OmniLip, PTFE Rotary Lipseals
16Pages

Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1Seal Nomenclature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2Materials/How To Order Seals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3OmniLip > Seals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4DynaLip > ٮ Lip Seal. . . . . ....

*See page 3 for material selection +32 (3) 4582828 >

ٮ Part Number Example: > NOTE: If it is not clear which seal design is appropriate,pleasecomplete the Application Data Form on Page 11 and fax ormail to the attention of Saint-Gobain Performance Plastics Sealing Technology Center. *(Always XX for DynaLip > which do not have metal support cases.) > MaterialCode Name andDescription Fluoroloy > ή SL Standard material for secondary elements and dust excluders. Good general purpose material for heatand wear resistance. Performs well on shaft surfaces with moderate hardness. Good in both lubricated and non-lubricated medias (good wear...

Series 10 > Series 11 Series 10 and 11 are economical OmniLip > ٙ seal designs employed in a wide range ofapplications. They are used in lubricated and non-lubricated environments. They can be used at shaft speeds to 25 m/s in lubricated media and pressures to 0,7 MPa. Typical applications are: gear boxes and environmental seals. Series 30 and 31 incorporate a threaded sealing lip which pumps the media away from theseal. These designs should only be used in lubricating media. These designs offer long life and positive sealing at shaft speeds to 30 m/s. They should not be used for pressures...

Seal TypeFor TemperaturesSeal TypeFor NORMAL Temperatures EXTREME Series 13 > Series 14 Series 13 and 14 are economical DynaLip > ή designs employed in a wide range of applications. They are used in lubricated and non-lubricated environments. They can be used at shaft speeds to 25 m/s in lubricated media and pressures to 0,5 MPa. Typical applications are: gear boxes and environmental seals. > Series 23 > Series 24 Series 23 and 24 offer improved sealing of gasses and abrasive media due to their higher lip load.They also offer additional runout capability. They can operate at speeds and...

3,0 mmMAX. 3,0 mmMAX. SEALINGLIPEXTENSION OmniLip > ՙ seals incorporating two sealing lips, or a dust excluder, mayhave seal lip extensions as shown. This must be considered when designing a seal gland. >

are must be taken not to damage the sealing lip duringthe installation of the shaft through the seal. It is mucheasier to install the seal if the shaft enters the seal fromthe atmosphere side. If this is not possible, or if the seal must be installed on a shaft which has a keyway or splines, please contact the factory. We can help with the design and manu- facture of simple tooling to assure that the seal is installed without damage. OmniLip > seals and DynaLip > ٮ sealsshould be pressed into the bore evenly. A tool, as shown below, simplifies this operation. > Care is essential in the...

aint-Gobain Performance Plastics has long been known foradvanced sealing solutions. We have more than threedecades of experience with PTFE, plus a full range of high performance plastics and elastomers.Our specialty is engineered sealing devices includingOmniSeal +32 (3) 4582828 . > , DynaLip > ٮ , andOmniSeal > seals, we bring you the advantages of ourlatest production technology for timely and cost-effective answers to your most critical sealing applications.We welcome the opportunity to help you achieve thebest technical and economical solutions for your sealing requirements. For a...
