SMARTFLEX

Product catalog summary

Overview: The document describes the SmartFlex, an advanced modular UV-Flexo machine designed by Rotatek S.A. for efficient label and flexible packaging printing. It emphasizes minimal waste, high productivity, and superior flexo quality.

Key Features:

Design: The machine is designed with a short linear web path to minimize waste and is ideal for single-pass production of various materials including self-adhesive labels, monofoils, BOPP, PET, PVC, and more.
Flexo Unit: Fully automated with shaftless technology, the Flexo Unit ensures less waste, faster make-ready times, and high-quality output. It features easy access for cleaning and setup.
Rail System: Offers flexibility for turn bars, cold stamping, and lamination, allowing multiple configurations and the ability to print on both sides of the material.
Die Cutting: The rotary die-cutting station provides high accuracy with a micro-adjustment system for perfecting die-cut shapes.
Main Control Panel: A multi-touch screen interface allows easy management of machine units, with access to technical and operational information.
Automatic Register System: Utilizes digital sensors for high-quality accuracy and stability, reducing waste and enhancing productivity.

Technical Specifications:

Max. mechanical speed: up to 150m/min (200m/min on request)
Max. web width: 350 mm
Maximum printing width: 330 mm
Printing repeat length: Variable between 8” and 24”
Die cutting repeat length: Variable between 10” and 24”
Max. Diameter Unwind: 1,000mm
Max. Diameter Rewind: 700mm

Additional Technologies: The machine supports various technologies including hot foil stamping, embossing, lamination, UV curing, and more, enhancing its versatility for different printing needs.

Catalog excerpts

SMART FLEX ADVANCED MODULAR UV-FLEXO MACHINE WITH SHAFTLESS TECHNOLOGY ROTATEK S.A. AVDA. GRAELLS Nº 39 08173 SANT CUGAT DEL VALLÉS BARCELONA, SPAIN T: 0034 93 674 52 50 SKYPE: rotateksa www.rotatek.com [email protected] DESIGNED WITH THE SHORTEST LINEAR WEB PATH FOR THE MINIMUM WASTE. IDEAL FOR PRINTING ANY KIND OF LABEL OR FLEXIBLE PACKAGING MATERIAL IN A SINGLE-PASS PRODUCTION. THE BEST PRODUCTIVITY AND MAKE READY TIMES WITH THE HIGHEST FLEXO QUALITY. FOR ALL KIND OF MATERIALS: Self-Adhesive Labels, Monofoils, BOPP, PET, PVC, Laminates, Wrap Around, Shrinkable Sleeves, PVC Labels, Aluminium, Multi-substrates, Sandwich, Technical Labels

Open the catalog to page 1

1. FLEXO UNIT The Advanced Flexo Unit of the SmartFlex is fully automated. With fully shaftless technology, a direct motor drives the impression cylinder and all operations in the flexo unit are motorized with a very accurate system in order to achieve less waste, fastest make-ready times and the highest flexo Quality. The unit has very easy access for cleaning and setup times. Fully automatic! 2. RAIL SYSTEM FOR COLD STAMPING AND LAMINATION The Rail System for Foil Cold Stamping and Lamination is very flexible, giving the opportunity to add value to the printed products to meet the most demanding...

Open the catalog to page 2
