5/2, 3/2 SPOOPET DESIGN NAMUR SOLENOID VALVE Specifications are subject to change without notice. 3 . . . . . . . .Quick . . . . . . . . . Voltage, current and enclosure can be changed by replacing solenoid without affecting performance of the valve. Easily servicable. Body material Aluminium, Brass and SS 316. Life 60 million cycles. Fast acting upto 1000 cycles per minute. Exhaust ports can be blocked for speed regulation. Can be supplied with NAMUR 2,3 and 4 port configuration. Exhaust for faster operation of the Actuator. Spoopet design offering advantage of spool and poppet designs....

Open the catalog to page 3

4 Specifications are subject to change without notice. 5/2, 3/2 SPOOL DESIGN NAMUR SOLENOID VALVE . .Best suited for clean environment. .O rings and fasteners to mount solenoid valve on the actuator are provided. .Temperature -- 20 ºC to 70 ºC. .PTFE seals. .Suitable for dry or lubricated air filtered to 50 mm .Voltage, current can be changed by replacing solenoid without affecting performance of the valve. .Manual override provided. Low cost economical solution. 3/2 POPPET DESIGN NAMUR SOLENOID VALVE .Poppet design. .Manual override provided as standard. .Voltage, current and enclosure can...

Open the catalog to page 4

Specifications are subject to change without notice. 5 SOLENOID VALVE WITH PORTS IN THE BODY 2/2, 3/2 DIRECT ACTING SOLENOID VALVE Orifice : 0.8 mm to 10 mm Pressure : Vacuum to 150 bar Body Material : Aluminium, Brass, Stainless Steel Type : 20101, 20201, 30125, 30126, 30308, 30309, etc. Orifice : 6 mm to 50 mm Pressure : 0 to 70 bar Actuation : Internal / External Pilot Body Material : Aluminium, Brass, Stainless Steel Type : 51400, 57400, 51432, 57408, 31119, 31120, 33101, etc. 3/2, 5/2 PILOT OPERATED SOLENOID VALVE 2/2 DIAPHRAGM OPERATED SOLENOID VALVE 2/2 PISTON OPERATED SOLENOID VALVE...

Open the catalog to page 5

30106 1 2 4 3 5 .. NC 0 20 10 8 6 P6 8 30106LW 1 2 4 3 5 .. NC 0 16 8 4 P2 2 30106IS 1 2 4 3 5 .. NC 0 8 0.4 30306 3 2 4 3 5 .. UNI 0 11 7 4 P6 8 FLUID CONTROL SYSTEM FEATURES . ON / OFF and Control duty. . Low cost economical model . High pressure upto 110 bar available. . Dust caps provided on exhaust ports Ideally suited for spring return actuator on 6 Specifications are subject to change without notice. 3/2 DIRECT ACTING ON / OFF / REGULATING, NAMUR SOLENOID VALVE Power (Watt) IS CKT AC DC Port Connection Valve Type Op. Mode Min. Op. Pr. (bar) Max. Op. Pr. (bar) 1.0 1.2 1.8 2.2 2.5 0.5...

Open the catalog to page 6

Specifications are subject to change without notice. 7 OUTLET PORT CONFIGURATION AS PER NAMUR II X DO NOT SPECIFY CODE IF OPTED VALVE CODE + SOLENOID CODE ORDERING OPTION VALVE CODE SOLENOID CODE TYPE SUFFIX ORIFICE PORT CONNECTION VOLTAGE CURRENT SOLENOID ENCLOSURE BODY AND INTERNALS MATERIAL APPROVAL MANUAL OVERRIDE INSULATION SEAL SPECIAL VERSION . Refer to page 6 for option of Body and internals material, manual override and seals. . Refer to page 38 and 39 for options of voltage, current, solenoid enclosure, approval, insulation and special version. . Refer to page 38 for ordering...

Open the catalog to page 7

Specifications are subject to change without notice. 9 DIMENSIONS OUTLET PORT CONFIGURATION AS PER NAMUR II X DO NOT SPECIFY CODE IF OPTED VALVE CODE + SOLENOID CODE ORDERING OPTION VALVE CODE SOLENOID CODE TYPE SUFFIX ORIFICE PORT CONNECTION VOLTAGE CURRENT SOLENOID ENCLOSURE BODY AND INTERNALS MATERIAL APPROVAL MANUAL OVERRIDE INSULATION SEAL SPECIAL VERSION FLUID CONTROL SYSTEM Note : For 50/60 Hz operating current select 'RC' from special version. For size I solenoid enclosure 15, 16, 19, 15CO, 16CO,19CO, 36, 37, 39, 36CO, 37CO, 39CO. For size III solenoid enclosure 15, 16, 19, 15CO,...

Open the catalog to page 9

Specifications are subject to change without notice. 11 DIMENSIONS OUTLET PORT CONFIGURATION AS PER NAMUR II VALVE CODE + SOLENOID CODE ORDERING OPTION VALVE CODE SOLENOID CODE TYPE SUFFIX ORIFICE PORT CONNECTION VOLTAGE CURRENT SOLENOID ENCLOSURE BODY AND INTERNALS MATERIAL APPROVAL MANUAL OVERRIDE INSULATION SEAL SPECIAL VERSION X DO NOT SPECIFY CODE IF OPTED FLUID CONTROL SYSTEM For size I solenoid enclosure 15, 16, 19, 15CO, 16CO,19CO, 36, 37, 39, 36CO, 37CO, 39CO. For size III solenoid enclosure 15, 16, 19, 15CO, 16CO, 19CO, 36, 37, 39, 36CO, 37CO, 39CO, 66, 67, 68, 71, 72 & 73. For...

Open the catalog to page 11

Specifications are subject to change without notice. 13 DIMENSIONS OUTLET PORT CONFIGURATION AS PER NAMUR II X DO NOT SPECIFY CODE IF OPTED VALVE CODE + SOLENOID CODE ORDERING OPTION VALVE CODE SOLENOID CODE TYPE SUFFIX ORIFICE PORT CONNECTION VOLTAGE CURRENT SOLENOID ENCLOSURE BODY AND INTERNALS MATERIAL APPROVAL MANUAL OVERRIDE INSULATION SEAL SPECIAL VERSION . Refer to page 12 for option of Body and internals material, manual override and seals. . Refer to page 38 and 39 for options of voltage, current, solenoid enclosure, approval, insulation and special version. . Refer to page 38 for...

Open the catalog to page 13

FEATURES FLUID CONTROL SYSTEM 14 Specifications are subject to change without notice. 5/3 DIRECT ACTING ON / OFF / REGULATING NAMUR SOLENOID VALVE ?Air or power failure to retain. ?Low cost alternative to 5 port valve. ?Ideally suited for operating double acting rotary actuator connected to ball or plug valve for on/off, Control duty cycle. ?Solenoid can be operated directly or through PID controller Power (Watt) IS CKT AC DC Port Connection Valve Type Op. Mode Min. Op. Pr. (bar) Max. Op. Pr. (bar) 1.0 1.2 1.8 2.2 2.5 0.5 0.7 1.4 2.5 3.5 INLET OUTLET OUTLET EXHAUST EXHAUST 1/8 1/4 3/8 1/2...

Open the catalog to page 14

Specifications are subject to change without notice. 15 OUTLET PORT CONFIGURATION AS PER NAMUR II X DO NOT SPECIFY CODE IF OPTED VALVE CODE + SOLENOID CODE ORDERING OPTION VALVE CODE SOLENOID CODE TYPE SUFFIX ORIFICE PORT CONNECTION VOLTAGE CURRENT SOLENOID ENCLOSURE BODY AND INTERNALS MATERIAL APPROVAL MANUAL OVERRIDE INSULATION SEAL SPECIAL VERSION . Refer to page 14 for option of Body and internals material, manual override and seals. . Refer to page 38 and 39 for options of voltage, current, solenoid enclosure, approval, insulation and special version. . Refer to page 38 for ordering...

Open the catalog to page 15

Specifications are subject to change without notice. 17 DIMENSIONS OUTLET PORT CONFIGURATION AS PER NAMUR II X DO NOT SPECIFY CODE IF OPTED VALVE CODE + SOLENOID CODE ORDERING OPTION VALVE CODE SOLENOID CODE TYPE SUFFIX ORIFICE PORT CONNECTION VOLTAGE CURRENT SOLENOID ENCLOSURE BODY AND INTERNALS MATERIAL APPROVAL MANUAL OVERRIDE INSULATION SEAL SPECIAL VERSION . Refer to page 16 for option of Body and internals material, manual override and seals. . Refer to page 38 and 39 for options of voltage, current, solenoid enclosure, approval, insulation and special version. . Refer to page 38 for...
