Rudolph Research Analytical
AUTOPOL V PLUS Polarimeter

AUTOPOL V PLUS Polarimeter

Product catalog summary

Overview
The document presents two polarimeter models, Autopol® V and Autopol® V PLUS, designed for pharmaceutical applications. These instruments are noted for their compliance with industry standards and advanced features that cater to global pharmaceutical companies.

Specifications and Features

Autopol® V: Offers electronic cooling and heating (TempTrol™) from 15°-35°C, six standard wavelengths, and 21CFR11 compliance for secure data storage. It includes a domestic 3-year warranty and a 20-year support guarantee.
Autopol® V PLUS: Includes all features of the Autopol® V with additional acid resistance, a NIST traceable quartz plate with three rotations, and enhanced connectivity options such as USB ports and Ethernet for network connections.

TempTrol™ System
The TempTrol™ system allows precise temperature control without the need for a water bath, meeting USP and European Pharmacopoeia requirements for optical rotation measurements. It provides push-button temperature control and automatic calibration.

Technical Specifications

Both models measure optical rotation, specific rotation, and concentration with high accuracy and reproducibility.
They feature automatic wavelength selection, a wide temperature range, and robust data storage capabilities.
The Autopol® V PLUS offers additional features such as a larger display, enhanced acid resistance, and improved connectivity options.

Conclusion
The Autopol® V and V PLUS are robust solutions for pharmaceutical labs, offering precise measurements, compliance with regulatory standards, and advanced features for ease of use and connectivity.

Catalog excerpts

For Pharmaceutical Applications Two Great Solutions The Autopol® V and Autopol® V PLUS TECHNICAL BUL LETIN 928 *Emmes Survey The brand of polarimeter used in more U.S. labs than any other.*

Open the catalog to page 1

The Industry Standard Polarimeter The Autopol V has the validation tools and features to satisfy today’s global pharmaceutical companies, including: instrument level 21CFR Part 11 compliance, NIST traceable calibration standards and a global list of installations. Rudolph Research has thousands of satisfied customers who praise the Autopol V’s quality, accuracy and reproducibility. Autopol V Standard Features And Accessories • TempTrol™ – Electronic cooling & heating from 15°-35°C • Six Standard Wavelengths: 365nm, 405nm, 436nm, 546nm, 589nm and 633nm • 21CFR11 Compliance: Electronic Signature...

Open the catalog to page 2

The Autopol V and V Plus Use Rudolph’s Exclusive TempTrol™ Electronic Temperature Control System The USP <781> requires optical rotation measurements at 25°C ± .5°C (unless another temperature is specified). The European Pharmacopoeia requires optical rotation measurements made at 20° ± .5°C (unless another temperature is specified). Whatever your temperature control needs are, the Autopol® V and the Autopol V Plus’ exclusive TempTrol™ System (Patent No. 2778542) makes your measurement in a few minutes without a waterbath or any type of water circulation. The TempTrol™ System allows push-button...

Open the catalog to page 3

Rudolph Research Analytical 55 Newburgh Road, Hackettstown, NJ 07840 USA • Phone: 973-584-1558 • Fax: 973-584-5440 • E-mail: [email protected] • Internet: www.rudolphresearch.com 10/09 200 Specifications Features Autopol® V Autopol® V PLUS Measuring Mode: Optical Rotation, Specific Rotation, Concentration & User-defined Scales Optical Rotation, Specific Rotation, Concentration & User-defined Scales Measuring Scale: Degrees Arc, % Concentration Degrees Arc, % Concentration Measuring Range: ±89° Arc Optical Rotation, ±999.99° Arc Specific Rotation and 0-99.9% Concentration ±89° Arc Optical...

Open the catalog to page 4
