SATO Product Guide

Product catalog summary

Introduction
SATO is a leader in Data Collection Systems and Labelling solutions, known for innovations like the first hand labeller and thermal transfer printer. They focus on enhancing supply chain efficiency through barcodes and RFID technology.

RFID and e Series
SATO's RFID printers, such as the CL 400e RFID HF-UHF, support HF and UHF RFID labels, featuring robust construction and high throughput. Models like CL 408e and CL 412e offer thermal printing with resolutions of 203 and 305 dpi, supporting interfaces like USB and LAN.

S Series
The M 8485Se UHF printer is designed for high-speed printing with a maximum width of 128 mm and speed of 300 mm/sec, featuring a real-time clock and memory expansion options.

Pro Series
The M-84Pro series caters to demanding applications with changeable print resolutions and high-speed data processing, supporting various interfaces and options like label cutters.

Compact Series
The MB 20xi and MB 400 are mobile printers for on-the-go labelling, featuring durable construction and high-speed printing. The CT 400 and CX 400 models offer compact designs with easy maintenance.

Retail Series
The HT 200e is a cost-effective, stand-alone label printer for low-volume needs, emphasizing ease of use.

Conclusion
SATO provides a range of printers and labelling solutions for various industrial needs, offering robust and versatile options for efficient data collection and labelling.

Product Overview
This document details specifications and features of SATO printers and accessories for retail and industrial applications, highlighting capabilities, technical specifications, and optional features.

HT 200e Printer
A user-friendly printer for retail and industrial use, supporting thermal and thermal transfer printing with a resolution of 203 dpi, featuring a maximum print width of 48 mm and print speed up to 80 mm/sec.

XL 400e/410e Printers
Designed for textile tag and ticketing industries, offering print speeds up to 200 mm/sec with interfaces like USB and LAN, and options like a rewinder and stacker.

S Series Printers
High-speed, durable printers for continuous printing, supporting various barcodes and graphics with speeds up to 300 mm/sec.

Lt408 Printer
An affordable OEM print engine for barcode label production, featuring a 203 dpi resolution and interfaces like RS-232C and Wireless LAN.

S84xx Series
High-end OEM print engines for print-and-apply systems, offering speeds up to 400 mm/sec and resolutions up to 609 dpi, with tool-less part replacement.

Label Gallery Software
Advanced label design and printing solutions with a user-friendly interface, offering versions like EASY, PLUS, and TRUE PRO for different design complexities.

Labels and Ribbons
SATO produces high-quality, custom-made labels and ribbons in wax, resin, and wax/resin qualities for optimal printer performance.

Hand Labellers
SATO offers hand labelling systems for various applications, designed for ease of use and durability.

Accessories
Includes rewinders for label management and a smart keyboard for independent label printing, supporting various media widths and winding directions.

SATO Smart Keyboard
Designed for standalone label production, featuring a 68-key keyboard and a 20-character by 2-line LCD display, compatible with all SATO printers.

Specifications

Display Unit: Compatible with all SATO printers.
Keyboard: 68 keys.
LCD Display: 20 characters x 2 lines.
Serial Interface: Two COM ports with 9 pins, supporting baud rates from 9600 to 57600.
Memory: 1 MB Flash ROM and 256K SRAM.
Firmware: Includes a BASIC-like language interpreter.
Additional Features: Real-time clock, € currency logo, and 6-digit floating calculation.
Power: 5V/DC, 250mA supplied via RS232 printer interface.
System Requirements: SATO Label Gallery software, Windows 9x, ME, 2000, NT, RS232 interface.
Country Character Stickers: Available for various languages including UK, Danish/Norwegian, Swedish/Finnish, and more.

Accessories

S70 Rewinder: Suitable for large volumes of labels, rewinding onto a core for later application.
Technical Data for S70:
- Dimensions: W 110 mm x L 260 mm x H 170 mm.
- Weight: 1550g (excluding battery).
- Power Supply: AC Adaptor.
- Label Feed Speed: Max. 110 mm/s.
- Supported Label Sizes: Width 15 ~ 70 mm, Length 10 ~ 150 mm.
- Core ID: Minimum 25 mm.
- Label Roller Outer Diameter: Max. 120 mm.
- Energy Saving: Auto power off after 5 minutes of non-operation.
- Protection Functions: Auto stop for label detection and low battery.
- Optional Accessories: Battery pack, battery charger, sync connector.

Catalog excerpts

Untitled table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:8.00pt "Arial", sans-serif; } .font1 { font:9.00pt "Arial", sans-serif; } .font2 { font:14.00pt "Arial", sans-serif; } .font3 { font:5.00pt "Verdana", sans-serif; } .font4 { font:7.00pt "Verdana", sans-serif; } .font5 { font:14.00pt "Verdana", sans-serif; } SSries : RFID SOLUTIONS M 8485Se UHF On-Line Labelling Module Many major consumer goods manufacturers are already using automated print and apply systems. Replacing the print engine with an RFID enabled printer allows the system to automatically encode...

Open the catalog to page 5

Untitled table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:7.00pt "Arial", sans-serif; } .font1 { font:8.00pt "Arial", sans-serif; } .font2 { font:5.00pt "Verdana", sans-serif; } .font3 { font:14.00pt "Verdana", sans-serif; } e Sries : M 10e Maximum printing! SATO's 267mm (10,5") wide web printer is just as big on performance as it is in size. With a print speed of up to 125 mm (5") per second and an ultra high speed data processor, the M 10e meets the needs of a range of industries, including shipping, logistics, electronics, general manufacturing, paper and timber....

Open the catalog to page 10

Untitled table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:4.00pt "Arial", sans-serif; } .font1 { font:4.20pt "Arial", sans-serif; } .font2 { font:6.60pt "Arial", sans-serif; } .font3 { font:7.00pt "Arial", sans-serif; } .font4 { font:8.00pt "Arial", sans-serif; } .font5 { font:11.00pt "Arial", sans-serif; } .font6 { font:4.00pt "Lucida Sans Unicode", sans-serif; } .font7 { font:6.00pt "Tahoma", sans-serif; } .font8 { font:2.00pt "Verdana", sans-serif; } .font9 { font:5.00pt "Verdana", sans-serif; } .font10 { font:6.00pt "Verdana", sans-serif; } .font11 { font:14.00pt...

Open the catalog to page 24
