ManualPressRack-and-Pinion Presses, Toggle Presses, CamPress 11N and ManualPress 300 Series with Process Monitoring SCHMIDT Technology GmbH Feldbergstr. 1 • 78112 St. Georgen • Germany Tel. +49 (7724) 899 0 • Fax +49 (7724) 899 101 [email protected] • www.schmidttechnology.de SCHMIDT Technology Ltd. United Kingdom (UK)

SCHMIDT® ManualPressFrom 1.6 kN to 22 kN Efficient manufacturing requires appropriate means of production - not always automation. In particular, with small production runs, manual presses are often the most cost effective solutions. We are continually developing the range of manual presses so that you can achieve your production targets. The expertise we have gained from our exposure to numerous production applications has been implemented in our new models. Therefore, we can offer a wide range of manual presses to suit all requirements. - Rapid changeover due to the easy and secure adjustment...

SCHMIDT® Rack-and-Pinion Presses Constant force over the entire stroke Do you need force over a longer stroke distance for assembly processes? Then SCHMIDT® Rack-and-Pinion Presses are the right choice. Characteristics Long stroke Linear force progression Precise adjustment of the press depth via an integrated hardened adjustable stop Honed ram guiding and ground rams provide a long service life and a precise guidance Improved return stroke mechanism for rack-andpinion presses No. 3 and 6 with stroke 100 mm and 160 mm The use of a spring package optimized specifically for large strokes improves...

SCHMIDT Technology Press Type Frame Overview Options• Series with no additional charge o Additional charge applies11 Adjustment of locking position on request 2) The weight was determined with hand lever position 45° forward (guide) 3) Typical values; can vary ± 3 mm due to casting and production tolerancesOther available options■ Nickel plated - cast parts are electroless nickel plated, steel components black oxide finished, aluminum anodized, precision steel surfaces are untreated■ Custom paint - press and column can be painted to customer's color specification■ Bores for adapting tooling -...

Do you need a high force at the end of stroke for material transforming processes? Then SCHMIDT® Toggle Presses are just the right choice. ■ High force at the end of stroke (see diagramm below) ■ Honed bores and ground rams provide a long service life and a precise guidance 1 = No. 13 force at the hand lever 200 N 2 = No. 13 force at the hand lever 120 N 1 = No. 17 force at the hand lever 200 N 2 = No. 17 force at the hand lever 120 N o 3 = No. 11, 14, 15, 16 force at the hand lever 200 N ^ 4 = No. 11, 14, 15, 16 force at the hand lever 120 N Maximum force will be reached just before extended...

SCHMIDT Technology Press Type Frame Overview Press Type Options • Series with no additional charge o Additional charge applies 11 Adjustment of locking position on request 2) Stroke reduction about 10 mm by version with additional charge 3) The weight was determined with hand lever position 45° forward (guide) 4) Typical values; can vary ± 3 mm due to casting and production tolerances 5) Stroke adjustable with stop clamp (in the scope of delivery) ■ Nickel plated - cast parts are electroless nickel plated, steel components black oxide finished, aluminum anodized, precision steel surfaces are...

Do you need a high force at the end of stroke for material trans- Characteristics forming processes? Then SCHMIDT® Toggle Presses are just the ■ High force at the end of stroke (see diagramm below) right choice. ■ Honed bores and ground rams provide a long service life and Ergonomic Press with horizontal pull With press No. 113 and No. 111 the manual force is applied by pulling the lever towards the body. This press is especially suitable for rapid production at small forces. We supply press No. 111 including the ergonomic handle (standard scope of supply). 1 = No. 111 force at the hand lever...

From 2.5 kN to 12 kN Press Type ■ Nickel plated - cast parts are electroless nickel plated, steel components black oxide finished, aluminum anodized, precision steel surfaces are untreated ■ Custom Paint - Press and column can be painted to customer's color specification ■ Bores for adapting tooling - customer specific sizes Detailed dimensional drawings can be downloaded: www.schmidttechnology.de schmidttechnology.com | II 07

Do you need a high force at the end of stroke for materialtransforming processes? Then SCHMIDT® Toggle Presses are just the right choice. Characteristics■ High force at the end of stroke■ Square ram is anti-rotational (no die sets required)■ Fully adjustable, play-free teflon-lined gibs Press Type 11 VRFZ 1 = No. 11, 14, 15, 16 force at the hand lever 200 N 2 = No. 11, 14, 15, 16 force at the hand lever 120 N No. 13 see on page 8 1 = No. 19 force at the hand lever 200 N 2 = No. 19 force at the hand lever 120 N Maximum force will be reached just before extended position II 08 | SCHMIDT® Presses...

From 5 kN to 22 kN Press Type Options • Series with no additional charge o Additional charge applies 11 Special strokes 12 mm and 50 mm on request 2) Adjustment of locking position on request 3) The weight was determined with hand lever position 45° forward (guide) 4) Typical values; can vary ± 3 mm due to casting and production tolerances 5) Stroke adjustable with stop clamp (in the scope of delivery) ■ Nickel plated - cast parts are electroless nickel plated, steel components black oxide finished, aluminum anodized, precision steel ■ Custom Paint - Press and column can be painted to customer's...

SCHMIDT® CamPress 11N The best of both worlds We have merged the best features of the two hand lever press types, the toggle press and the rack and pinion press, and combined them in the SCHMIDT® CamPress 11N. Thanks to this clever mechanism, the patented assembly press is characterized by a particularly smooth operation and strong force at the end of the stroke. The sophisticated mechanics make the manual CamPress 11N particularly ergonomic and user-friendly. This unique motion creates a high, linear force progression with high breakaway torque at the beginning of the ram movement and a steep...
