Presses, Control Units, Safety & more Complete solutions from a single source

Rack-and-Pinion Presses Toggle Presses  NockenPresse 11N  DuplexPress 8  ManualPress 305, 307, 311 with Process Monitoring Hydro-/Pneumatic Presses PneumaticPress Direct Acting Presses PneumaticPress Toggle Presses  PneumaticPress Force / Stroke Monitoring  HydroPneumaticPress C-Frame Design  HydroPneumaticPress Force / Stroke Monitor.  HydroPneumaticPress H-Frame Design  Cylinder Units Electric Presses ElectricPress ServoPress  TorquePress Control Units PressControl 75 PressControl 700  PressControl 7000  Visualization & Process Analysis  Software Tools, PRC DataBase  PRC...

Family-Run Company As internationally accepted Technology Leader SCHMIDT Technology is a family-run, medium-sized enterprise at the highest technological level. The success speaks for itself: Today, products and services from SCHMIDT Technology are exported to over 80 countries of the world. Because of this, SCHMIDT Technology is valued internationally as a solid, dependable and competent partner. The outstanding characteristics of a successful company must include a strong visionary innovation potential. The safety and quality of SCHMIDT Technology products make them unique on the global...

Your profitability Is our top priority The task to assemble two or more components requires a careful decision about the joining method. Traditional processes such as bolting, soldering, welding or glueing are continuously being replaced with cost effective and efficient pressing operations. These are exactly our strengths. Pressing Snap Fitting Forming Calibrating / Sizing Use our knowledge for your application The right press type can be chosen depending on the application. Today, SCHMIDT® Presses stand for first-class assembly technology worldwide. This applies both for stand-alone...

A global market requires linked processes. Thanks to the OPC connection via Ethernet technology, you can access your process data at any time. Furthermore, local representation and rapid response are essential. Our worldwide distribution network of subsidiaries and trained sales & support partners ensure that our customers will receive full support for all their requirements. All our representatives' support teams have been trained specifically on our products. Deciding in favour of our technology is the first step to a successful partnership. The economic success is then shown in daily...

SCHMIDT® ManualPress From 1.6 kN to 22 kN Efficient manufacturing requires appropriate means of production – not always automation. In particular, with small production runs, manual presses are often the most cost effective solutions. We are continually developing the range of manual presses so that you can achieve your production targets. The expertise we have gained from our exposure to numerous production applications has been implemented in our new models. Therefore, we can offer a wide range of manual presses to suit all requirements. Characteristics Flexibility - Rapid changeover due...

SCHMIDT® Rack-and-Pinion Presses Constant force over the entire stroke Do you need force over a longer stroke distance for assembly processes? Then SCHMIDT® Rack-and-Pinion Presses are the right choice. Characteristics  Long stroke  Linear force progression  Precise adjustment of the press depth via an integrated hardened adjustable stop  Honed ram guiding and ground rams provide a long service life and a precise guidance Improved return stroke mechanism for rack-andpinion presses No. 3 and 6 with stroke 100 mm and 160 mm The use of a spring package optimized specifically for large...

From 1.6 kN to 2.5 kN Press Type Throat depth C Ram bore Ø Collet (standard Ø 10) Ø Hand lever left Angle of rotation / mm stroke Press head type Nominal force Working stroke up to Press head height Max. weight of the upper tool 2) Return stroke lock Minimum working stroke mm mm bef. BDC Locked position 1 mm bef. BDC Locked position 2 Disengaging accuracy Working height 3) Frame No. 13 Frame No. 3 Frame No. 2 Frame No. 2-600 • Frame No. 2-1000 • Weight Mechanical counter Throat depth frame (total depth) 111 mm, 131 mm, 160 mm, 200 mm Additional fixture mounting plate suitable for throat...

SCHMIDT® Toggle Presses The high force at the end of stroke, just where it is important Do you need a high force at the end of stroke for material transforming processes? Then SCHMIDT® Toggle Presses are just the right choice. 1 = No. 13 force at the hand lever 200 N 2 = No. 13 force at the hand lever 120 N stroke before full extension position of the toggle (mm) stroke before full extension position of the toggle (mm) Characteristics  High force at the end of stroke (see diagramm below)  Honed bores and ground rams provide a long service life and a precise guidance pushing force (kN) 1 =...

From 5 kN to 15 kN Press Type Press head type Nominal force Throat depth Press head height Ram bore Ø Hand lever left Angle of rotation Max. weight upper tool 3) standard / reinforced spring Return stroke lock 1) Minimum working stroke Locked position 1 Locked position 2 Disengaging accuracy Working height 4) Accessories Mechanical counter Throat depth frame (total depth) 111 mm, 131 mm Additional fixture mounting plate suitable for throat depth frame Block clamping piece 2) Frame Overview No. 13 No. 3 No. 5 No. 2 No. 2-600 No. 2-1000 Options • Series with no additional charge • Additional...

SCHMIDT® Toggle Presses with Horizontal Pull The high force at the end of stroke, just where it is important Do you need a high force at the end of stroke for material transforming processes? Then SCHMIDT® Toggle Presses are just the right choice. Characteristics  High force at the end of stroke (see diagramm below)  Honed bores and ground rams provide a long service life and a precise guidance Ergonomic Press with horizontal pull With press No. 113 and No. 111 the manual force is applied by pulling the lever towards the body. This press is especially suitable for rapid production at...
