and mixers.
Model RX and MG: For free flowing materials from chutes and product lines, with easy cleaning and inspection features.

Sampling Systems for On-line Analyzers: Sentry designs systems to interface with particle size analyzers and moisture sensors, providing representative samples and precise conditioning.

Controllers: PLC-based controllers allow for manual, automatic, or continuous sample cycling, with various housing options available.

Sample Containers: Available in polyethylene or stainless steel, suitable for pressurized applications, with capacities ranging from 32 ounces to 2.5 gallons.

Additional Options: Special alloys and coatings are available for sample tubes, including Hastelloy®, Monel®, and Teflon®-impregnated Nickel.

For more information, contact Sentry Equipment Corp at their provided contact details.

Catalog excerpts

sentry equipment corp > The Sampling Connection guide to bulk solids samplers >

Open the catalog to page 1

A point sampler takes a sample at one point in the product flow stream. > Օ > Free flowing materials from screw or drag conveyorsPellets, flakes, granules, grain and seed Օ > Non-free flowing and free flowing materials, including sanitary products, from gravity chutes and hoppers Powders, flakes, granules, powdered milk and pharma. products Conformant to 3-A Sanitary Standards ՕՕ > Designed for sampling free flowing material from pneumatic convey lines Pellets, powders, flakes and granules Isolated sample tube captures a fixed sample volume Օ > Designed for sampling non-free flowing and free...

Open the catalog to page 2

A strip sampler takes a sample of a strip across the product flow stream. > Օ > Non-free flowing and free flowing materials from gravity chutes and hoppers Pellets, powders, flakes and granules Low height requirements Օ Օ > Free flowing materials from gravity chutes and product linesPellets, powders, granules, grain, seed and friable material Sample tube is easily removed for cleaning and inspection Available in pneumatically and electrically driven versions ՕՕ > Non-free flowing and free flowing materials from gravity lines, hoppers, bins, air slides, mixers and blenders Pellets, powders, flakes...

Open the catalog to page 3

For further information , contact : 856 Eas t Armo u r Roa d P O B o x 12 7 Oconomowoc , WI 53066 US A Phone: 2 6 2- 56 7-72 56 Fax: 2 6 2- 56 7-4 5 2 3 E -m a il : sales@sentr y -equip.co m W ebs it e: www.sentr y -equip.co m > 18.1.0 Rev. 0 5 / 06 ISOLOK samplers are a registered trademark of Sentry Equipment Corp. size="-2">

Open the catalog to page 4
