Overview

This document provides a comprehensive product overview of SCHURTER's range of IEC connectors, power entry modules, cord connectors, and distribution units. It details various connector types, their features, mounting options, connection methods, and certifications.

Main Sections

1. IEC Connector Types and Features

The document lists multiple IEC connector types categorized by current ratings (e.g., 2.5 A, 10 A, 16 A) and UL ratings. Each connector type is described with the following attributes:

• Protection class (Class I or II)
• Ingress Protection (IP) ratings where applicable
• Maximum pin temperature (typically 70°C, some up to 155°C or 120°C)
• Locking and cord retaining features
• Enhanced glow wire resistance
• Additional components such as fuse holders (1-pole or 2-pole), switches (1-pole or 2-pole, illuminated), circuit breakers, and voltage selectors
• Mounting and connection types including screw-on (front/rear), snap-in, drop-in, sandwich, quick connect, solder terminals, screw terminals, PCB, and IDC terminals
• Alternate types with line filters

Polarized and shuttered versions are also noted for specific connector types.

2. Cord Connectors

Details on rewireable cord connectors are provided, specifying:

• IEC type and maximum pin temperature
• Design approvals (VDE, ENEC, UL, CSA, etc.)
• Maximum wire size in mm² and AWG
• Maximum cable diameter
• Design variations such as gold-plated contacts and IP67 rated versions

3. Distribution Units

Distribution units are described with their appliance inlet and outlet types, number of outlets, and available options such as switches, fuse holders, and line filters. Current ratings covered include 10 A / UL 15 A and 16 A / UL 16 A. Examples include:

• Single and multiple outlet units with appliance inlets C14, C20, and power supply cords
• Options for solder terminals, quick connect terminals, and plug couplers
• Special features like space for additional elements or integrated line filters and switches

4. Approvals and Certifications

The document highlights various international approvals and certifications for connectors and components, including VDE, ENEC, UL, CSA, CCC, PSE, and others, ensuring compliance with global safety and quality standards.

5. Additional Information and Services

SCHURTER offers customized solutions beyond the standard product range, including sample builds and tailored designs to meet specific customer requirements. Detailed datasheets for each connector type can be accessed via the SCHURTER website by entering the connector type number.

Key Technical Parameters and Best Practices

• Selection of connectors should consider maximum pin temperature and protection class to ensure safety and reliability.
• Mounting and connection methods vary by application; choosing the appropriate type (e.g., snap-in vs. screw-on) affects installation ease and durability.
• Fuse holders and switches integrated into connectors provide enhanced circuit protection and control.
• Enhanced glow wire resistance and IP ratings improve safety in harsh environments.
• Compliance with international certifications is critical for market acceptance and regulatory adherence.

Summary of Critical Information

This structured overview facilitates selection and application of SCHURTER connectors and power entry modules based on technical requirements, safety standards, and installation preferences.
