Altitude Test Chamber
Altitude Test Chamber
- Control Range: -70°C to 180°C, with variations for different models (A: 0°C to 180°C; B: -20°C to 180°C; C: -40°C to 180°C; D: -70°C to 180°C).
- Fluctuation: ±0.5°C.
- Cooling Rate: From 180°C to -70°C within 120 minutes (1.0 to 2.0°C/min).
- Heating Rate: From -70°C to 180°C within 100 minutes (2.0 to 3.0°C/min).
- Uniformity: ±1.5°C (-40°C to 100°C), ±2.0°C (100.1°C to 180°C or -40°C to -70°C).
- Range: Normal pressure to 0.5kPa (500Pa).
- Error: ±2kPa (>40kPa), ±5% (2kPa to 40kPa), ±0.1kPa (<2kPa).
- Depressurization Time: Normal pressure to 1kPa in about 30 minutes.
- Pressure Recovery Time: Less than 10kPa/min.
- Control Range: 20.0%RH to 98.0%RH under atmospheric humidity.
- Fluctuation: ±2.0% RH.
- Uniformity: ±5.0% RH.
- Internal Material: 2mm thickness stainless steel plate (SUS304).
- External Material: 10mm thickness cold rolled steel plate, fully welded and powder sprayed.
- Insulation: 100mm thickness polyurethane plate and 10mm thickness mineral wool.
- Fan: Centrifugal blower.
- Compressor: France Tecumseh, Germany Bock, Germany Bitzer.
- Condenser: Air cooling and water cooling.
- Refrigerant: R404A, R23, R508.
- Evaporator: Fin-and-tube heat exchanger.
- Heater: Nickel chromium alloy heating wire.
- Humidifier: Steam humidifier.
- Inner Size (W*H*D in mm): 800*800*800, 1000*1000*1000, 1200*1200*1200, 1500*1500*1500.
- Outer Size (W*H*D in mm): 900*1950*1495, 1050*2000*1445, 1300*2085*1800, 1900*2050*2900.
- Volume: 250L, 500L, 1000L, 2000L.
- Ambient Temperature: +5°C to 35°C.
- Power Supply: 380V AC, 50/60Hz.
- Controller: SANWOOD SH5600 with RS232 port and 7.0-inch controller, USB data export capability.
Catalog excerpts
Environmental Test Chambers Altitude Temperature Chamber Energy Conservation Circuit System Remote network system international standard Environmental Test Chambers Temperature control range Temperature f luctuation Temperature Cooling rate Heating rate Temperature unif ormity Pressure range Depressurization time Normal pressure～1kpa，about 30 mins ； <10kpa/min 20.0%RH ～98.0%RH(work under atmospheric humidity ) Humidity unif ormity Internal material Adopt 2mm thickness stainless steel plate (SUS304) External material Adopt 10mm thickness cold rolled steel plate f ully welded / powder spray ed Heat insulating material 100mm thickness poly urethane plate＋10mm thickness mineral wool Centrif ugal blower France Tecumseh, Germany Bock, Germany Bitzer Air cooling, water cooling Fin - and - Tube Heat Exchanger Nickel chromium alloy heating wire Material / components Humidity control range Humidity Pressure error Pressure recov ery time Inner size(mm)W*H*D Outer size(mm)W*H*D Operating ambient temperature Power supply
