- Shim Plate
Shim Plate
1 / 1 PageView full catalog
Shim Plate
Product catalog summary
Specifications:
- The document provides specifications for slide plates and shim plates, including dimensions and tolerances.
- Nominal widths (W) for slide plates are specified as 48, 75, 100, 125, and 150.
- Material used is SUS304 with specific tolerances for thickness (T) at ±0.01 and ±0.02.
- Instructions for drilling tapped holes (M4) on the wear plate at the folding area to prevent loss of the shim plate.
- Guidance on bending the shim along the folding line and securing it with bolts.
- For shim plates with thicknesses of 0.05 and 0.1, orders are shipped in quantities of 10 per size.
- Single plates can be ordered for shim plates with thicknesses of 0.2 and 0.3.
- Ensure proper drilling and securing of shim plates to maintain functionality and prevent loss.
