SEKO
Peristaltic dosing pumps

Peristaltic dosing pumps

Product catalog summary

Introduction
This document provides technical specifications and features of SEKO's peristaltic pumps, specifically designed for chemical dispensing in dishwashing machines. These pumps are part of the cleaning and hygiene division, offering solutions for various dosing needs.

Compliance and Standards
SEKO dosing pumps comply with international standards including 73/23CEE, 89/336CEE, EN60335-1, and ISO 9001 (version 2000), ensuring safety and quality.

Key Features

Durability: Polypropylene enclosure is shockproof and resistant to chemical aggression.
Protection: IP 65 protection degree and class 2 electrical insulation.
Reliability: Equipped with Santoprene and Sekobril squeeze tubing for secure connections.
User-Friendly: Easy installation and maintenance with wall mounting brackets and quick electrical connections.

Technical Specifications

Power Supply: 230 Vac 50-60 Hz (24 Vac available upon request).
Power Consumption: 3.5 W.
Models: Various models with different flow rates and pressure capabilities, including PR, PRT, PA, and PE series.
Adjustments: Analogic speed and dosing time adjustments available.

Accessories

Installation kits include conductivity probes, wall mounting brackets, and various connectors.
Level control systems with alarm inputs and relay outputs are available.

Global Presence
SEKO operates in multiple regions including Asia Pacific, China, Brazil, USA, Southern Africa, Germany, France, Spain, Italy, Romania, Russia, and the UK.

Note
Technical data is subject to change without notice, and images are indicative only.

Catalog excerpts

innovation > technology > future Peristaltic Pumps Chemical dispensers for dishwashing machines

Open the catalog to page 1

cleaning & hygiene division > chemical dispensers for dishwashing machines SSoolluuttioionsnfsor feoacrh e daocsihng d noeesdins g needs SEKO dosing pumps comply with the provisions contained in the following international standards: > 73/23CEE of 19/2/73 > 89/336CEE of 3/5/89 > EN60335-1 > ISO 9001 (version 2000) Easy installation Minimum maintenance Polypropylene enclosure extremely shockproof and resistant to chemical aggression IP 65 protection degree and class 2 electrical insulation (no ground connection required) Extra-strong and long life Santoprene and Sekobril squeeze tubing, always...

Open the catalog to page 2

Power supply 230 Vac 50-60 Hz (24 Vac 50-60 Hz upon request) Power consumption 3.5 W PR 4 (Santoprene squeeze tubing) 0.1 bar 0.6…4 lt/h PR 7 (Santoprene squeeze tubing) 0.1 bar 1.2…7 lt/h Models powered via single or double solenoid valves available. Two setting trimmers enable detergent Initial Charge and Make Up Charge. Power supply 230 Vac 50-60 Hz (24 Vac 50-60 Hz upon request) • Power consumption 3.5 W Initial Charge time 18 to 180 sec. • Make Up Charge time 2 to 15 sec. PRT 6 (Santoprene squeeze tubing) 0.1 bar 6 lt/h PRT 9 (Santoprene squeeze tubing) 0.1 bar 9 lt/h PRT Fixed speed peristaltic...

Open the catalog to page 3

SEKO Asia Pacific SINGAPORE • SEKO China CHINA • SEKO do Brasil BRAZIL • SEKO Dosing Systems USA • SEKO Southern Africa SOUTH AFRICA • SEKO Deutschland GERMANY • SEKO France FRANCE • SEKO Iberica SPAIN • SEKO Italia ITALY • SEKO SIETA ROMANIA • OOO SEKO RUSSIA • SEKO UK UNITED KINGDOM w w w . s e k o . c o m BRO PRPUK 071 Technical data can be change without warning. Pictures and technical drawings are indicative only Installation Kit Conductivity probe Wall mounting bracket PP injection connector Stainless Steel non return valve Boiler non return valve adapter Ø 6-8 mm Foot filter PVC Suction...

Open the catalog to page 4
