FerriteLine 240 ADVANCED CRIMPING MACHINE FOR PROCESSING OF FERRITE CORES Connecting Multi-Core Cables The comprehensively equipped machine is designed for stripping and equipping two wires with ferrite cores as well as for crimping with previously bent terminals. The individual ferrite cores are brought into the correct position in a conveyor pot and are supplied via a feed rail. Terminals to be manufactured are formed by a bending unit and then fed to the crimping process. Wires are inserted by the operator and in the following steps automatically equipped with ferrite cores and connected to the terminals. The robust machine design enables high durability and reproducibility of the crimp connections. © Schäfer Werkzeug- und Sondermaschinenbau GmbH | 1.0

CRIMPING MACHINE FOR PROCESSING OF FERRITE CORES Wide Range of Use Options A high degree of flexibility and diverse applications are made possible by the simple changeover to another product to be processed. For crimping different terminals, crimp applicators can be easily exchanged using the quick-change device. The ideal speed for the crimping process can be individually adjusted according to the existing terminal properties. Quality Assurance Functions The integrated crimp force monitoring reliably detects false crimps during the production. To support quality assurance, faulty cables are...

MODERN OPERATING INTERFACE Machine Control Software The touch screen control has an intuitive user interface for easy and safe operation of the crimping press in various languages. Selecting different user roles and operating modes as well as machine networking functions provides flexible and modern process sequences. EQUIPMENT OF THE MACHINE Base Equipment Optional Extensions Crimping machine Machine cover Ferrite feeding unit Zero cut module Stripping unit Bad part cutter Crimp force monitoring Specific wire gripper Vacuum cleaner for stripping leftovers Paper winder Bending unit Color detection...

TECHNICAL DATA Stripping lengths Sheath-removal lengths Motor speed Pressing force Stroke Closing height Two individual wires, two-core sheathed cables, two-core twisted cables Wire cross section: 0.35 - 0.5 mm2 [1] Transversely belted stripes Display Touchscreen [1] Depending on the material and the geometry of the materials to be processed. [2] Approximate indication for basic equipment without attachments, e.g. contact feeder. Dr.-Alfred-Weckesser-StraRe 6 76669 Bad Schonborn Germany E-Mail: [email protected] FURTHER INFORMATION
