CLASS I HYDROCARBON SEPARATORS BY COALESCENCE, SEPARATION CHAMBER WITH ADJUSTABLE SKIMMER AND COMPACT STORAGE TANK
1Pages

Page 2 Catalogue- Hydrocarbon Separators, May 2009 Ref: 7-1 Models and data are subject to change Carrera Toledana, 33 28500 Arganda (Madrid) TEL: +34 918 70 00 15 FAX:+34 918 70 05 18 e-mail: international@salher.com 5 www.salher.com LENGTH Ø M Ø M Ø M CS ØT2 Ø CE Air vent 1" ØT1 Skimmer Skimmer Regulator Solids settling Coalescence plates 390 mm Separated oil Separated oil tank Oil outlet Registration plate CLASS I HYDROCARBON SEPARATORS BY COALESCENCE, SEPARATION CHAMBER WITH ADJUSTABLE SKIMMER AND COMPACT STORAGE TANK MODEL: CHC-SH-L-X-K Function: • Mineral oil, grease and hydrocarbon separation from water, by density difference; it does not separate emulsified oils and Hydrocarbon. NOTICE: For organic oil and greases removal (from vegetables and animals) please refer to: Grease Separator Chamber. Characteristics: • Manufactured by Salher, Model CHC-SH-L-X-K Class I, outlet smaller than 5 ppm. • Designed according to DIN 1999 and UNE 858 Standards. • Made of Fiberglass Reinforced Polyester (FGRP) with orthophthalic resin. • Oil separation, solids settling and oil storage chamber. • Coalescence plates with a large specific surface: 340m2/m3. • Adjustable skimmer to collect separated oil and hydrocarbon. • Built-in chamber to store separated oil. Oil extraction through upper manhole. • PVC inlet and outlet pipes. Manhole with air vent to install a ventilation pipe. • In option: hydrocarbon and oil detection alarm. FLOW [L/S] Total Capacity [Liters] Capacity K. [Liters] Capacity S-B. [Liters] Capacity A [Liters] [mm] L [mm] R1-2 [mm] FLOW [L/S] 3 1.800 600 600 600 1.000 2.480 110-125 2x500 5 3.200 1.900 600 700 1.200 3.340 125-160 620 7 4.500 2.400 1.200 900 1.400 3.200 125-160 620 10 7.000 3.000 2.250 1.750 1.400 4.900 160-200 620 15 11.000 4.000 4.250 2.750 1.700 5.180 160-200 620 20 14.500 6.000 5.000 3.500 2.000 5.000 200-250 620 25 18.000 8.000 5.500 4.500 2.000 6.120 200-250 620 FLOW (L/S) CAPACITY (L) SIZE (MM) FOR LARGER FLOWS PLEASE CONSULT US T.1 ENTRY S. SETTLING TANK A. OIL TANK B. SEPARATOR K. STRIP SEPARATOR T2. EXIT . DIAMETER L. LENGHT
