Your success guaranteed Press brakes

We give SHAPE to any sheet The sophisticated building technology of the machines and tools, matched with the angle measurement sensor developed and patented by Schiavi, produces a perfect bending on the whole length of the processed piece. The key features of Schiavi press brakes is their capability to produce simple and complex geometrical shapes with the same accuracy. Every model of the Schiavi press brakes has developed a specifi c system that makes it possible to obtain parallel table curvature, an essential principle to guarantee the constancy of bending angle.

A wide choice and many models renewed in their structural, technical and design contents Flexa Hfb Stp.c Press brakes To guarantee perfect integration between hydraulic, electronic and mechanical parts, Schiavi has developed these machines’ design, making use of an integrated technical team exclusively dedicated to machines’ manufacturing. All the line of Schiavi press brakes makes use of high-quality components. A signifi cant example of this is represented by the upper table, whose descent is lead by an ensemble of bearings that slide on steel guides integral with the machine sides; this...

The new generation of press brakes The FLEXA numerical control press brakes series is the result of the continual technological research lead by Schiavi. The Flexa press brake features a peculiar structure with closed gate (Patented) that, regardless of weight and tonnage, guarantees the best inertial conditions with a thrust reaction force that remains always perfectly aligned. The action of the aligned hydraulic actuators avoids the typical bending that takes place in press brakes with throat. Thanks to the opening in the two side racks, movement in the columns is unhindered. This allows...

The Flexa series press brakes are extremely versatile machines that allow optimisation and management of several working procedures. The structure, thanks to its building features, guarantees that passage through the columns corresponds to the maximum bending length. This allows working on details that might otherwise be very diffi cult to obtain with traditional press brakes. • Closed gate structure (Patented) • Triple board lower table (Patented) designed to obtain perfect parallel deformation of the boards • The increase of upper table and ram return and approaching speed • Quick tool...

Intermediates for the HFBs L model, with increased open height. To bend with absolute accuracy HFB press brakes represent our most advanced technological model as far as automation of the bending process is concerned. Schiavi, with this new product range, provides all companies operating in sheet metal operation with the means to increase their competitive edge on a continually evolving market. The exceptional HFB range consists of three separate lines that perfectly conform to the most diversifi ed production needs. The standard Line, HFBs, ensures high versatility and fl exibility with...

perfectly integrating with company-made press brakes with high cinematic performance can minimise the work process cycle times. The press brakes in this line are particularly recommended for integration with a robot-operated bending cell. Schiavi is in fact equipped with a wide range of multi-axis robots with load capacity from 8 to 150 kg that, 9 HFB is the new series dedicated to the customer that needs excellent bending accuracy. Matched with dedicated hydraulics and last generation software, this press brakes line increases your competitive edge in a continually evolving market. •...

Hfb .. .. .. .. .. .. .. .. .. 10 HFBx, the top performance line Schiavi proposes the HFBx, a line with a large number of models ranging from 50 to 220 tons, with lengths ranging from 2000 to 4000 mm. The approaching speed (250 mm/sec.) and return speed (250 mm/sec.) of the upper table make it possible to keep high production standards.

Flexibility and automation Maximum productivity, extremely low labour costs, safer working environment and extreme ease of use. All of this is possible by making use of the integrated automation that Schiavi offers with its robot-operated bending cells. The interaction between design and manufacturing has made it possible to devise the robot operated bending cells that now Schiavi can offer, a full package that includes press brakes, handling robot and CNC, as well as a software application capable of simulating the whole bending process on PC. The Schiavi bending cells are therefore the...

A second 3 axes robot can be integrated to support the bending cell. This allows piece preparation in offl ine time, which greatly speeds up the bending process. • Five axes solution: two linear axes and three revolving ones • Free to defi ne and lay out the loading/unloading areas in the working area • It is possible to install them on machines already in operation at the end user’s • Possibility of placing the robot in the sideways parking area in order to be able to return the machine to the original manual working condition • The robot, designed and built by Schiavi, achieves a perfect...

Schiavi offers custom-tailored solutions for your needs More than 12,000 press brakes installed by Schiavi testify to the well known quality of these machines, on the Italian market from almost 50 years. As regards sheet metal bending, Schiavi Macchine Industriali has defi nitely aimed to tradition with a large amount of new contributions: from process automation to bending angle measurements, without forgetting the new numerical controls. We have also produced the new HFBx series press brakes, with remarkable geometrical sizes and high-level dynamic performances, in addition to the new STP...
