DOUBLE INSULATION MODULAR BOX IP 66 · Envolventes fabricados en poliéster reforzado con fibra de vidrio moldeado en caliente, de color gris claro RAL 7035. · Self-extinguishing materal, demonstrated through a 960º glow-wire test in accordance with UNE-EN 60695-2-10 (IEC 60695-2-10) regulations. · IEC62208 certification for empty enclosures. Suitable for indoor or outdoor use. IP-66 protection rating in accordance with UNE-EN 60529 regulation. · IK-10 impact resistance in accordance with EN 50102 (IEC 62262) regulation. · Models with high and low doors, either opaque or transparent. Sealable 16mm screws. · Customization options for color, machining, installation accessories, locks, and laser printing for company logos. Polyester or metallic mounting plates may be attached as well. · Over 10 years of maintenance-free lifespan under standard environmental conditions. Height x Width x Depth Empty standard box with tall tranparent door

DOUBLE INSULATION MODULAR BOX IP 66 Polyester box with transparent door 540 x 360 x 205mm Packaging 17 Units per pallet 120 x 80 cm (Height 205cm) Fastener characteristics Nº of fastening screws Environmental performance Minimum Temperature IP rating against water IEC-60529 Maximum Temperature IK rating against impact IEC-62262 Electrical performance Installation & mounting system Nominal tension on direct current up to: Nominal tension on alternating current up to:: Maximum power dissipation DT=40ºC (wall installation)
