System LSI Product Selection Guide
18Pages

^^^^^^ ^^^^^H r w 9 m Օ ^^^^ Samsung Semiconductor, Inc. Product Slection Guide System LSI August 2007

SYSTEM LSI ASIC / FOUNDRY 3 ASIC ORDERING INFORMATION CMOS IMAGE SENSORS LCD DRIVER ICs LCD DRIVER IC ORDERING INFORMATION MOBILE APPLICATION PROCESSORS HDTV/STB PRODUCTS MICROCONTROLLERS 10-14 MICROCONTROLLER ORDERING INFORMATION 15 SERIAL EEPROMS

ASIC/Foundry Solutions SYSTEM LSI ASIC LIBRARY For more information on Samsung's dedicated 300mm logic foundry, go to www.samsung.com/global/business/semiconductor/products/strategicfoundry Specialty I/O Peripherals SSTL2, SSTL18 ARM PrimeCell Peripheral LVDS Samsung Peripheral USB 1.1 MDDR ASIC PROCESS TECHNOLOGY Design Rule 45nm 65nm 90nm Process Technology L(D/R)4LP (=11LP) L6G (=10FS) L(D/R)6LP (=10LP) L(D)9G (=9SF) L(R)9LP (=9LP) Description 45nm Low Power Process (with eDRAM/RFCMOS option) 65nm Generic Process 65nm Low Power Process (with eDRAM/RFCMOS option) 90nm Generic Process...

ASIC Ordering Information SYSTEM LSI ASIC ORDERING INFORMATION S 6 X X X X X X X X - X X X X 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 1. System LSI (S) 12~14. Package Type (14) Packing 2. Large Classification: ASIC (6) - In Case of PKG (12) Package Type A : SDIP C : CHIP BIZ J : ELP N : COB S : SOP W : WAFER (13) Reserved B : BUMP BIZ E : LQFP K : TR Q : QFP T:TQFP X : ETQFP - In Case of TAB / COF (12)(13) Film Type 00~49 -^-TAB 50~99 -^>- COF (14) Revision 3. Small Classification B : STN (Graphic) D : TFT (Mobile) E : OELD T : TCON A : STN (Character) C : TFT (Large) F : TFT (Midsmall) P : PDI...

SYSTEM LSI LCD Driver ICs BW STN GRAPHIC DISPLAY DRIVER IC FOR MOBILE DISPLAYS Part Interface DDRAM Vlcd DC/DC Convert Number Segment Common (Bits) (Bits) VDD (V) (Max V.) (Times) Package S6B0107 64 1 / 1 4.5~5.5 17 S6B0086 80 1 / 4 2.7~5.5 28 S6B0715 100 33 1 / 8 8580 2.4~5.5 15 2~4 Au bump chip/TCP S6B0717 100 55 1 / 8 6500 2.4~5.5 15 2~5 Au bump chip/TCP S6B0718 104 81 1 / 8 9256 2.4~3.6 15 3~6 Au bump chip/TCP S6B0719 160 105 1 / 8 16800 2.4~3.6 15 3~6 Au bump chip/TCP S6B0723 132 65 1 / 8 8580 2.4~5.5 15 2~5 TCP S6B0724 132 65 1 / 8 8580 2.4~5.5 15 2~5 Au bump chip S6B0725 104 65 1 / 8...

LCD Driver IC Ordering Information SYSTEM LSI LCD DRIVER IC ORDERING INFORMATION S6XX1234 X 5 X 9 10 11 12 X 13 X 14 X 15 1. System LSI (S) 11. (14) Packing 2. Large Classification: LDI (6) 12~14. Package Type - In Case of TAB / COF (12)(13) Film Type 00-49^ TAB 50~99^-COF (14) Revision 3. Small Classification - In Case of PKG A : SDIP C : CHIP BIZ J : ELP N : COB S : SOP W : WAFER (13) Reserved B : BUMP BIZ E : LQFP K : TR Q : QFP T : TQFP X : ETQFP A : STN (Character) C : TFT (Large) F : TFT (Midsmall) P : PDI (DUAL) V : Process Vehicle B : STN (Graphic) D : TFT (Mobile) E : OELD T : TCON...

slsi_07_4 table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:6.00pt "Trebuchet MS", sans-serif; } .font1 { font:8.00pt "Trebuchet MS", sans-serif; } .font2 { font:10.00pt "Trebuchet MS", sans-serif; } Application Processors SYSTEM LSI MOBILE APPLICATION PROCESSORS Part Max Memory Boot Multimedia Connectivity Timer/PWM Serial Number Core (Cache) Freq Inteface Option Features Counter Interface DMA Package S3C3410 ARM7TDMI 40MHz ROM/SRAM NOR/ROM LCD I/F WDT, RTC UART/IIC 2-ch 128QFP (4KB) SRDAM 10-bit ADC x 8 8/16-bit TCx5 SIOx2 S3C44B0 ARM7TDMI 66MHz ROM/SRAM...

HDTV/STB Products SYSTEM LSI HDTV/STB PRODUCTS Part Number S3C2800 S5H2000 S5H2010 Product Description Co-Processor for DTV MPEG Decoder DTV MPEG Decoder DTV MPEG Decoder Typical Applications Set top box,HDTV,General Purpose Low-Mid-Range HDTV/STB Low-Mid-Range HDTV/STB Package 208 LQFP 352 TBGA 492 BGA CPU Core ARM920T Uses External S3C2800 CPU Uses External S3C2800 CPU Max Frequency 200MHz 135MHz 135MHz Data Bus (bits) 32 32 32 Serial Interface PCI (32 bits, 33MHz) PCI (32 bits, 33MHz) PCI (32 bits, 33MHz, UART, Smart Card I/O Pins 244 276 I/O Ports 44 General Purpose Interupts (Ext) 34...

slsi_07_4 table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:6.00pt "Trebuchet MS", sans-serif; } .font1 { font:8.00pt "Trebuchet MS", sans-serif; } .font2 { font:10.00pt "Trebuchet MS", sans-serif; } Microntrollers SYSTEM LSI 16-BIT MICROCONTROLLER FAMILY Part Name Package ROM RAM Interrupt Timer/ Serial LCD ADC PWM(1) Max. OSC. Other Kbytes Bytes I/O Pins (Int/Ext) Counter Interface (Seg/Com) (Bit x Ch) (BitxCh) Freq. Vdd (V) Features S3FC11BXZZ-QX8F 100QFP 64 10k 77 8/9 BT/WT/8TCx3 SIO 36/8 10X4 8x1 40MHz 2.0~3.6 MAC1616 S3FC11BXZZ-TX8F 100TQFP S3CC34DXZZ-QX8D...

Microcontroller Ordering Information SYSTEM LSI MICROCONTROLLER ORDERING INFORMATION X X X X 14 C: 8 K: 20 O: 32 - TQFP A: 128 X: 100 - TEBGA X: 492 - FBGA A: 337 D: 160 G: 285 L: 400 Q: 289 - SBGA A: 432 - WAFER 0: None 14. Packing X 15 X 16 H: 16 M: 24 1X71X8 I: 18 N: 28 1 2 3 4 5 6 7 8 9 10 11 12 1. System LSI (S) 2. Large Classification: Microcontroller(3) 12. Package Type 3. Small Classification A: SDIP B: LGA C: CHIP BIZ D: DIP C: MASK ROM E: EVA-CHIP E: LQFP F: WQFP F: FLASH P: OTP G: BGA H: CSP 3: MCP J: BQFP K: UELP 4. Core L: ELP M: QFPH N: COB P: PLCC 1: 51 4-bit 2: 32-bit ARM9...

SYSTEM LSI EEPROMs SERIAL EEPROMS Write Cycle Part Number Density (bit) Write Protection Vopr (V) Time (Max) Interface Package S524A40X20-RC70 2K by Hardware & Software 1.8 ~ 5.5 5 ms S524A40X21-DC90 S524A40X21-SC90 S524A40X21-SC70 / S524A40X41-DC90 4K by Hardware 1.8 ~ 5.5 5 ms I2C BUS S524A40X41-SC90 S524A40X41-SC70 S524A60X51-DC90 16K by Hardware 1.8 ~ 5.5 5 ms S524A60X51-SC90 S524A60X51-SC70 DC90 = 8DIP SC90 = 8SOP S524A60X81-DC90 S524A60X81-SC90 S524A60X81-SC70 8K by Hardware 1.8 ~ 5.5 5 ms SC70 = 8SOP (T&R) RC70 = 8TSSOP (T&R) S524A90X91-DC90 32K by Hardware 1.8 ~ 5.5 5 ms...

Samsung's broad line of logic products features System-on-Chip and ASIC solutions manufactured using some of the world's most advanced processes. Samsung's mobile application processors, ASICs, microcon-trollers, image sensors and other System LSI products are found in a wide range of digital devices such as some of today's most coveted handhelds. Samsung also offers custom logic chip design and production in a dedicated foundry that employs the latest technologies. For more information, visit our website: www.usa.samsungsemi.com Disclaimer: The information in this publication has been...
