1967 Inception of ROTEX 1970 Acquired 18000 Square meter of land for ROTEX, Dombivli (MAHARASHTRA). Constructed area is 6000 Square meter 1972 ROTEX entered into a technical collaboration with a Swiss company to manufacture Solenoid Valves 1976 ROTEX entered into an agreement with a Dutch Company to manufacture Pneumatic Actuators, Cylinders, Spool Valves etc. 1983 Started a second company at Vadodara in Gujarat ROTEX AUTOMATION LTD (RAL) to manufacture Solenoid Valves 1984 Bought a land of 7000 Square meter. The constructed area is 4200 Square meter 1988 To meet increasing market demand,...

Open the catalog to page 2

• ¾ • 3” tank mounted • Quick opening and closing for effective bag cleaning • Hytrel diaphragm ” to 2 ½” body ported • Compatible to ASI, Profibus, Devicenet. 3 VALVE ISLAND AND LIMITSWITCH PULSE JET VALVE/ DUST COLLECTOR VALVE • Size ½” to 2” • All wetted parts SS 316L • Wide range of operators from dia 40 mm to 110 mm • Precise dispensing of liquids like Petrol, Kerosene, Diesel, Water, etc. • The valve has dual orifice. Large for coarse flow up to 95% to 99% of set Value and small for fine flow ANGLE SEAT VALVE PETROL VENDING VALVE NEW PRODUCTS Specifications are subject to change...

Open the catalog to page 3

• • Pressure: Up to 40 bar Orifice: 12,20,25,40,50,65 mm • • Pressure: 0 - 150 bar Orifice: Up to 2 mm 2/2 PULSE JET VALVE • ¾ • Pressure: 8.5 bar/16 bar • Orifice: ”, 1”, 1½”, 2”, 2½”, 3” • Pressure: Up to 20 bar Orifice: 10,12,20,25,40,50 mm • Orifice p to 10 mm • Pressure: Up to 400 bar : U 4 2/2 PISTON OPERATED SOLENOID VALVE 2/2 DIRECT ACTING SOLENOID VALVE 2/2 DIAPHRAGM SOLENOID VALVE • • Pressure: 0 - 150 bar Orifice: Up to 10 mm 3/2 DIRECT ACTING SOLENOID VALVE 3/2 DIRECT ACTING SUB BASE MOUNTED SOLENOID VALVE FLUID CONTROL SYSTEM Specifications are subject to change without notice

Open the catalog to page 4

3/2 PILOT OPERATED POPPET VALVE • Orifice: 6,7,10,16,20,25,32,40,50 mm • Pressure: Up to 70 bar 5 • Orifice: 4.5,6.7,10 mm • Pressure: up to 10 bar 5/2 SPOOL VALVE 5/2 PILOT OPERATED POPPET VALVE • Orifice: 6,7,10,16,20,25,32,40,50 mm • Pressure: Up to 70 bar 3/2 SPOOL VALVE • • Pressure: 10 bar Orifice: 4.5,6.7,10 mm • Orifice: 6,12,25 mm • Pressure: Up to 16 bar 5/2 INLINE POPPET VALVE 5/3 PILOT OPERATED POPPET VALVE • Orifice: 6,10,16,25 mm • Pressure: Up to 40 bar. FLUID CONTROL SYSTEM Specifications are subject to change without notice

Open the catalog to page 5

• panel box as per customer's logic/ Design Solenoid valves mounted in the 6 • Modular expandable design • 2/2, 3/2, 5/2 & 5/3 version possible • Intrinsic Safe version available • Working pressure 10 bar • Subbase version available VALVE ISLAND 15 mm WIDTH INTRINSICALLY SAFE SOLENOID VALVE WITH CERCUIT • safe solenoid without any change in parameters • Working pressure up to 12 bar 2/2, 3/2, and 5/2 valve with intrinsically PANEL BOX CUSTOMISED PRODUCT • Solenoid Valve for Electric and Diesel Locomotives • Manifold Mounted Valve • 2/2,3/2,5/2 Valve duly mounted on manifold MANIFOLD MOUNTED...

Open the catalog to page 6

3/2, 5/2 valve • Working pressure up to 8 bar • Suitable for zone 1 Remote i/o • • to work as power fail to stayput type (LC) • Pressure up to 20 bar 2/2, 3/2, 5/2 valve with Latch solenoid for valve • 5 W, 2 W, 0.4 W solenoid • Pressure up to 16 bar 2/2, 3/2, and 5/2 valve operated with 7 INTRINSICALLY SAFE SOLENOID VALVE TERMINAL BOX ENCLOSURE • i.e. low power solenoid housed in Ex d enclosure • Pressure up to 8 bar • Suitable for zone 1 Remote i/o 3/2 and 5/2 valve with dual protection 2/2, 3/2, 5/2 manual reset • Manual reset off solenoid valve available • Pressure up to 16 bar • MANUAL...

Open the catalog to page 7

LIMIT SWITCH EXPLOSION PROOF o ROTARY ACTUATOR 180 WEATHER PROOF • • ± 10º End stroke adjustment • Torque up to 5110 Nm Double Rack and Pinion Actuator • • Type: DRV, DRC • Torque up to 112000 Nm Single Rack and Pinion Actuator • • Single/ Double acting 180° Rotary Actuator Actuator with Explosion proof solenoid valve and electro-pneumatic positioner • • Proxy switch and Feedback Positioner Limit switch mounted with Micro switch, AUTOMATED VALVE LIMIT SWITCH BOX ROTARY ACTUATOR ECF ROTARY ACTUATOR 8 VALVE AUTOMATION SYSTEMS Specifications are subject to change without notice

Open the catalog to page 8

• Pneumatic Actuator with limit switch, solenoid valve for On/ Off function • Complete valve automation system designed and developed as per customer requirement • Linear cylinder with volume Booster valve for operating damper/ globe/ gate valve with positioner 4-20 mA or 5-15 psi AUTOMATED VALVE POWER CYLINDER - PROPORTIONATE AUTOMATED VALVE AUTOMATED VALVE AUTOMATED VALVE • Pneumatic Actuator with Positioner for regulation duty • Pneumatic Actuator with Positioner for regulation duty • Linear cylinder with limit switch box for operating globe valve/air damper POWER CYLINDER ON/ OFF 9...

Open the catalog to page 9

CYLINDER Æ8 TO Æ25 mm MOUNTING SHORT STROKE CYLINDER • Single / Double acting cylinder Stroke upto 300 mm • Stroke upto 3000 mm Single / Double acting cylinder • Complete range of mountings and piston rod accessories • Short stroke cylinder for clamping application Diameter upto 100 mm, Stroke upto 50 mm • return valve Orifice 4.5, 6.7, 12 mm 3/2, 5/2 and 5/3 hand operated, hand/ spring • return valve Orifice 3, 4.5, 6.7, 10 mm 3/2, 5/2 and 5/3 hand operated, hand/spring CYLINDER Æ32 TO Æ160 mm 10 HAND OPERATED VALVE AIR, LEVER, PUSH BUTTON OPERATED VALVE PNEUMATICS Specifications are...

Open the catalog to page 10

POWER CYLINDER SPOOL VALVE WITH STAINLESS STEEL BODY • S media which has a danger of getting contaminated pecial pinch solenoid valve for harsh media or • Power cylinder with manual override • Body and internals most suited for Pharma, Oil and Gas, Petrochemical and Food industry • Working pressure up to 400 bar Spool valve with various options made in SS 316 PINCH VALVE SPECIAL CYLINDER GAS OVER OIL 3 POSITION ACTUATOR • Single acting actuator can be made to work as 3 Position actuator using a 3rd CAM for setting 3rd position operated by a special solenoid valve 3 position actuator with...
