Mobile Memory

Product catalog summary

Samsung Mobile Memory Overview

Mobile DRAM
Samsung Mobile DRAM is engineered to enhance performance and battery life in mobile electronics. It features low power consumption with supply voltages as low as 1.2V and advanced technologies like Temperature Compensated Self Refresh (TCSR) and Deep Power Down (DPD). It supports high density up to 4Gb and high performance with interfaces up to 533MHz LPDDR2. These DRAMs are ideal for mobile phones, MP3 players, GPS devices, and digital cameras.

Multi-Chip Packages (MCP)
MCP technology stacks multiple memory dies into a single package, saving board space and improving system performance. Samsung's MCPs can include up to 16-chip stacks, utilizing technologies like wafer-thinning to achieve minimal thickness. The moviMCP™ combines eMMC and Mobile DRAM for multimedia applications, offering significant space and power savings.

eMMC (Embedded Multimedia Card)
Samsung's eMMC, or moviNAND™, integrates high-density MLC NAND Flash with an MMC controller, providing a scalable and cost-effective solution. It supports up to 64GB with a data transfer rate of 64MB/s, using industry-standard interfaces and packaging. This makes it suitable for the growing demand in smartphones and tablets, driven by multimedia content.

Future Trends
The smartphone market is expected to grow significantly, driven by multimedia content and network advancements. Samsung's memory solutions, including eMMC, are positioned to support this growth by enhancing the transfer and storage of large multimedia files.

Catalog excerpts

Samsung Mobile Memory Mobile DRAM Performance and battery life are the key metrics upon which mobile electronics are measured. Samsung Mobile DRAM memory is optimized to deliver on both. Mobile Synchronous DRAMs - low power, double data rate (LPDDR1, 1.8V and LPDDR2, 1.2V) - are designed to consume less power than standard synchronous DRAM, and Samsung's save power by adopting advanced circuit architectures that translate into longer battery life. The future of Mobile DRAM Particularly well suited for today's high-performance, battery-sensitive mobile electronics, Samsung Mobile DRAM can be found...

Open the catalog to page 2

MCP (Multi-Chip-Package) As the popularity of handheld electronic devices continues to expand, the memory solution of choice for mobile product designers has become Multi-Chip Package technology. MCPs are stacks of discrete memory die made into single packages. Samsung, the leader in MCPs, offers a broad selection based on leading-edge Flash, Mobile DRAM, SRAM, and now even PRAM technology. Samsung manufactures all the memory chips used in MCPs ՗ DRAM, SRAM, Flash and PRAM Samsung has developed MCP technology for 2-to 16-chip stacks Օ For its 16-die MCP, Samsung created a new wafer-thinning...

Open the catalog to page 3

eMMC (Embedded Multimedia Card) Samsung eMMC, also known as moviNAND, is an embedded memory card comprised of high-density MLC NAND Flash and an MMC controller in a small BGA package. The use of industry-standard packaging, interface and firmware makes Samsung's moviNAND easy to use, enabling: ٕ Faster time to market Common application for use as both embedded and external flash memory Օ Cost-effective, performance scalable solution using MLC NAND and MMC controller elements The future of mobile multimedia The global Smartphone market is forecast to grow over 22% annually from 2009 to 2015,...

Open the catalog to page 4
