VERSIONS PR5D - 5 steps, 96x96mm housing Օ PR5D - 7 steps, 96x96mm housing PR6D - 8 steps, 144x144mm housing Օ PR-6D - 12steps, 144x144mm housing DESCRIPTION Digital microprocessor power factor controller. Օ 3 digit 7 segment LED display. 4 key membrane keypad. Օ TTL-RS232 serial interface for set-up and automatic testing via PC (Personal Computer). Internal temperature sensor. INSTALLATION Օ Install the controller according to wiring diagrams given on the last pages of this instruction manual. The CT(Current Transformer) must be connected to the free phase to supply the unit as indicated in...

Program Function Range Default P.01 CTPrimary Off ...10.000 Off P.02 Smallest kvar step 0.10 ...300 1.00 P. 03 Rated capacitor voltage 80 ... 750 V 400 V P.04 Reconnection time 5 ... 240sec. 15 sec. > n(1) Step n coefficient Setting of required cos Џ 0.80 Ind ..0.80 Cap 1 Ind value (2) >

P.05- Sensitivity The sensitivity is a coefficient, which consents to adjust the controller tripping speed. Alow sensitivity provi-des for faster adjustments but with a greater number of switchings. With high sensitivity, the adjustment is slo- wer but with fewer switchings.The sensitivity value corresponds to the time in which the controller is delayed before taking action to a reac-tive power demand equivalent to the smallest step. For higher power demands, the time will be quicker accor- ding to the criteria of inverse proportion. Example: For 60 s/step, set In this case with the smallest...

Led Function Pressing Pressing V RMS Voltage MAX voltagevalue A RMS current MAX currentvalue Steps requiredto achieve the set-point > kvar kvar required to reach set-point Σ kvar(system kvar) > Week F.P. Average weekly power factor Real powerfactor > (1) CURR% Capacitor overlo- ad % (2) MAX overloadvalue Overloadevent counter Electric panel tem- perature (3) TEMP MAX tempera-ture value Unit of mea-sure C or аF > SETCOS Decrease SETCOS Increase SETCOSf value ϕ Required cos ϕ φ value > AlarmCode Description Enabling Alarm relay Disconnection Trippingdelay A01 Under compensation >

CODE TYPE PR-5D REG05DPR5500000 PR-5D-5 REG07DPR5500000 PR-5D-7 PR-5D(96 x 96) IMPORT ANT NOTE: DEVICE PRE-PROGRAMMED IN F ACT OR Y In this case during the system installation and once the controller is powered up, the display will view a flas- hing (Current Transformer). By pressing CT and , the CT primary can be directly set.Once programmed, press Caution: if the automatic set up is executed, all the data programmed in factory will be deleted. MAN/AUT to confirm. The unit will store the setting and directly restart in automaticmode. PR-5D7 wiring diagrams -8- >

CODE TYPE PR-6D REG08DPR6500000 PR-6D-8 REG12DPR6500000 PR-6D-12 PR-6D(144 x 144) IMPORT ANT NOTE: DEVICE PRE-PROGRAMMED IN F ACT OR Y In this case during the system installation and once the controller is powered up, the display will view a flas- hing (Current Transformer). By pressing CT and , the CT primary can be directly set.Once programmed, press Caution: if the automatic set up is executed, all the data programmed in factory will be deleted. MAN/AUT to confirm. The unit will store the setting and directly restart in automaticmode. PR-6D12 wiring diagrams -9- >

Rear view PR-5D Overall dimensions and panel cutout PR-5D -10- >

Rear view PR-6D Overall dimensions and panel cutout PR-6D -11- >

CONNECTION DIAGRAMS CHILERTR DNAChile, S.A. La Estera n 668 Panamericana Norte. Km 17 Loteo Valle Grande - Lampa, CHILE Tel.: 56 2 328 44 00 Fax: 56 2 738 69 11 e-mail:[email protected] Gavilanes, 11 Bis Pol. Ind. Pinto-Estaciڳn 28320 PINTO (Madrid) Tel.: 34 91 691 66 12 Fax: 34 91 691 22 57 SPAIN RTR Energa, S.L. > RTR Energa S.L. keeps the right to modify in any form or by any means all the information published in this catalogue withoutprior notice. Any accepted material to be returned, will be paid in origin. If a devolution is produced by any cause NOT imputable to RTR Energa S.L. the total...
