Cables for Railway Technology

Cables for Railway TechnologyContent page In case that you don't find a suitable cable for your special application, we are always prepared to design a cable according to your individual construction requirements.

Cables for Railway TechnologyFire protection requirements EN 45545-2 Extract from EN 45545-2 table 5 Requirement set R15 (EL1A) for the respective hazard levels

SAB Bröckskes GmbH & Co. KG Customised connection solutions quality & innovation since 1947 For three generations, B Bröckskes stands for customised connection solutions in cable and measurement technology. Having grown from a one-man business, we now employ approx. 550 people and realise more than 1,500 customised special constructions every year. Our strength lies in the development and production of special solutions that are perfectly tailored to our customers‘ requirements. nership. Our products are use in more than 100 countries and fulfil the highest quality standards, certified in accordance...

SAB Bröckskes GmbH & Co. KG Family business in its third generation 1947 - 1989 Peter Bröckskes sen. Visionary with a thirst for action: Peter Bröckskes Senior was a successful company founder with determination, hard work and a pioneering spirit. He started in 1947 as a one-man alarm system company and continuously developed new products. In the course of his entrepreneurial career, he overcame setbacks and repeatedly managed to recognise gaps in the market and develop new products. 1989 - 2017 Peter Bröckskes After studying business administration, Peter Bröckskes joined the company in 1980...

jitwchink- nmtt Good results are not determined by luck and chance, but rather by years of experience, sophisticated technology, technical expertise and the ability to develop and test new things and improve existing ones. We are constantly developing and refining our products in order to round off our range of services and consolidate and expand our position in the market. With our extensive testing and inspection machines, we ensure that our products are intensively tested and checked before they are ready for the market. Further tests are often carried out in cooperation with our customers...

Cables for Railway Technology Selection table Fire performance Temperature range fixed laying* Halogenfree from CATLine CAT 5e R flex CATLine CAT 6A R flex CATLine CAT 7A R flex CATLine CAT 5e R CATLine CAT 6A R CATLine CAT 7A R single conductor multi-core cable screened wiring cable data cable control cable Ethernet cable USB 3.0 resp. 2.0 cable cross linked type tested acc. to EN 45545-2 acc. to EN 50306-1 + EN 50264-1 are fulfilled. Development of HCl is < 0,5% acc. to DIN EN 50267-2-1. pH-value is > 4,3 acc. to DIN EN 50267-2-2. Conductivity is < 10,0 µS/mm acc. to DIN EN 50267-2-2. Fluoric...

» flame retardant and self-extinguishing » very good stripping » flexible » fulfils fire protection requirements R15 (EL1A) acc. to EN 45545-2 for hazard levels HL1-3 » flame retardant acc. to UN/ECE R118 » PFAS free Cables for Railway TechnologySfiBIX® A 146 FRNC SfiBIX® A 156 FRNC warn BROCKSKES ■ D-VIERSEN ■ SfiBIX* A 146 FRNC 300/500 V 0,5 mm2 C marking example: SflB BROCKSKES ■ D-VIERSEN ■ SfiBIX® A 146 FRNC 300/500 V 0,5 mm2 C Construction: Technical Data: Conductor: bare copper strands Nominal voltage: SfiBIX* A 146 FRNC: SfiBIX* A 156 FRNC: Temperature range Outstanding features:» halogen-free...

Cables for Railway TechnologySflBIX® R 600 FRNCSRBIX® Rail Control with numbered cores marking example: SOB BROCKSKES ■ D-VIERSEN ■ SfiBIX® R 600 FRNC 12 x 1,5 mm2 C Conductor: bare copper strands Insulation: special SfiBIX” Colour code: black cores with consecutive numbers acc. to EN 50334 + VDE 0293-334, green-yellow earth wire from 3 cores Stranding: in layers Sheath material: special SfiBIX” Sheath colour: grey (RAL 7000) Outstandiung features: » flame retardant and self-extinguishing » fulfils fire protection requirements R15 (EL1A) acc. to EN 45545-2 for hazard levels HL1-3 » flame retardant...

SRBIX® Rail Control with numbered cores and overall copper screen 3KES • D-VIERSEN • SfiBIX® R 638 FRNC 5 x 1,5 mm2 C marking example: SOB BROCKSKES • D-VIERSEN • SfiBIX® R 638 FRNC 5 x 1,5 mm2 c Construction: Technical Data: Conductor: bare copper strands acc. to IEC 60228, VDE 0295, class 5 Insulation: special SfiBIX” Colour code: black cores with consecutive numbers Min. bending radius fixed laying: 5 x dflexible application: 10 x d Nominal voltage: Uo/U 300/500 V Testing voltage: core/core 3000 V acc. to EN 50334 + VDE 0293-334, green-yellow earth wire from 3 cores Stranding: in layers Wrapping:...

Cables for Railway Technology S R 605 FRNC S Rail Data CKSKES · D-VIERSEN · S R 605 FRNC 32 x 0,5 mm² C marking example: S BRÖCKSKES · D-VIERSEN · S R 605 FRNC 32 x 0,5 mm² C bare copper strands with reference to IEC 60228, VDE 0295, class 5 Peak operating voltage: Testing voltage: Colour code: Sheath material: Min. bending radius fixed laying: flexible application: Sheath colour: Temperature range fixed laying: flexible application: Outstandiung features: » » » » fulfils fire protection requirements acc. to NFPA 130 section 8.6.7.1.1.1 and section 12.2.1 (1) no flame propagation flame retardant...

Cables for Railway TechnologySBBIX® R 605 FRNC SfiBIX® Rail Data D-VIERSEN • SflBIX® R 605 FRNC 32 x 0,5 mm2 C FREE marking example:SOB BROCKSKES • D-VIERSEN • SfiBIX® R 605 FRNC 32 x 0,5 mm2 c item no. NFPA 130 / FT4 only up to outer-0 < 13 mm. Other dimensions and colours are possible on request.

Cables for Railway TechnologySRBIX® R 615 FRNC SRBIX® Rail Data with overall copper screen SEN • SflBIX® R 615 FRNC 5 x 0,5 mm2 C marking example: SOB BROCKSKES • D-VIERSEN • SfiBIX® R 615 FRNC 5 x 0,5 mm2 c Conductor: bare copper strands with reference to IEC 60228, VDE 0295, class 5 Insulation: special SRBIX” Colour code: with reference to DIN 47100 Wrapping: foil Screen: tinned copper braiding Sheath material: special SRBIX” Sheath colour: grey (RAL 7032) Outstandiung features: » halogen-free » good EMC characteristics » no flame propagation » flame retardant and self-extinguishing » fulfils...
