EDGE GATEWAY NETWORK INTERFACE FOR INDEVA® MANIPULATORS

INTERCONNECTION PROCEDURES The Edge Gateway ensures the full integration of INDEVA® industrial manipulators with company IT systems, enabling real-time data exchange, remote monitoring and the management of operating parameters. When combined with the Wi-Fi Bridge module, it also allows for the wireless transmission of information, offering a flexible solution for machine connectivity and supporting Smart Factory and Industry 4.0 processes. GATEWAY + WI-FI BRIDGE Ethernet connection Ethernet connection Wi-Fi connection Torque Control Brake Drive Servo Drtve! Inclinometer _ Gateway software Reduction...

EDGE GATEWAY - NETWORK INTERFACE FOR INDEVA® MANIPULATORS An INDEVA® manipulator equipped with an Edge Gateway can seamlessly integrate into the customer’s IT infrastructure by exchanging data through the company’s Ethernet network. This connectivity enables real-time communication between the manipulator and the production management system, supporting the principles of Industry 4.0. Through standard communication protocols (ModBus® TCP/IP), the Edge Gateway allows the transmission of various parameters, thereby monitoring operations, optimising processes and improving production efficiency...

Wi-Fi Bridge is the communication module which, when paired with the Edge Gateway, enables the wireless exchange of data that has been collected and stored. Wi-Fi Bridge receives the information collected by the Edge Gateway and sends it, via a Wi-Fi network, to the company’s IT systems, ensuring reliable and efficient data transfer. This solution eliminates the need for wired connections, enables remote monitoring and access to data, and improves the system’s flexibility and scalability. The Liftronic Monitoring Application enables real-time monitoring of variables relating to the manipulator,...

TECHNICAL SPECIFICATIONS Supply voltage Protection rating EXAMPLES OFVARIABLES (more than 130) FEATURE

SOLUTIONS FOR SMART MANUFACTURING LEAN SYSTEM INDUSTRIAL MANIPULATORS ROBOTIC AUTOMATION A unique and extensive range of products, at the cutting edge of technology, to best meet customised applications. INTERNATIONAL PRESENCE PRODUCTION PLANTS Scaglia INDEVA S.p.A. INDEVA SysDesign S.r.l. United Kingdom Scaglia INDEVA S.A.R.L. Scaglia INDEVA GmbH Scaglia INDEVA Nordic AB Scaglia INDEVA (Shanghai) Ltd. Scaglia INDEVA Ergomatic India Pvt. Ltd.

EDGE GATEWAY The products described in this document are subject to updates or modifications at any time. The descriptions, technical and functional information, illustrations and instructions in the leaflet are to be considered as purely illustrative, and consequently have no contractual relevance. Remember also that the products themselves must be used by qualified personnel, in compliance with current plantengineering installation regulations, in order to avoid damage to persons or property. NETWORK INTERFACE FOR INDEVA® MANIPULATORS via G. Marconi, 42 24012 Val Brembilla (Bergamo) - ITALY...
