MAGNETIC ENCODER EBMD58A-RS485
MAGNETIC ENCODER EBMD58A-RS485
- Dimensions: Housing diameter of 58mm, with options for cable placement on the side or rear of the housing.
- Mechanical Specifications: Includes a high protection degree (IP67 for housing, IP65 for shaft), starting torque of 50mN·m, and a life expectancy of over 100 million turns. The encoder is heavy-duty with antimagnetic interference and features precision ball bearings.
- Electrical Specifications: Operates on 9V-30V with a current consumption of 50mA (no-load) and 130mA. It supports Modbus RTU slave protocol with a baud rate range of 1200~115200bps, defaulting to 9600bps.
- Environmental Specifications: Operating and storage temperature range from -25°C to +85°C, vibration resistance of 100m/s², and shock resistance of 1000m/s².
- Complies with MODBUS RTU Slave protocol, with CRC16 verification. It can switch to MODBUS Master protocol for active sending mode.
- Supports commands for reading and writing register variables, with default settings of BPS-9600, no parity, 8 data bits, and 1 stop bit.
- Default slave address is 0x01, modifiable via register TX_PARA.
- Includes registers for multi-turn count, single-turn position, slave address, and communication parameters.
- Real-time data and special address command support for querying device address.
Catalog excerpts
EBMD58A 系列编码器 EBMD58A Series Encoder / Magnetic encoders / Max. number of turns: 16384 (14bit) / High protection degree / Antimagnetic interference / Screw&Servo mount / With one couple of precision ball bearings 侧面线缆（标准） Cable on the side of the housing (standard) 屏蔽线缆，标准长度1米 Shield wire, standard length 1m 尾部线缆（可选） Cable on the rear of the housing (optional) 屏蔽线缆，标准长度1米 Shield wire, standard length 1m 16MAX / Selection Guide / Signal type / Single-turn / Multi-turn / Shaft type / Installation method / Connection method / Output direction / Resolution for single turn / Output characteristics Staring torque Life expectancy Mass Housing material Shaft material Shaft load Shaft diameter 上海思博机械电气有限公司 SHANGHAI SIBO M&E CO.,LTD. / Front shaft ) / Cable on the side of the housing (Standard) ( ( ) / Cable on the rear of the housing (Optional) ) / Connector on the side of the housing (Optional) ) / Connector on the rear of the housing (Optional) ) / Servomount (Standard) / General Mechanical Speci cations Protection degree / Magnetic encoder
Open the catalog to page 1
Operating temperature range fiSSSIfi Storage temperature range sa Vibration X1® Shock ScftSSSt® (Contact discharge ±8KV, Standard model Applied voltage Current consumption (no-load) Single -turn resolution zmimm Multi-turn resolution films' Protocol Baud rate iSAddress Insulation resistance AffiHEi Dielectric strength Sift Color £T& Red Xfe Black gffl Title E&ggllEflmVCC GND £6 Brown aft Yellow Sfe White EBM^5iJ^S^tH£Ifi3f««RS485}}Iffl,tMX. / EBM Series Multi-turn Absolute Encoder «RS485» Communication Protocol / Communication Convention 1- tMX/ Protocol: SAMODBUS RTU SlavetMX(^&±%KUSASlave),...
