Three-phase hybrid solar inverters from 4 to 12 kW EQUINOX2 HT: Versatility with three-phase renewable energy The EQUINOX2 HT three-phase hybrid solar inverters retain the features of the single-phase EQUINOX2 HSX range, for application in installations with 3 x 380 V / 3 x 400 V. As such, we can continue to speak of maximum versatility. The EQUINOX2 HT has up to six operating modes: general or automatic mode, peak load mode, isolated mode, UPS mode, economy mode (allowing users to program battery charging/discharging and usage times via the app, web or display) and a mode for operation without batteries. The mode for operation without batteries ensures that photovoltaic energy is still available even when the batteries are in poor condition, disconnected for replacement or even if the user decides to acquire them at a future date and initially operates the system without storage. Although this function is usually temporary, it helps to enhance the already comprehensive availability of the installation. The UPS function is also of particular note. Thanks to technological advances, our inverter boasts a transfer speed of just 10 ms, thereby ensuring the continued operation of connected devices in the event of an unexpected power outage and without requiring any manual intervention. The EQUINOX2 HT offers a high degree of independence from the electricity network, with a three-phase installation. It is the ideal solution for facilities with low- and medium-power equipment, such as workshops, small production facilities, food retailers, catering establishments, etc.

Performances ∙ Input current adapted for high-performance panels. ∙ Two 13 A MPPT trackers, without current penalty by the battery connection. ∙ Very low start-up voltage of 150/180 VDC (depending on the model) and the ability to charge the batteries even with low solar radiation. ∙ Admits +60% of input power in DC, above the nominal level. ∙ Battery transfer time of less than 10 ms. ∙ Option of delivering 10% more power in addition to the nominal. ∙ Fast charging/discharging of up to 25 A. Fast battery charging (1 hour). ∙ Back-up of up to 100% of nominal power, in battery mode. ∙ Wide battery...

Range MODEL MAXIMUM MAXIMUM DC RATED POWER APPARENT INPUT POWER (kW) OUTPUT POWER (kW) OUTPUT CURRENT Batteries selection POWER INVERTER BASE CODE CAPACITY RATED VOLTAGE BATTERY CODE RATED(kWh) (V) Positive photovoltaic input terminals. Negative photovoltaic input terminals. Main communication port (communication module connection). Auxiliary communication port (optional). AC / mains terminal. DC disconnector. Output connection for critical loads. Connection port for current metering. Communication port with batteries. Positive battery connection terminal. Negative battery connect

REF. JJ142A01 CODE 401AB001386 ED. OCTOBER 2023 - SOLAR INVERTERS Technical specifications INPUT DC MPPT voltage range (VDC) Input maximum current per tracker (A) OUTPUT Power factor Network voltage Voltage ranges Max. total harmonic distortion (THD) Maximum performance Battery type Voltage range Maximum charge/discharge current 3 LED states, LED bar for battery level, OLED display Inverse polarity DC, Residual Current, DC disconnector, Over-voltage, Over-temperature, Differential, Islanding operation, AC short-circuit, Over-voltage AC Over-voltage protection category GENERAL Contamination level...
