CV系列开关型操作杆(专利产品，仿冒必究) CV Series Switch Joystick(Patented) 标准尺寸 / Standard Dimensions C202 抓握把手 Grip-knob Abt. 20° Φ17.5 ◆ 结构紧凑 Compact structure ◆ 规格多样（开关量模拟量可选） Various specifications (switch signal joystick or analog signal joystick optional) ◆ 本体牢固 Firm body 安装面板厚度 1~2mm Mounting panel thickness CV6-YQ-05R2G-BM 按钮开关把手型 / With push-button knob 开关布局（标准型） Switches arrangements (standard) C101-C 单开关把手 Knob with 1pc push button switch （COM ）注：另有单轴型、双层型等开关布局可选，订购前需与我们联系。 Note: available for 1 axis coordinate, double layer switches arrangements. Please consult with us in advance. 面板开孔尺寸 Panel arrangements 4-Φ2.5 孔hole Φ30 选型指导 / Selection Guide S 指特殊定制的机械规格 S means special mechanical specifications G - B M - R - 0000 特殊编号：用于特殊的客户需求 Special 4-digit part number: For customized products CV 指低价位开关型操纵杆系列 CV means low cost switch joystick 把手按钮开关带灯，指示灯可选颜色* Available LED function for push-button knob W 白色 White Y 黄色 Yellow R 红色 Red G 绿色 Green 6 指底部外壳的大概尺寸, 以cm为单位 6 means approx size of base housing in cm X 单轴调节型 / X means 1 axis coordinate Y 双轴调节型 / Y means 2-axes coordinate 把手带按钮开关* / Knob with push button switch M 触发型 Momentary L 切换型 Maintained (Locked) 操纵杆的可选操作方向 / Available directions of lever operation Q 360°方形操作(标准型) / Square-directional 360° operating angle (standard) X 只能在X、Y轴上十字操作 / Cross directional of X & Y operaing type I 只能在Y轴上 I 型操作 / I figure (Y) directional operating type Q 把手按钮开关可选颜色* Available button colors of switch for push-button knob B 黑色 Black Y 黄色 Yellow R

Open the catalog to page 1

CV系列开关型操作杆(专利产品，仿冒必究) CV Series Switch Joystick(Patented) 一般性能 / General Specifications 操作角度 Operating angle 约 Approx. ±20º （自中心位置 From center position）极限操作力 Maximum allowable force 预期机械寿命 Mechanical life expectancy 工作温度 Operating temperature range 储存条件 Storage conditions 防护等级 Protection grade IP65 (面板以上 Above panel）注1 储存条件：1.请不要在有腐蚀性气体、盐雾环境或高温多湿等环境下使用或储存，可能会影响产品的性能。如有此类使用需求，请预先与我们联系确认。2.为防止端子（镀银）的硫化出现变色，建议在60%湿度以下保存，并且在出厂后3个月内完成端子的焊接操作。Note 1 Storage conditions: 1. Avoid using or storing in corrosive gas, salt spray, high temperature, or high humidity environment, as it may affect the...

Open the catalog to page 2

CV系列开关型操作杆(专利产品，仿冒必究) CV Series Switch Joystick(Patented) C103-C 单开关把手 Knob with 1pc push button switch C103D-C 单开关把手 Knob with 1pc push button switch 其他可选把手 / Other Optional Knobs C102A-C 双开关把手 Knob with 2pcs push button switches 特殊可选规格 / Special Specifications Available 模拟量信号 / Analog signal 其他输出信号 Other output signals 特殊机械规格产品，如特殊杆高、特殊弹簧复位力等 Speical mechanical property such as special lever height, special spring return force, etc. 特殊机械规格 Special mechanical property 特殊把手 Special knob 特殊定制把手，带按钮开关把手（可选带灯），微动开关可选其他型号等 Customized knob, with push button switch (with light is optional), with...

Open the catalog to page 3
