PLASTICITY AND MOISTURE CONTROL SYSTEM NOVATRONIC C3 For preparation and moulding lines for • • • • • • • Brick and clinker works Roof tile works Production of hand-made bricks Technical ceramics Plant/garden ceramics Refractory ceramics Expanded clay Modern PLC technology for the equipment of individual machines and lines with up to 5 control circuits • • • • Pan mills or sieve kneaders Single and double-shaft mixers Circular screen feeders Vacuum units Your benefits • • • • • • • Quality improvement Performance optimisation of the moulding process Energy saving at the dryer Reduction of working...

OF UP TO 5 PROCESSING MACHINES The following parameters can be employed for controlling the plasticity by addition of cold/hot water and/or steam, as well as dry matter, also combined: • • • • • Power consumption Flow pressure in pressing head Material moisture Material temperature Material throughput Cleaner Water Belt scale Example: Typical preparation/moulding line

HARDWARE The NOVATRONIC C3 system can be supplied in a wall housing as well as in 19“ execution for installation in existing control cabinets. A Siemens S7 PLC is used. In the standard version a 12“ TFT touch display is used as a HMI. DATA BASE The data obtained from the production process are filed in a data base and presented graphically for evaluation. In addition to the control parameters the following data can be stored in the data base: Special customer-specific features can be integrated. The NOVATRONIC C3 can import all measured data into company network. • Data security • Mobile HMIs...

Cross Linking With the NOVATRONIC C3 it is possible all measured Data to import to your company network. About a secured VPN connection the data security is ensured. Thus, even the operation of the NOVATRONIC C3 mobile or from the office possible. With the NOVATRONIC C3 we offer a remote service and diagnostic based on a broadband data connection for visual and acoustic communication between customers and service technicians. ONLINE Office Ethernet Tablet Direct Connection / Powerlink Dosing units

EXTERNAL SENSORS and ASSEMBLY GROUPS 1 ELECTRONIC PLASTOMETERS 4 DOSING UNITS FOR WATER Plastometers for detection of pressure value optional either with temperature sensor PT 100 and display station or with variously designed displays. Belt-weighers can be integrated for the determination of material throughput. Existing weighing frames can also be integrated into the Novatronic C3 system. When the installation of a belt-weigher is impossible for technical reasons we can provide level switches for determination of throughput via belt speed and material height. From DN 25 to DN 65 with electro-pneumatic...

PLASTICITY AND MOISTURE CONTROL SYSTEM MOULDING LINES Brick and clinker works Roof tile works Production of hand-made bricks Technical ceramics Plant/garden ceramics Refractory ceramics Expand

OF PROCESSING MACHINE The NOVATRONIC C2+ can be used to evaluate following measured values: • • • • • Power consumption Flow pressure in pressing head Material moisture Material temperature Belt scale NOVATRONIC C2+ IS THE NEW, ENHANCED VERSION OF THE TRIED-AND-TESTED CONTROL SYSTEM NOVATRONIC C2 NOVATRONIC C2+ is based on PLC control and is designed to regulate individual processing machines. During development, the dimensions and parameter structure of the NOVATRONIC C2 were used as a guide, meaning that it is simple to make a 1-to-1 swap between the two systems without a great deal of effor...

CONNECTION ASSIGNMENT of the novatronic C2+ OVERVIEW

EXTERNAL SENSORS and ASSEMBLY GROUPS 1 ELECTRONIC PLASTOMETERS 4 DOSING UNITS FOR WATER Plastometers for detection of pressure value optional either with temperature sensor PT 100 and display station or with variously designed displays. Belt-weighers can be integrated for the determination of material throughput. Existing weighing frames can also be integrated into the Novatronic C2+ system. From DN 25 to DN 65 with electro-pneumatic proportional control valves for additions of 625 kg/h to 3750 kg/h at 8 bar. • With impulse valves • Throughput performance with piston stroke 1 mm at 1.0 bar 0...

NOVATRONIC CONTROL SYSTEMS for preparation and shaping in the CLAY INDUSTRY [email protected] www.sensor-control.de

ELECTRONIC PLASTOMETER THE PROVEN SENSOR FOR PLASTICITY MEASUREMENT For measuring mould pressure and clay temperature on extruders for ceramic products. The plasticity sensor is a part of the moisture- and plasticity control system NOVATRONIC for preparation and shaping in ceramic production lines. TECHNICAL DATA Measuring range for pressure: 0... 25 bar / 0... 40 bar or in Special measuring ranges between 4... 100 bar Standard output signal: standard 4 - 20 mA (also available in 0 - 10 V) Measuring range for temperature: Mineral-insulated resistance thermometer with Pt 100, 0... 100°C Standard...

ELECTRONIC PLASTOMETER OVERVIEW OF AVAILABLE VERSIONS WITHOUT DISPLAY PRESSURE / TEMPERATURE WITH DISPLAY with display PRESSURE with two displays PRESSURE / TEMPERATURE WITH EXTERNAL DISPLAY PLASTOMETER-SET with external display PRESSURE PLASTOMETER-SET with two external displays PRESSURE / TEMPERATURE

ITEM NUMBER Other pressure ranges on request. Type: 49.011-242 (4-20 mA version with 2-wire connection) . Type: 49.011-010 (0-10 V version)

CONVEYER BELT SCALE CONTINUOUS BULK MATERIAL MEASUREMENT IN BELT CONVEYOR The single-idler belt scale records the weight of the material on a load cell specific section of conveyor belt. Continuous weight recording Conveying rates between 45-800 t/h Belt widths from 500 to 1.350 mm Efficient data collection Easy installation Low installation depth The weight of the conveyed material is measured with a strain gauge bending beam load cell. The current belt speed is continuously recorded by the measuring wheel with the speed sensor. The flow rate [t/h] is then calculated from these two variables....
